Installation, Service and User
INSTRUCTIONS
FOR THE
ZERO MODEL: GEV60
SINGLE LID CHEST FREEZER
3-WAY: L.P. Gas, 230V Electric
& 12V DC
ZERO APPLIANCES (PTY) LTD
Cat. I
& I
3+ (28–30/37)
3B/P (30)
WARNING: THIS APPLIANCE MUST BE
EARTHED
ENSURE THAT THE GAS SUPPLY HOSE IS NOT IN
CONTACT WITH OR NEAR THE BURNER BOX
Advertisement
Table of Contents
Related Manuals for Zero Appliances GEV60
Summary of Contents for Zero Appliances GEV60
- Page 1 Installation, Service and User INSTRUCTIONS FOR THE ZERO MODEL: GEV60 SINGLE LID CHEST FREEZER 3-WAY: L.P. Gas, 230V Electric & 12V DC ZERO APPLIANCES (PTY) LTD Cat. I & I 3+ (28–30/37) 3B/P (30) WARNING: THIS APPLIANCE MUST BE EARTHED...
-
Page 2: Technical Data
Page1 TECHNICAL DATA Zero Appliances Model GEV60 Freezer Category: For use on Butane at 2.8-3.0 kPa 3+ (28-30/37) and Propane at 3.7 kPa. For use on Butane and Propane 3 B/P (30) mixtures (LPG) at 3.0 kPa Injector size 0.42mm diameter, marked ‘13’... -
Page 3: Installation Instructions
Page2 INSTALLATION INSTRUCTIONS: IMPORTANT INFORMATION FOR THE USER Only a registered LP Gas installer may install a gas installation. All registered installers are issued with a card carrying their registration number. Ask to be shown the card before allowing the installation work to commence and make a note of the Installer QCC number. Upon completion of the installation, the installer is required to explain the operational details of the installation together with the safety instructions. -
Page 4: Gas Connection
Page3 GAS CONNECTION: The appliance inlet is to the 8mm plain straight tube, allowing connection by means of a gas-tight compression fitting to comply with both EC and local regulations. The freezer is suitable for connection to butane/propane mixtures (LPG) at 2.8-3.0 kPa and to propane at 3.7 kPa. Means must be provided to turn off the gas supply. - Page 5 Page 4 If the odour persists, contact your dealer or gas supplier immediately. Do not store or use gasoline or other flammable vapour and liquid in the vicinity of this or any other appliance. USER OPERATING INSTRUCTIONS TO START ELECTRIC OPERATION 1.
- Page 6 Page 5 To terminate the gas operation turn off the shut-off valve on the gas bottle or gas installation. USERS NOTE: The gas safety valve knob (A) should never be depressed for periods longer than 15 seconds with the burner unlit as this can cause a potentially dangerous build- up of unburnt gas.
- Page 7 Page 6 TROUBLESHOOTING IF THE APPLIANCE FAILS TO WORK: Check the following points before calling for service: 1. That the instructions for starting the appliance have been followed. 2. The appliance is level. 3. If it is possible to start the appliance on an alternative energy sources. 4.
-
Page 8: Some Useful Hints
Page 7 11. The absorption unit is leaking. In the case of a visible leak, there will be traces of a yellow deposit at the point where the ammonia is escaping. If there is a leak on the evaporator inside the cabinet, a smell of ammonia may be noticeable inside the bin. -
Page 9: Cleaning Your Freezer
Page 8 10. You are aware that the temperature inside the appliance can vary according to the ambient temperature, the location of the freezer, the frequency with which the lid is opened, and the volume and concentration of products stored in it. 11. -
Page 10: In The Event Of Failure
Page 9 WARNING: The needle valve screw used for admitting the ammonia / hydrogen filling charge to an absorption unit is fitted to the unit’s reservoir. It is a strictly applied provision of the guarantee extended on the unit to the customer, that any interference with the filling valve screw will automatically void the guarantee. -
Page 11: Important Note
Page 10 IMPORTANT NOTE If there is a smell of ammonia, it is advised that the user turn off the appliance, clear out all the food and remove the appliance from dwelling areas. GAS BURNER PARTS LIST 1. SANS BRASS HOSE TAIL. 2. - Page 12 Made in South Africa (Pty) Ltd...
