- Page 1 PJP4 SERIES PRODUCT INSTRUCTIONS STATIC MODEL NOTE: We recommend reading through the entire Assembly Instructions prior to proceeding with installation, service or maintenance. All references to left and right throughout this guide are as viewed from the front. Page 1 of 17...
-
Page 2: Product Specifications
PRODUCT SPECIFICATIONS PJP4 SERIES DIMENSION IMPERIAL METRIC Exterior Height 91.0 in 231 cm Interior Height 82.0 in 208 cm Exterior Width 43.5 in 1 10 cm Interior Width 41.0 in 104 cm Exterior Length 47.0 in 1 19 cm Interior Length 41.0 in... -
Page 3: Product Overview
PRODUCT OVERVIEW PJP4 SERIES • When using air operated screw drivers or impact wrenches, be sure that the torque setting does not exceed 28 inch pounds. • When using a battery-operated drill, set it to the lowest torque setting. • Please follow the instructions in the order they are presented. It is suggested that you read through the entire assembly instructions prior to proceeding with the assembly. - Page 4 FULL SIZE SCALE PJP4 SERIES FASTENER DRAWINGS (48) PC-000100 Rivet Large (1) PC-000117 Rivet Small (5) PC-000123 Washer Flange, Short Flange, Long Hollow Wall 1/4” x 5/8” Flat (79) PC-000106 Washer (26) PC-000103 Rivet Large (5) PC-000174 Screw 3/16” Back-up Flange, Medium 1/4”...
- Page 5 ASSEMBLY INSTRUCTIONS PJP4 SERIES STEP 2: CORNER MOLDINGS TO SIDE PANELS: Refer to Figure 2. Place a wall panel on top, and one on each side of the tanks. The miter cut end of the corner moldings go towards the top of the side panel.
- Page 6 ASSEMBLY INSTRUCTIONS PJP4 SERIES STEP 4: WASTE HOLDING TANK INSTALLATION: Refer to Figure 3. Position the tank so that it is centered between the left and right side wall panels and pushed up to the floor plate. There are drill spots on each of the side wall panels.
- Page 7 ASSEMBLY INSTRUCTIONS PJP4 SERIES STEP 6: FLY SCREEN INSTALLATION: (Each of the three sidewall panels has two vent screens. On the surface of each vent screen there is a date stamp symbol. The symbol goes toward the center of the sidewall panel, facing the inside.) For each of the three sidewalls, insert one screen from each side of the vent slot and overlap the center holes at the date stamp symbol (as shown in Figure 4).
- Page 8 ASSEMBLY INSTRUCTIONS PJP4 SERIES STEP 9: VENTILATION STACK INSTALLATION: Force the vent stack up through the 4” diameter hole in the roof. (This is intended to be a tight fit.) Slide the vent stack down and into the 4” diameter recessed hole in the holding tank so PC-000117 Rivet that it rests on the round ledge of the hole in the tank.
-
Page 9: Parts Diagram
PARTS DIAGRAM PJP4 SERIES http: / /www. p ol y j o hn. c om/pj 0 3-0007n/ PJ03-0007N - Roof PC-000570 - Screen http: / /www. p ol y j o hn. c om/pc- 0 00570/ http: / / www. p ol y j o hn. c om/pc- 0 00100/... - Page 10 PARTS DIAGRAM PJP4 SERIES FRONT ASSEMBLY PJP3-0012 - Hinge Tube https://www.pol y j o hn.com/pj p 3-0012-hi n ge-tube PJP4-0004R - Right Front Panel https://www.pol y j o hn.com/pj p 4-0004r-ri g ht-front-panel PC-000102 - Rivet http://www.pol y j o hn.com/pc-000102 http://www.pol y j o hn.com/pc-000106...
-
Page 11: Cleaning And Maintenance
PSD1-1000 SU3-0002PJ - PJ Model SU3-0001F - Fleet Model For a complete list of all our accessories, visit www.polyjohn.com/products/additional-products.html For a complete list of all our chemicals, visit www.polyjohn.com/supplies/pros-choice.html CLEANING AND MAINTENANCE Use a mild soap to clean all surfaces and component parts. - Page 12 Singlefold Towels (item # GP-23504). ® • Toilet Paper Dispenser – PolyJohn offers a 2 roll dispenser, or a 3 roll dispenser. The dispenser rod is designed for small core toilet paper rolls, but can work with standard rolls if desired.
- Page 13 Chemical exposure typically occurs through inhalation, ingestion, or adsorption. PolyJohn products are not intended to be used in these methods. PolyJohn Corporation cannot foresee all uses of their products (both intended and unintended uses) and as a result has opted to provide a general warning of known chemical presence.
- Page 14 PJP4 SERIES REACH Compliance We certify that all components of the PolyJohn PSW3-1000 conform to REACH standards. Specifically, we cite Article 7 of the Standard which indicates as follows: Article 7(1) requires Producers and Importers of products to register with the ECHA chemical substances that are intentionally released from the products during use.
-
Page 15: Frequently Asked Questions
A: The new PolyJohn Urinal has been completely redesigned. The new design has been proven to be the best shape and form to keep splash- back to a minimum. The side walls are much higher and there is no lip on the inside. This will help keep the urinal clean. The entire urinal has smooth surfaces as well to aid in cleaning. -
Page 16: Warranty
Sinks, Tanks, Trailers and SaniStands PolyJohn Enterprises warrants our sinks, tanks, trailers and sanistands from the date of purchase. Any misuse or abuse of our products or failure to properly follow recommended procedures shall void this warranty. The warranty is a 1 year limited warranty and a 90 day limited warranty for components thereof. - Page 17 OUR MISSION STATEMENT “PolyJohn is a family owned, state of the art, plastics manufacturing company dedicated to providing its employees with a work environment committed to excellence, and its customers with innovative products, services and technology that meet or exceed their requirements.”...
