OPERATION

1. Counterweight
Set the tonearm lift -14- (without the needle guard) to the „DOWN" position. Now move the tonearm -12- to just in front of the turntable platter
-1-. Adjust the counterweight -17- by turning it clockwise so that the tonearm -12- does not tilt up or down, i.e. it should be balanced parallel to the
record. Then guide the tonearm -12- back into the tonearm support -13-. Adjust the counterweight scale -16- on the counterweight so that the posi-
tion „0" is above the marking line. Turn the counterweight further clockwise until the scale shows the value that corresponds to the recommended
needle tracking force of the pick-up system.
2. Anti-Skating Wheel
Adjust the Anti-Skating Wheel -15- so that the setting directly matches tracking force of the fitted cartridge.
3. Selecting PRE-AMP ON/OFF & Turning on Power
Check the PRE AMP ON/OFF -7- position. Depending on your phono/line connection choice, the pre-amplifier should be turned on or off.
After all connections have been made and all settings have been adjusted you can turn the device on via the ON/OFF Button -6-.
4. Playback
Place the record onto the optional felt mat -27- on the record platter -1-. Select the appropriate speed for your record with the 33/45 switch -9-.
Remove the needle guard from the pick-up system -11-. Now set the tone arm lift -14- to the „UP" position and move the tone arm -12- over the part
of the record you want to play. Then set the tonearm lift -14- to the „DOWN" position so that the tonearm lowers onto the record groove.
NOTE! You can also leave the tone arm lift permanently in the „DOWN" position and lower the tone arm manually to the desired position.
When doing so, be careful not to damage the needle of the pick-up system.
5. USB-Recording (Connection to a Computer)
Connect the USB Port -10- to a spare USB port on your PC. The USB audio interface will be recognized automatically (USB Audio Codec) and does
not need additional drivers (Class Compliant). After the USB sound card has been installed automatically, you can adjust the following settings in
your preferred recording software or OS system settings:
- 2-channel
- 16-bit
- 48 000 Hz
NOTE! There should always be a direct USB connection to the computer. If a USB hub is used, there may be occur some interferences.
There are a number of recording programmes available. We can recommend Audacity as a free version.
Further information and download is available at: www.audacityteam.org.
NOTE!
Set the record player (USB Audio Codec) as the recording device in your software. If you have any support questions regarding the software /
recording function, please contact the provider's website or hotline directly.
6. Dust Cover
Place the dust cover on the hinges and then insert the hinges into the holders -20- provided. The Dust Cover protects your turntable when it
is not in use. However, we recommend to remove the Dust Cover when the turntable is in use, as it will have a negative impact on the acoustic
performance. Furthermore, your turntable should be placed on a base that is as resonance-free as possible.
HELP & SUPPORT
If you need additional help or have technical questions,
you can contact our support team:
https://www.reloop-hifi.com/support-ticket-request
Subject to alterations.
Illustrations similar to original product.
Misprints excepted.
14

TECHNICAL SPECIFICATIONS

Turntable Section:
- Type of turntable: ................................................................................ Belt-Driven manual Turntable System with USB Interface
- Drive: .................................................................................................... Belt drive
- Motor: .................................................................................................... DC Motor
- Rotation speeds: .................................................................................. 33 1/3, 45
- Starting Torque: ................................................................................... //
- Start-up time / rpm change: ............................................................. //
- Wow and Flutter: ................................................................................. 0,2% WRMS
- S/N Ratio: ............................................................................................. >45dB or higher
- Breaking System: ................................................................................ Manually
Turntable Platter:
- Turntable Platter: ................................................................................ Acrylic glass
- Diameter: ............................................................................................... 300 mm
- Weight: .................................................................................................... 1.7 kg
Tonearm Section:
- Type: .................................................................................................... Straight Tonearm
- Effective Length: ................................................................................. 223.6 mm
- Overhang: ............................................................................................. 18.61 mm
- Tracking Error Angle: .......................................................................... ±1.5°
- VTA Adjustment Range: ..................................................................... - 2 ~ 4 mm
- Applicable Cartridge Weight: ............................................................ 7.2 ~ 11.2 g (incl. Headshell)
- Anti-Skating Range: ............................................................................ 0 - 4 mm
- Terminals: ............................................................................................. 1x PHONO/LINE Out
Cartridge:
- Ortofon 2M Red
- Output voltage at 1000 Hz, 5cm/sec.: ............................................ 5.5 mV
- Channel balance at 1 kHz: .................................................................. 1.5 dB
- Channel separation at 1 kHz: ............................................................. 22 dB
- Channel separation at 15 kHz: .......................................................... 15 dB
- Frequency response: ........................................................................... 20-20.000 Hz + 3 / - 1 dB
- Tracking ability at 315Hz at recommended tracking force: ........ 70 µ Mm
- Compliance, dynamic, lateral: ........................................................... 20 µ Mm
- Stylus type: .......................................................................................... Elliptical
- Stylus tip radius: ................................................................................. r/R 8/18 µm
- Tracking force range: .......................................................................... 1.6-2.0 g (16-20 mN)
- Tracking force, recommended: .......................................................... 1.8 g (18 mN)
- Tracking angle: ..................................................................................... 24.7°
- Internal impedance, DC resistance: ................................................. 1.3 kOhm
- Internal inductance: ............................................................................ 700 mH
- Recommended load resistance: ........................................................ 47 kOhm
- Recommended load capacitance: ..................................................... 150-300 pF
- Cartridge colour, body/stylus: ........................................................... Black/Red
- Cartridge weight: ................................................................................. 7.2 g
General:
- Power Supply: ...................................................................................... 12V, 1A DC
- Power consumption: ........................................................................... 12W
- Dimensions: .......................................................................................... 420(W) x 356(D) x 148(H) mm
- Weight: ................................................................................................... 8.2 kg
Incl.: dust cover, 2x hinges, Felt Mat, international power supply (UK/EU/US), RCA cable, Headshell with Ortofon 2M Red (pre-installed),
7" aluminium adapter, Acrylic turntable platter, operation manual & counterweight, Allen key , USB-cable
