SECTION 3 - ELECTRICAL CONNECTIONS FOR ELECTRIC MODELS
Connection for E2 and E4 - No Door Light
4a
Connection for E2 and E4 - With Door Light and Programmable Night Light
4b
Connection for E2 and E4 - With Door Light and Manual Control Night Light
4c
© 2019 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376
www.robern.com
Installation instructions
Circuit Breaker
120 VAC
20A GFI
Circuit Breaker
Black (L)
120 VAC
White (N)
20A GFI
Green (G)
Field Connection
Circuit Breaker
Black (L)
120 VAC
20A GFI
White (N)
Field Connection
Black (L)
White (N)
Green (G)
Field Connection
Black (L)
Wall-mounted
Dimmer/switch
Wall-mounted
Dimmer/switch
Black (L)
White (N)
Wall-
mounted
night light
switch
Black (L)
White (N)
Green (G)
9
Cabinet Power Circuit
Black (L)
Black (L)
White (N)
White (N)
Ground (G)
Red (L)
Black (L)
Circuit
White (N)
White (N)
Black (L)
Black (L)
White (N)
White (N)
Ground (G)
Red (L)
Black (L)
White (N)
White (N)
Yellow (L)
Black (L)
Black (L)
White (N)
White (N)
Ground (G)
Part no. 209-1319-rA rev. 08/21/19
Uplift Tech Cabinet
Door
Light
Cabinet
Power
Circuit
Door
Light
Circuit
Night
Light
Circuit
Cabinet
Power
Circuit
