Page 30
Catalogue Understand the flight safety Disclaimer & Warnings Know your aircraft Know your WK-V8 Controller Parameters Check Battery Level Charging Download the WK Fly Application Introduction of the WK Fly APP interface 10-12 Prepare the WK-V8 controller Prepare the aircraft 12-13 Ready to fly 13-14...
Page 31
The user undertakes to use this product only for legitimate purposes and agrees to these terms and conditions and to any related policies or guidelines that Walkera may establish. To the fullest extent permitted by law, in no event will Walkera be liable for any indirect, consequential, punitive, incidental, special or criminal damages, including damages resulting from your purchase of, use of, or inability to use this product (even if Walkera has been advised of the possibility of such damages).
Page 32
15) Type-C upgrade/charging port 16) MicroSD card slot * 1) Before using T210 Mini, please watch the instructional video in WK Fly App to upgrade related firmware and calibration related items and read the "Operation Guide" carefully to avoid property damage or even personal injury caused by improper operation.
Page 33
T210 MINI(WK-V8)Operation guide Walkera All Rights Reserved Know your WK-V8 Controller The WK-V8 controller uses 2.4GHz long-distance digital encryption transmission technology, which can display high-definition pictures and flying device related parameters in real time through the voice handle display or connected mobile device.
Page 34
T210 MINI(WK-V8)Quick operation guide Walkera All Rights Reserved 12) Power button 13 Upgrad/charging port 14 Somatosensory control switch: Double-click to switch the somatosensory control object (switch between “ ” aircraft and “ ” gimbal); press and hold to turn on the somatosensory control; release to turn off the somatosensory control;...
T210 MINI(WK-V8)Operation guide Walkera All Rights Reserved 2)Voice control Turn on the power supply of the WK-V8, and turn on the power supply of the aircraft. After the aircraft is successfully connected with the WK-V8, call "Hello Drone" to wake up the voice control function of the the WK-V8, and then speak the voice command you want the aircraft to execute to the voice controller.
T210 MINI(WK-V8)Quick operation guide Walkera All Rights Reserved WK-V8 Controller Operating Frequency: 2.400~2.4835GHz Maximum Communication Distance: 3~4 km (open without shielding, no electromagnetic interference) Display Screen: 1.54-inch LCD screen Resolution: 240 * 240 Battery: 3.7V 5000mAh 21700 LiPo Maximum Follow Speed:...
Page 37
Apple iOS9.0 and above mobile phones and tablets.For Android system or Hongmeng system mobile device, please open the browser and enter the URL ( https://fly.walkera.cn/a/) or scan the QR code below to download and install the APP; for Apple iOS system, please go to the APP Store and search for WK Fly to download and install.
Page 38
Introduction of the WK Fly APP interface In this interface, you can preview the real-time HD video and photos taken by the T210 MINI, as well as dynamically set the parameters such as the aircraft, voice controller, camera gimbal and battery.
Page 39
T210 MINI(WK-V8)Operation guide Walkera All Rights Reserved 15) Camera Settings: Click the icon to expand the camera 18) Posture thumbnail icon: Click this icon to expand the attitude ball suspension window. Settings interface, which has professional Settings, photo settings, video settings and other settings.
T210 MINI(WK-V8)Quick operation guide Walkera All Rights Reserved Dragging up or down on the left side of the VR mode 28) Erase the flight track: Erase the flight track displayed display interface can switch the video display mode; on the map interface.
Activate and fly the aircraft and bind the device The brand new T210 MINI must be activated and bound to the device by the WK Fly App, please turn on the power of the aircraft and the remote control respectively, run the WK Fly App after connecting the mobile phone, and operate according to the interface prompts.
T210 MINI(WK-V8)Quick operation guide Walkera All Rights Reserved Satellite positioning signal indication and description 1) The status bar at the top of the WK-V8 controller display shows that the voice handle and the GPS status icon of the aircraft are all green, and the number of received satellites is high, indicating that the current satellite positioning signal is strong.
