Elived YD1003-A Installation Instructions

YD1003-A
INSTALLATION INSTRUCTION
Bubble Level ×1
26"~55" Max:
88LBS
(40KG)
If you have any questions, please contact us.
Step 1-1 Select TV screw diameter
Thread screws by hand into the threaded holes on the back of your TV to select which screw
diameter fits your TV.
M4 M6 M8
Step 1-2 Select TV screw length
When attaching brackets to the flat screen, be careful not to over tighten screws and
be sure that screws do not bottom out in the mounting holes.
Too Long
Too Short
Step 2 Mesure your TV pattern
Measure and note the width and the height
of the square or rectangle formed from the
VESA holes pattern .
100mm ≈ 4in.
130mm≈ 5 1/8in.
200mm ≈ 8in.
300mm ≈ 11 3/4in
340mm ≈ 13 3/4in.
400mm≈ 16in.
Please read this instruction carefully before installation.
If you do not understand these instructions or have doubts about the safety of the installation, assembly
or use of this product, please contact us.
● This product is designed for use in wood stud and solid concrete wall.
- DO NOT install into drywall alone.
● The wall must be capable of supporting five times the weight of the TV and mount combined.
● Do not apply this product to any purpose not indicated by ELIVED.
● Incorrect installation may result in product damage or body inj
for any damage or injury resulted from incorrect installation, incorrect assembly or misuse.
WARNING:
Before starting assembly, verify all parts are included and undamaged. For parts shortage or damage,
please contact us.
Must Check Before Getting Started
MAX:400mm/16"
MAX:
400mm/16"
Installation Tools (Not Included)
Wood Stud Installation
Max:400x400mm/16x16"
Min:75x75mm /3x3"
(5.5mm)
(V5.1)
Stud Awl Wood
Finder Drill Bit
Step 3-1 Select monitor plate configuration
Select the configuration A , B , C, D, or E to use based on the measurement from STEP
VESA Pattern
(WxH)
100mm x 100mm
130mm x 130mm
200mm x 100mm
200mm x 200mm
200mm x 300mm
200mm x 400mm
200 mm
Correct
Correct
B
for VESA hole
pattern:
200x300mm,
W 200x400mm
H
2M 2M
3
4
Safety Caution
ury. ELIVED shall bear no responsibility
This product contains small items that could be a choking hazard if swallowed.
<16mm(5/8") Min. Wood Stud Size:
nominal 4"(102mm)
actual 3 1/2"(89mm)
Min. Wood Stud Size:
nominal 2"(51mm)
Max:
actual 1 1/2"(38mm)
88LBS
(40KG)
Drywall with wood studs
CAUTION: DO NOT install into drywall alone.
Concrete Installation
2M
7/32" 3/8"
(10mm)
Band Pencil Electrodrill
Masonry Hammer Tape
Drill Bit
VESA Pattern
Configuration Configuration
(WxH)
A 300mm x 200mm C
A 300mm x 300mm E
A 400mm x 200mm C
A 400mm x 300mm D
B 400mm x 400mm E
B
for VESA hole pattern:
100x100mm, 130x130mm,200x100mm, 200x200mm.
400 mm
300 mm
C
for VESA hole pattern:
400x200mm, 300x200mm
400 mm
300 mm
400 mm
D E
for VESA hole
for VESA hole pattern:
pattern:
300x300mm, 400x400mm
400x300mm,
Hardware Included
Wall Plate
x1
01
Nuts Bolts
Min. 8"
(203mm)
4A 4B
x8 x8
Solid concrete wall
TV Screws / Washers
Philips Screws Philips Screws
M4 x 12mm M6 x 15mm
M4 x 30mm M6 x 30mm
1/2"
x4 x4
(13mm)
x4 x4
Socket Screwdriver
M-A M-B
Wrench
1
Step 3-2 Assemble monitor plate and extenders
2.
If your TV hole pattern is greater than 200x200mm, attach extenders [3A] and [3B] to monitor
200 mm
plate [02] using Nut [4A] and Bolt [4B].
02 4A
130 mm
100 mm
3B
A
Step 3-3 Attach the brackets
(a) For Flat Back
M-C
M-A
M-B
Use the shorter screws
No!
M-E
Not for M8 screws
(b) For Round Back / Extra Space
M-C
M-A
M-B
Use the shorter screws
M-E
Not for M8 screws
No!
M-D M-F
4
Monitor Plate Extenders
3A 3B
x2 x2
x1
02
Hardware
(Wall /Product)
Washers Open-end wrench
Lag Bolts
Ø8mm
5/16 x 2½ in
x3 x3
x1
A B C
Philips Screws Spacers Washers Spacers
M8 x 25mm Ø6mm L5mm
M8 x 45mm M4-5-6
L10mm
x4 x8 x4 x8
x4
M-C M-D M-E M-F
3A 3B
4B
3A
C
4A
3B
3A
4B
2
5
