New Classic Furniture DIXON D1426-22 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which
may have come loose inside the carton during shipment. Identify and count all items and compare with the PARTS
LIST and/or HARDWARE LIST shown below.
Caution: Please read the instructions thoroughly before assembly.
1.` We recommend that you assemble this product with the assistance of another person: this will make the
assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2. Please do not over tighten screws or bolts until the assembly is completed.
3. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficiently
PARTS LIST
COMPONENT
NO:
1
Chair Back
Seat Frame
2
3
Cushion Seat
Side Stretcher
4
Left & Right
Front Stretcher
5
6
Legs Left & Right
ASSEMBLY INSTRUCTIONS
ITEM: D1426-22 DIXON COUNTER CHAIR
Q'TY
DRAWING
2pcs
2pcs
2pcs
4pcs
2pcs
4pcs
MADE IN VIETNAM
HARDWARE LIST
NO.
DRAWING COMPONENT
A Flat Washer 5/16"
B
Spring Washer 5/16"
C
Nut 5/16"
D Allen Wrench
Short Bolt 1/4" x 1 3/4"
E
F Long Bolt 1/4" x 3"
Screw 5/32" x 1 1/2"
G
Note: Tool needed but not supplied
QTY
22 pcs
22 pcs
8 pcs
1 pc
6 pcs
8 pcs
24 pcs
