Sola Hevi Duty S3K2U User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S3K2U UPS
U
M
SER
ANUAL
Line-Interactive
1000 - 3000VA
230V
Version française, : reportez-vous www.solaheviduty.com/products/ups/UPSmanuals.htm.
Para español, consulte www.solaheviduty.com/products/ups/UPSmanuals.htm.
Die deutsche Fassung finden Sie auf www.solaheviduty.com/products/ups/UPSmanuals.htm.
Per l'Italiano, consultare www.solaheviduty.com/products/ups/UPSmanuals.htm.
Downloaded from
Elcodis.com
electronic components distributor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S3K2U and is the answer not in the manual?

Questions and answers

Related Manuals for Sola Hevi Duty S3K2U

Summary of Contents for Sola Hevi Duty S3K2U

  • Page 1 S3K2U UPS ANUAL Line-Interactive 1000 - 3000VA 230V Version française, : reportez-vous www.solaheviduty.com/products/ups/UPSmanuals.htm. Para español, consulte www.solaheviduty.com/products/ups/UPSmanuals.htm. Die deutsche Fassung finden Sie auf www.solaheviduty.com/products/ups/UPSmanuals.htm. Per l'Italiano, consultare www.solaheviduty.com/products/ups/UPSmanuals.htm. Downloaded from Elcodis.com electronic components distributor...
  • Page 2 Downloaded from Elcodis.com electronic components distributor...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS ..........1 MPORTANT AFETY NSTRUCTIONS...
  • Page 4 ............23 OMMUNICATIONS DB-9 Connector .
  • Page 5 Line diagram of S3K2U 1000VA & 1440VA ........
  • Page 6 Downloaded from Elcodis.com electronic components distributor...

  • Page 7: Important Safety Instructions

    MPORTANT AFETY NSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important safety instructions that should be followed during the installation and maintenance of the UPS and batteries. Please read this manual thoroughly before attempting to install or operate this UPS. WARNING SAFETY PRECAUTIONS To prevent the risk of fire or electric shock, install the UPS in a temperature and humidity controlled room, free of conductive contaminants, moisture, flammable liquids, gases and...
  • Page 8 Sola/Hevi-Duty representative or the Sola/Hevi-Duty Technical Services. The S3K2U 1000 VA, and 1440 VA models are not supplied with an input power cable for connection to the mains supply socket. Use the input mains supply power cable from your data processing equip- ment to connect the UPS to the mains supply.

  • Page 9: Wichtige Sicherheitsanweisungen

    ICHTIGE ICHERHEITSANWEISUNGEN DIESE ANWEISUNGEN AUFBEWAHREN Dieses Handbuch enthält wichtige Sicherheitsanweisungen, die während der Installation und Wartung der USV und Batterien befolgt werden sollten. Lesen Sie dieses Handbuch bitte gründlich durch, bevor Sie versuchen, diese USV zu installieren oder in Betrieb zu nehmen . ACHTUNG SICHERHEITSVORKEHRUNGEN Um die Gefahr eines Brandes bzw.
  • Page 10 Ihren örtlichen Händler, den Sola/Hevi-Duty-Vertreter oder weltweiten Kundendienst von Sola/Hevi-Duty. Die S3K2U-Modelle 1000 VA und 1440 VA sind nicht mit einem Eingangsstromkabel zum Anschluss an das Hauptnetz ausgestattet. Verwenden Sie das Netzversorgungskabel von Ihrem Datenverarbei- tungsgerät für den Anschluss der USV an die Netzversorgung.
  • Page 11 • Beim Umgang mit Batterien, beim Transport und Recycling müssen die örtlichen Vorschriften eingehalten werden. Elektromagnetische Verträglichkeit - Die S3K2U-Serie entspricht den Erfordernissen der EMC- Richtlinie 89/336/EEC und den veröffentlichten technischen Normen. Eine kontinuierliche Einhal- tung der Richtlinien erfordert die Installation gemäß dieser Anweisungen sowie die Verwendung von ausdrücklich von Sola/Hevi-Duty genehmigtem Zubehör.

  • Page 12: Glossary Of Symbols

    Glossary of Symbols LOSSARY OF YMBOLS Risk of electrical shock Gefahr eines Stromschlags Indicates caution followed by important instructions Zeigt einen Vorsichtshinweis an, auf den wichtige Anweisungen folgen Requests the user to consult the manual Fordert den Benutzer dazu auf, das Handbuch zu konsultieren Indicates the unit contains a valve-regulated lead acid battery Gibt an, dass das Gerät über eine Bleisäurebatterie mit Ventilregelung verfügt...

