POLYJOHN
USA
PolyJohn Enterprises Corp
2500 Gaspar Ave.
Whiting, IN 46394
Phone: 800-292-1305
Fax: 219-659-0625
www.polyjohn.com
info@polyjohn.com
• 13/64" Drill Bit
PH04 Comfort XLT™
Mounting Instructions
Thank you for purchasing the optional grab bar kit for the
Comfort XLT unit. The 2019 redesign of the Comfort XL
unit to incorporate a larger tank with flushing capabilites
does not require internal grab bars. Please read through
these instructions prior to installing the grab bars. If your
unit has the optional urinal installed, the left side grab bar
will not be used. If your unit has the optional sink (required
for the fresh flush option), you will be installing the shorter
PH04-0020 grab bars on the rear and right side wall.
All references to left and right will be from viewing the
unit from the front.
POLYJOHN
WORLDWIDE
PolyJohn (UK) Ltd.
Equinox 1 Audby Lane
Wetherby, England LS22 7RD
Phone: 44 (0) 1937-583333
Fax: 44 (0) 1937-583322
sales@polyjohn.co.uk
~~Tools Required for Assembly~~
• Rivet Gun w/ 3/16" nose piece
PH04 Comfort XLT Grab Bar - June 2019
Page 1 of 3
Grab Bar
GENERAL OVERVIEW
POLYJOHN
CANADA
PolyJohn Canada
P .O. Box 2300
199 Forest Plain Rd.
Orillia, Ontario LV3 6S2
Phone: 800-465-9590
Fax: 705-325-8250
info@polyjohncanada.ca
• Tape Measure
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PolyJohn Comfort XLT PH04
Summary of Contents for PolyJohn Comfort XLT PH04
- Page 1 All references to left and right will be from viewing the unit from the front. POLYJOHN POLYJOHN POLYJOHN CANADA WORLDWIDE PolyJohn Enterprises Corp PolyJohn Canada PolyJohn (UK) Ltd. 2500 Gaspar Ave. P .O. Box 2300 Equinox 1 Audby Lane Whiting, IN 46394 199 Forest Plain Rd.
- Page 2 ASSEMBLY INSTRUCTIONS Step 1. Grab Bar Mounting Locations To mark the holes to mount the left side grab bar (if no urinal is installed), use the diagram to the right as a reference, and mark the mounting hole locations as shown. There are a total of 8 hole locations for each grab bar.
- Page 3 Association International. Contact your area sales representative for further details. OUR MISSION STATEMENT “PolyJohn is a family owned, state of the art, plastics manufacturing company dedicated to providing its employees with a work environment committed to excellence, and its customers with innovative products, services and technology that meet or exceed their requirements.”...
