Installation, Service and User
INSTRUCTIONS
FOR THE
ZERO DOMESTIC
MODELS:
GF180IP, GF215,
& GF200
SINGLE LID CHEST FREEZER
2-WAY: L.P. Gas & 230V Electric
ZERO APPLIANCES (PTY) LTD
Cat. I
& I
3+ (28–30/37)
3B/P (30)
WARNING: THIS APPLIANCE MUST BE
EARTHED
ENSURE THAT THE GAS SUPPLY HOSE IS NOT IN
CONTACT WITH OR NEAR THE BURNER BOX
Advertisement
Table of Contents
Related Manuals for Zero Appliances GF180IP
Summary of Contents for Zero Appliances GF180IP
- Page 1 FOR THE ZERO DOMESTIC MODELS: GF180IP, GF215, & GF200 SINGLE LID CHEST FREEZER 2-WAY: L.P. Gas & 230V Electric ZERO APPLIANCES (PTY) LTD Cat. I & I 3+ (28–30/37) 3B/P (30) WARNING: THIS APPLIANCE MUST BE EARTHED ENSURE THAT THE GAS SUPPLY HOSE IS NOT IN...
-
Page 2: Technical Data
TECHNICAL DATA Zero Appliances Model GF180IP, GF215 & GF200 Freezer Category: For use on Butane at 2.8-3.0 kPa 3+ (28-30/37) and Propane at 3.7 kPa. For use on Butane and Propane 3 B/P (30) mixtures (LPG) at 3.0 kPa Declared rate: Injector size 0.42mm diameter, marked ‘13’... -
Page 3: Installation Instructions
INSTALL ATION INSTRUCTIONS: IMPORTANT INFORMATION FOR THE USER Only a registered LP Gas installer may install a gas installation. All registered installers are issued with a card carrying their registration number. Ask to be shown the card before allowing the installation work to commence and make a note of the Installer QCC number. Upon completion of the installation, the installer is required to explain the operational details of the installation together with the safety instructions. -
Page 4: Gas Connection
IMPORTANT: There must be adequate space to reach the controls situated at the back of the appliance. NOTE: Any gas supply cylinder should have at least 250mm clearance if placed behind the appliance. GAS CONNECTION: The appliance inlet is to the 8mm plain straight tube, allowing connection by means of a gas-tight compression fitting to comply with both EC and local regulations. -
Page 5: For Your Safety
FOR YOUR S AFETY If you smell gas: Turn off gas supply at bottle. Extinguish all naked flames Do not operate any electrical appliances. Ventilate the area. Do not smoke while checking for leaks. Do not check for leaks with an open flame. If the odour persists, contact your dealer or gas supplier immediately. -
Page 6: Troubleshooting
3. Open flap B. 4. Keep the flame failure device knob (A) pressed in for approximately 5 seconds to allow gas to flow to the burner. 5. Strike a match and insert into flap hole (B). W hile the flame is burning press and hold the flame failure device for a further 10 seconds. -
Page 7: Some Useful Hints
The gas pressure is incorrect – check the pressure regulator at the gas cylinder or at the jet (6) of the burner. (Page 9 – Gas burner parts list). If the jet (6) is blocked, remove the jet, clean with alcohol or other solvent and blow through with compressed air. -
Page 8: Cleaning Your Freezer
some time. If the appliance is fitted with a locking device – remove key to prevent accidental locking. 3. Liquids or items with strong odors are well packaged. 4. The ventilation of the absorption unit is not obstructed. 5. You do not touch the absorption unit while it is in operation as parts of it will be extremely hot. - Page 9 DEFROSTING W ARNING: Normally the temperature of items would rise during defrosting and so, they should be consumed within 24 hours or discarded. Do not try to accelerate defrosting by using any kind of heating appliance, as this might damage the internal surfaces of the freezer.
-
Page 10: In The Event Of Failure
and no yellow tipping or sooting. Check the door/lid seals are in good condition. IN THE EVENT OF FAILURE If the burner will not light: Check adequate gas supply – through to burner. Depress flame failure device for 15sec and try lighting with a match. This must be done in a well ventilated area! QUALIFIED TECHNICIAN Check jet is clean –... -
Page 11: Important Note
IMPORTANT NOTE If there is a smell of ammonia, it is advised that the user turn off the appliance, clear out all the food and remove the appliance from dwelling areas. GAS BURNER P ARTS LIST 1. SANS BRASS HOSE TAIL. 2. - Page 12 Guarantee Registration For Guarantee registration please visit: https://zeroappliances.co.za/guarantee-form/ Complete the online form and click submit. Or scan the above QR code with your smart device which will take you to the form. Complete the online form and click submit. WARNING: THIS APPLIANCE MUST BE EARTHED.
