P
J
®
OLY
OHN
POLYJOHN
USA
PolyJohn Enterprises Corp
2500 Gaspar Ave.
Whiting, IN 46394
Phone: 800-292-1305
Fax: 219-659-0625
www.polyjohn.com
info@polyjohn.com
PH03 Comfort Inn™
Assembly Instructions
USA PATENTS: 4,577,351, 4,637,299, 4,793,100, 4,831,671, 4,895,400, 4,918,765
SPECIFICATIONS
DIMENSION
Exterior Height
Exterior Width
Exterior Length
Door Frame Height(I.D.)
Door Frame Width(I.D.)
Tank Seat Height
Weight
Static Tank Capacity
Recirc Tank Capacity
Side Panel Decal Area
Door Panel Decal Area
We recommend reading through the entire Assembly Instructions prior to
proceeding with installation, service or maintenance. All references to left
and right throughout this guide are as viewed from the front.
POLYJOHN
WORLDWIDE
PolyJohn (UK) Ltd.
Equinox 1 Audby Lane
Wetherby, England LS22 7RD
Phone: 44 (0) 1937-583333
Fax: 44 (0) 1937-583322
sales@polyjohn.co.uk
PH03 Comfort Inn - September 2008
Page 1 of 12
Des. 304,082 CANADIAN PATENT: 1311898
IMPERIAL
METRIC
91 in
231 cm
62 in
157 cm
62 in
157 cm
74 in
188 cm
32 in
19 in
240 lb
108 kg
33 gal
125 L
22 gal
83.6 L
12" x 23"
30cm x 58cm
27" x 27"
68cm x 68cm
POLYJOHN
CANADA
PolyJohn Canada
P.O. Box 2300
199 Forest Plain Rd.
Orillia, Ontario LV3 6S2
Phone: 800-465-9590
Fax: 705-325-8250
info@polyjohncanada.ca
81 cm
48 cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the Comfort Inn PH03 and is the answer not in the manual?

Questions and answers

Summary of Contents for PolyJohn Comfort Inn PH03

  • Page 1 All references to left and right throughout this guide are as viewed from the front. POLYJOHN POLYJOHN POLYJOHN CANADA WORLDWIDE PolyJohn Enterprises Corp PolyJohn Canada PolyJohn (UK) Ltd. 2500 Gaspar Ave. P.O. Box 2300 Equinox 1 Audby Lane Whiting, IN 46394 199 Forest Plain Rd.
  • Page 2 PH03 Comfort XL - Parts - March 2012 Page 1 of 3...
  • Page 3 PH01-0003 Front Assembly NOT SHOWN PC-000794 - Serial I.D. Plate **PC-000200 - Door Cable (2) PC-000108 - Rivet (3) PC-000105 - Rivet (to door) (1) PC-000104 - Rivet (to jamb) **SA1-0017 U-Type Handle (1) PC-000168 - Washer (2) PC-100796 Rubber Grommet (1) PC-000106 - Washer **SG1-0030 - Slide Latch **PC-000223 - Handle...
  • Page 4 Optional Recirculating Flush System - Exploded View FS3-0022P PC-100372B Nozzle PC-100611 Shaft Bowl/Lid Pewter (2) PC-000102 Rivet (2) PC-000106 Washer **NOT SHOWN PC-000786 Decal - Flush Tank (2) PC-000235 Shoulder Bolt PC-000591 Pump Handle CH100-014 PC-000593 Cotter Pin Hose 1” x 14” FT02-0011 Prop Rod PC-000597 PC-000232 Screw...
  • Page 5: General Overview

    GENERAL OVERVIEW • Please follow directions in the sequence they are presented. It is suggested you read through the entire assembly instructions prior to proceeding. • Proper handling is required, especially structures that have fl at fl oors with minimal foundations. Dropping this unit during transport and site set-up may cause structural damage or misalignment of the front assembly and door.
  • Page 6 Step 2. Front Sub-Assembly to the Base Surrounds Lift the front sub-assembly and place the legs of the aluminum door jamb into the “pockets” of the base surround on each side of the door opening. Place on 1/4” shims to make level with the wall and corner molding sub-assembly. At- tach the front sub-assembly to the front corner moldings by riveting into the pre-drilled holes using (9) PC-000100 rivets and (9) PC-000106 back-up wash- ers as in Step 1.
  • Page 7 Step 3. Attaching the Wall Panels and Corner Moldings to the Base Surround NOTE: (There are pre-drilled holes along the bot- tom edge of the wall panels. There are no holes in the bottom edge of the corner moldings. You will need to make drill holes in the corner mold- ings, one on each side of the rib making them even with the holes that are in the wall panels.) Start...
  • Page 8 Step 5. Waste Tank Installation On the outside of the unit someone will measure and mark drill spots. For the rear wall panel measure from the inside edge of the rib in 11” and up from the top of the base surround 17-1/2” and mark with a marker.
  • Page 9 Step 7. Mounting the Grab Bars To mount the grab bars, pry back the two round snap lock fl anges on each grab bar with a screwdriver. Align the three- hole pattern on both fl anges of the grab bars to the holes on the support rails and rivet in place using (18) PC-000102 rivets and (18) PC-000106 back-up washers.
  • Page 10 Step 10. Slide Latch and Cover Plate Place the slide latch in the cut-out recess of the door with the “OPEN/IN USE” decal facing the outside of the door. Place the slide latch cover plate over the slide latch. IMPORTANT: RIVET THE SLIDE LATCH AND COVER PLATE INTO PLACE WITH (4) PC-000105 RIVETS WITH (4) PC-000106 BACK-UP WASHERS ON THE ENDS OF THE RIVET IN BE- TWEEN THE COVER PLATE AND DOOR.
  • Page 11 Toilet Seat Installation Step 13. Place the toilet seat on the top of the tank. Line up the holes in the hinge of the seat with the holes in the top of the tank. Insert the seat bolts through the seat hinge and through the tank. Lift open the seat, thread the plastic seat nuts on the ends of the bolts and tighten.
  • Page 12: Cleaning And Maintenance

    International. Contact your area sales representative for further details. OUR MISSION STATEMENT “PolyJohn is a family owned, state of the art, plastics manufacturing company dedicated to providing its employees with a work environment committed to excellence, and its customers with innovative products, services and technol- ogy that meet or exceed their requirements.
