Motic SwiftLine M18 Series
Compound Microscope
Use and Care Manual
\
MOTIC SWIFTLINE
Enduring Quality and Technical Excellence

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SwiftLine M18 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Motic SwiftLine M18 Series

  • Page 1 Motic SwiftLine M18 Series Compound Microscope Use and Care Manual MOTIC SWIFTLINE Enduring Quality and Technical Excellence...
  • Page 2 MOTIC SWIFTLINE M18 Your M18 microscope is an instrument of precision, both optically and mechanically and will last a lifetime with a minimum amount of maintenance. It is built to the highest and most rigid optical and mechanical standards and has many built-in features to insure durability and high performance in the hands of both student and professional users.
  • Page 4: Components Of The Microscope

    COMPONENTS OF THE MICROSCOPE ARM – the vertical column (attached to the base) which supports the stage and contains the coarse and fine adjusting knobs and mechanism. BASE – the housing and platform of the instrument to which the arm is attached.
  • Page 5: Important Terminology

    ILLUMINATION – the built-in Koehler light source which provides the optical system with light. The M18 Series uses a variable intensity 3W LED. IRIS DIAPHRAGM – a multi-leaf round shaped device which is controlled by a lever. It is similar to a camera shutter and is installed under the condenser.
  • Page 6 majority of specimens should be protected by a cover glass, and must be covered when using 40XRD or 100XRD objectives. DEPTH OF FOCUS – the ability of a lens to furnish a distinct image above and below the focal plane. Depth of focus decreases with the increase of numerical aperture or with the increase of magnification.
  • Page 7 USING THE MOTIC SWIFTLINE M18 MICROSCOPE Once you have learned the terminology and purpose of each component of the microscope, use of the microscope is simple. By following these steps, you will be able to begin studying the specimen quickly and easily.
  • Page 8: Centering The Condenser

    8. For additional clarity, use the left eye diopter adjustment to correct the differences between the user’s eyes. Set the adjustable left eye diopter at zero. Then focus with the coaxial focusing knob, using your right eye only (close your left eye). Now using your left eye only, adjust the diopter ring until a clear image is seen (close your right eye).
  • Page 9: Oil Immersion

    OIL IMMERSION It is desirable to use immersion oil with the 100XRD objective. Oil generates a fine resolution and brightness of the image viewed through the microscope. Drop a tiny amount of oil (1 drop) onto the slide prior to focusing with the 100XRD objective (between the slide and the objective tip).
  • Page 10 Please note: Purchase of C-Mount Lens is necessary for camera attachment* Moticam C-Ring MA15602 C-Mount Locking Screw *C-Mount: Swift Part Number MA15602...
  • Page 11 CAUTION – Never disassemble electrical, mechanical or optical components. This servicing should only be done by an authorized Motic SwiftLine technician. The Limited Lifetime Warranty will be null and void if disassembled by a non-Motic SwiftLine dealer.
  • Page 12: Cleaning Your Microscope

    Never attempt to dismantle any parts other than the ones described below. If you notice any malfunction, contact your nearest Motic SwiftLine supplier. Optics Keeping the optics of your microscope clean is essential for obtaining clear images.
  • Page 13 Once the cleaning process is finalized if the image is still not clear, you can either contact us or you can contact your Motic SwiftLine supplier. For users that have a digital camera mounted on the...
  • Page 14 If the dirt persist you can either contact us or you can contact your Motic SwiftLine Optical supplier. Mechanics The mechanical components of the microscope require less maintenance than the optical components.
  • Page 15: Led Replacement

    LED REPLACEMENT The Motic Swift Line M18 series is equipped with a 3W LED illumination system. The life of the LED may vary depending on use and intensity. To prolong the life of the LED, you should always turn off the unit when not in use.
  • Page 16 MOTIC SWIFTLINE LIMITED LIFETIME WARRANTY Please see our website, www.swiftoptical.com, for complete warranty details and exclusions. MOTIC SWIFTLINE.● (877) 967-9438 ● www.swiftoptical.com...
