- Page 1 User Manual...
-
Page 2: Table Of Contents
Factory Reset......................... 21 Master/Slave Mode ..................RFC Remote Control..................RFC Remote Control Operation..................23 5. Maintenance................Product Maintenance ..................6. Technical Specifications ............Contact Us ..................Warranty & Returns..................Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... -
Page 3: Before You Begin
Important installation or configuration information. The product may not function correctly if this information is not used. Useful information. Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... -
Page 4: Safety Notes
♦ Leave the product unattended while charging. ♦ Deplete the battery below 10%. ♦ Charge the battery in a closed container. ♦ Charge for more than 24 hours. Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... -
Page 5: Fcc Compliance
Electronically published by Chauvet in the United States of America. Chauvet, the Chauvet logo, and Freedom Par H9 IP and H9 IPX4 are registered trademarks or trademarks of Chauvet & Sons LLC. (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company and product names and logos referred to herein may be trademarks of their respective companies. -
Page 6: Introduction
Carry handle Power button Gore valve Kickstand Magnetic Kickstand diffuser release Freedom Par H9 IPX4 Freedom Par H9 (x4) Custom foam case RFC-XL remote (optional) RFC remote Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... -
Page 7: Product Dimensions
126 mm 4.7 in 120 mm 4.7 in 120 mm 4.9 in 125 mm Freedom Par H9 IPX4 19.8 in 503 mm 13.7 in 15.8 in 349 mm 402 mm Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... -
Page 8: Setup
AC Power The Freedom Par H9 IP has an external power supply and can work with an input voltage of 24 VDC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel or refer to the product’s specifications chart. -
Page 9: Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The Freedom Par H9 IP may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes. -
Page 10: Accessories
To attach or remove the magnetic diffuser and/or the sleeve from the fixture, see the diagram below: Sleeve Magnetic diffuser The Freedom Par H9 IPX4 comes in an easily transportable gear bag with custom foam: Custom foam Gear bag Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... -
Page 11: Operation
HOT PINK Selects preset colors EMERALD OCEAN BABY PINK GOLDENROD LAVENDER FADED ORANGE FUSCHIA AMBIENT RADIOACTIVE GREEN SAPPHIRE UV RED UV YELLOW UV GREEN UV BLUE ORANGE CREAM DUSK Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... - Page 12 Operation Main Menu Programming Levels Description 2700K 3500K Preset 4000K Selects preset colors 5000K 6000K Static Selects a single static color or a Fixed Color combination of static colors Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1...
- Page 13 Selects the foreground and background colors, and adjusts the speed of auto programs Auto Show FG Color Auto 5–9 Note: Foreground and background colors BG Color are available only for auto programs 5–9. Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1...
- Page 14 GBAWP RGBAWP Sound Show Sound Sense 000–100 Adjusts sound sensitivity Slave1 Slave2 Sets which slave unit(s) will mimic the Slave Setting master unit Slave3 Slave4 Manual 125–255 White Balance Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1...
-
Page 15: Dmx Configuration
Choosing a starting address that is too high could restrict access to some of the product’s channels. The Freedom Par H9 IP uses up to 16 DMX channels in a 16Ch DMX mode, which defines the highest configurable address to 497. -
Page 16: Dmx Values
176 197 Auto program 8 198 219 Auto program 9 220 241 Auto program 1–9 242 255 Sound show Foreground color – – 000 255 0–100% dimmer Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... - Page 17 184 187 Red + green + white + purple 188 191 Red + blue + amber + white 192 195 Red + blue + amber + purple Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1...
- Page 18 112 115 Red + amber + white 116 119 Red + amber + purple 120 123 Red + white + purple 124 127 Green + blue + amber Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1...
- Page 19 004 007 Dimmer speed mode off Dimmer speed – – 008 011 Dimmer speed mode 1 (fastest) mode 012 015 Dimmer speed mode 2 016 019 Dimmer speed mode 3 (slowest) Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1...
-
Page 20: Standalone Configuration
6. Press <ENTER>. Fixed Color Mode To run the Freedom Par H9 IP on a single static color or a combination of static colors, do the following: 1. Press <MENU> repeatedly until Static shows on the display. 2. Press <ENTER>. -
Page 21: Automatic Programs
5. Press <ENTER>. The product will return to the last selected mode. Sound Sensitivity To set the sound sensitivity on the Freedom Par H9 IP, follow the instructions below: 1. Press <MENU> repeatedly until Sound Show is displayed. 2. Press <ENTER>. -
Page 22: D-Fi Setting
2. Use <UP> or <DOWN> to set the D-Fi channel, from CH01–CH16. 3. Press <ENTER>. RF Setting To set how the Freedom Par H9 IP will receive RF signal and work with RF remotes, do the following: 1. Press <MENU> repeatedly until RF Setting shows on the display. 2. Press <ENTER>. -
Page 23: Password
Operation Password To password protect a Freedom Par H9 IP fixture, follow the instructions below: 1. Press <MENU> repeatedly until Password shows on the display. Press <ENTER>. 2. Use <UP> or <DOWN> to select On (activates password protection) or Off (deactivates password protection). -
Page 24: Master/Slave Mode
The Master/Slave mode allows a single Freedom Par H9 IP product (the “master”) to control the actions of one or more Freedom Par H9 IP products (the “slaves”) without the need of a DMX controller. The master product will be set to operate in Standalone, whereas the slave products will be set to operate in Slave mode. -
Page 25: Rfc Remote Control
Operation RFC Remote Control The Freedom Par H9 IP can be operated with an RFC remote (comes with Freedom Par H9 IPX4) or an RFC-XL remote (sold separately). To enable RF control, follow the instructions below: Press <MENU> repeatedly until RF Settings shows on the display. -
Page 26: Maintenance
Softly drag any dirt or grime to the outside of the transparent surface. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... -
Page 27: Technical Specifications
104 °F (40 °C) Convection Input/Output Channel Range D-Fi 6, 8, or 16 Ordering Product Name Item Code UPC Number Freedom Par H9 IP 03032027 781462223755 Freedom Par H9 IPX4 03032028 781462223762 Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1... -
Page 28: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1...
