COMPONENT IDENTIFICATION

FRONT VIEW
■
RUN LED
1
2
3
4
5
6
ERR LED
7
8
11
12
13
14
15
16
17
18
19
20
■ STATUS INDICATOR LED
RUN indicator: Bi-color (red/green) LED;
Red when the bus A operates normally;
Green when the bus B operates normally;
Amber when both buses operate normally.
ERR indicator: Bi-color (red/ green) LED;
Green in normal operating conditions;
Red with abnormal configuration.
Output status indicator: Red LED; turns on with the output
ON.
■ SIDE DIP SW
(*)Factory setting
• I/O Mode Setting: SW2-7
Set output operation mode (Whether Output Complete Sta-
tus indicator is ON or OFF) *
SW
Input and Output
SW2-7 OFF (*)
*1. Output completion status is compatible with interface
modules model: R3-NC1, -NC3, -NE1, -NM1 and -NDx of
firmware version V2.00 or higher. Other interface modules
are not compatible. So, set I/O Mode as output (SW2-7:
ON) to use it.
Note 1: R3-NL1 and R3-NL2 are not available with this model.
• Output ON time: SW1
For setting Output ON time, DIP switch 1 through 8 correspond to each binary digit 1st through 8th digit. For every setting,
ON time will be as indicated below.
SW
0.1 (*)
SW1-1 OFF
SW1-2 OFF
SW1-3 OFF
SW1-4 OFF
SW1-5 OFF
SW1-6 OFF
SW1-7 OFF
SW1-8 OFF
Note 2: Be sure to set unused SW2-1 through 2-6 to OFF.
SIDE VIEW
■
9
10
11
12
13
14
15
Status Indicator
16
LED
1
2
3
4
5
6
7
8
9
10
1
I/O MODE
Output
ON
0.2 0.3
ON OFF
OFF ON
OFF OFF
OFF OFF
OFF OFF
OFF OFF
OFF OFF
OFF OFF
