Zendure SolarFlow ZDSPVH1200 User Manual page 29

5.3.3 Disconnection
Note : The method of disassembly is subject to the instructions of the
microinverter, and please confirm the warranty terms of the
microinverse before disassembly.
If you have installed the balcony solar system, you need to disconnect it
according to the following steps:
1
Unplug the cables of the microinverter and the home grid.
1
Only unplug the cables of the first solar panel and the microinverter.
2
Note: The installation of the solar panel does not need to be moved
unless you want to change the location.
The same way to unplug the cables of the second solar panel and the
3
micro-inverter.
Unscrew the mounting screws of the micro-inverter, remove the micro-
4
inverter fixed on the solar panel or metal bracket.
Note: Ensure that the state after disconnection is as shown in following
figure.
3
4
2
EN
9