T210 MINI(WK-V8)Operation guide Walkera All Rights Reserved Manual take-off Double-click button A on the WK-V8 controller to unlock and start the aircraft motor, and then push the joystick up slowly. Double-click A button Slowly push the joystick up Manual landing Slowly pull down the joystick, after the aircraft touches the ground, pull the joystick to the lowest position and hold for 2 seconds, the motor will stop and lock.
T210 MINI(WK-V8)Quick operation guide Walkera All Rights Reserved Warning 1) Do not release the aircraft in a crowded place by taking off. 2) When the aircraft is released by throwing, it is strictly forbidden to grab the aircraft or the propeller from the top of the aircraft, otherwise the consequences will be at your own risk.
Page 45
T210 MINI(WK-V8)Operation guide Walkera All Rights Reserved Attentions: 1) In Follow Mode, the aircraft will always remain in the relative position above the person holding the voice handle on the ground. At this time, the height of the aircraft, the horizontal position relative to the handle, and the heading are all controllable.
T210 MINI(WK-V8)Quick operation guide Walkera All Rights Reserved The horizontal distance between the aircraft and the Home point is 20m or The altiude difference from the Home point is greater than the set RTL Height The horizontal distance between the aircraft and the Home point is 20m...
T210 MINI(WK-V8)Operation guide Walkera All Rights Reserved Take photos and videos You can press the C button or wake up the voice control function of the WK-V8 controller ,and speak the voice command to realize the remote control aircraft camera to take pictures or videos; You can also click the shutter icons in the APP interface of the mobile device to take pictures or videos.
Page 48
T210 MINI(WK-V8)Quick operation guide Walkera All Rights Reserved Warning 1) Please use the intelligent flight function in an open, unobstructed and obstacle-free environment, and always pay attention to whether there are obstacles such as people, animals, buildings, etc. on the path of the aircraft.
Page 49
T210 MINI(WK-V8)Operation guide Walkera All Rights Reserved Circe Follow After entering the Follow Mode, manually adjust the aircraft position and gimbal pitch, the recommended height is 20 meters, and the distance to the WK-V8 controller is 40 meters. Select an open place without obstacles and click the Circle Follow button on the App interface.
Description of downward vision system and TOF ranging system The T210 MINI downward vision system and TOF time-of-flight ranging sensing system are both located at the bottom of the aircraft. The downward vision system consists of a camera; the TOF ranging sensing system consists of a TOF detection light pulse sensor module, which can provide a reference for the height of the aircraft to ground and calculate the aircraft position information with the downward vision system.
Page 51
T210 MINI(WK-V8)Operation guide Walkera All Rights Reserved 5) Do not block or interfere with the vision system in any way, and avoid using it in an environment with too much dust and water mist, so as not to affect the clarity of the camera. Please do not block the TOF detection light pulse transceiver sensor in any way.
Page 52
T210 MINI(WK-V8)Quick operation guide Walkera All Rights Reserved Calibrate the WK-V8 controller joystick The calibration of voice handle lever has been set, please follow the following methods; Turn Off the aircraft power or lock the motor before operation. The operation method is as follows down until the cursor selects "...
When the battery comes into contact with water, it may decompose with reactions, causing spontaneous combustion and even an explosion. 2) Using batteries not officially supplied by WALKERA are strictly prohibited.For replacement, please go to the WALKERA official website for the relevant purchase information.walkera is not responsible for battery accidents and flight failures caused by the use of batteries not officially provided by WALKERA.
Page 54
T210 MINI(WK-V8)Quick operation guide Walkera All Rights Reserved Voice Handle Voice Command Set The Wake Up Word: Hello Drone Voice Handle Reply Word Voice Command Word Aircraft Performing Actions Start takeoff/ About to take off, please stay Take off Takeoff the drone...
Page 55
T210 MINI(WK-V8)Operation guide Walkera All Rights Reserved Voice Command Word Voice Handle Reply Word Aircraft Performing Actions Lens down Camera starts down Camera tilts down Lens up Camera starts up Camera tilts up Lock to follow target Target lock Start target lock...
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment Product name Sport Aerial Aircraft T210 MINI Manufacturer Guangzhou Walkera Technology Co.,Ltd Add No.48 Wangtai Rd ,Taishi industrial Park,Dongyong Town,Nansha Dist Guangzhou,China.
