VMAX IP G4™
®
When selected, the NVR's menu bar remains on the screen permanently.
The Toolbar in Playback Mode
In the Playback View, move the mouse cursor to the bottom of the screen to show the menu bar.
Channel
Indicates the currently selected channel.
Intelligent Search Bar
Shows recording status for the selected channel from 00:00 to 24:00. A white-vertical line indicates
the time currently displayed. Moving the white-vertical line will update the video while seeking.
Previous/Next Date Search
Users can move to the previous date or the next date to search through recorded footage.
Playback Controls
: Playback speed control. (x32 / x16 / x8 / x4 / x2).
: Move backward one frame
: Stop button
: Play button
: Move forward one frame
: Playback speed control. (x2 / x4 / x8 / x16 / x32)
: Current playback speed
Screen Display Mode
Select the preferred display mode from 1CH, 4CH, 9CH, or 16CH splitscreen mode options.
Backup
Backup recorded video to an external device. See "4.6 Export" for details.
Playback
Switch to playback mode. See "3.7 Playback Recorded Image" for details.
Exit
Close playback mode and move to Live Mode.
Pin