  • Page 13: Introduction

    The S3K2U comes in nominal power ratings of 1000, 1440, 2200, or 3000 VA. Refer to 12.0 - Specifi- cations (Sechnische Daten) for details. The S3K2U is a 2U, line-interactive UPS that may be installed in a rack or used in a tower configura- tion. A line-interactive UPS continuously conditions and regulates its output voltage, whether mains power is present or not.

  • Page 14: Figure 2 1000 And 1440Va Models-Rear View

    Introduction Figure 2 1000 and 1440VA models—rear view Data Line Output Circuit Breaker Intellislot Port Receptacles Connectors REPO INPUT BREAKER PUSH TO RESET LOAD 1 BATTERY PHONE / FAX / MODEM / NETWORK CONNECTOR PROTECTION 1440VA/DC 48V/30A 1000VA/DC 48V/20A INPUT LOAD 2 INTELLISLOT AC Input...

  • Page 15: Major Components

    Major Components AJOR OMPONENTS Figure 4 Line diagram of S3K2U 1000VA & 1440VA Input Output EMI/RFI Relay Filter Transformer Charger Battery Inverter Figure 5 Line diagram of S3K2U 2200VA & 3000VA Input Output EMI/RFI Relay Filter Transformer DC-to-DC Bi-Directional Charger...

  • Page 16: Automatic Voltage Regulator

    - even if the UPS is turned Off. Battery The S3K2U utilizes valve-regulated, nonspillable, lead acid batteries. To maintain battery design life, operate the UPS in an ambient temperature of 20°C to 25°C (68°F to 77°F). Optional external battery cabinets are available to extend battery run times.

  • Page 17: What S Included

    What’s Included ’ NCLUDED The S3K2U unit is shipped with the following items: • S3K2U user manual • Warranty Card • MultiLink serial cable (black), 3m (10 ft) • Contact Closure Cable (gray), 3m (10 ft) • USB cable, 1.8m (6 ft) •...

  • Page 18: Installation

    UPS operation in temperatures above 25°C (77°F) reduces battery life. 3. The S3K2U may be installed in either a tower configuration or in a rack, depending on available space and use considerations. Determine the type of installation and follow the appropriate instructions in either Tower UPS Installation or Rack-Mount UPS Conversion and Installation.

  • Page 19: Figure 7 Rack Mount Handles

    Installation Figure 7 Rack mount handles Two (2) M4x6 Flat Head Screws Two (2) M4x6 Flat Head Screws M4x6 Flat Screw Rack Mount Handles 2. Unpack the two fixed rail assemblies and mounting hardware. Loosen the wing nuts and extend the inner members to their outermost position (see Figure 8).

  • Page 20: Figure 9 Rack Mounting Rails And Slide Assemblies

    10. Use the extra M5 screws provided, secure front of the UPS to rack mounting rails to prevent the UPS from sliding out of position. 11. S3K2U 230 VAC models are not supplied with an input power lead for connection to the mains supply. Additional input/output cords may be obtained from your dealer. The input power cord must have a minimal cross-sectional area of 1mm 12.
  • Page 21 Serial communication via the RS232 is disabled. The USB, Intellislot, and Contact Closure communications operate in parallel. 17. REPO Switch—The S3K2U is equipped with a Remote Emergency Power Off (REPO) switch. The user must supply a means of interfacing with the REPO circuit to allow disconnecting the UPS input feeder breaker to remove all sources of power to the UPS and connected equipment to comply with national and local wiring codes and regulations.

  • Page 22: Figure 10 Repo Switch Connections

    Installation Figure 10 REPO switch connections REPO Connector REPO Switch REPO connections REPO connections as shipped for normally open for normally closed switch system switch system (fail-safe) 1 2 3 4 1 2 3 4 1 2 3 4 Key to REPO switch connections 1.

  • Page 23: External Battery Cabinet Installation

    Installation External Battery Cabinet Installation Optional Sola/Hevi-Duty external battery cabinets may be connected to the UPS to provide additional battery run time. External battery cabinets are designed to be placed all on one side of the UPS or stacked beneath the UPS. The run time is limited to a maximum of four (4) hours. CAUTION The external battery cabinet(s) are heavy (see 12.0 - Specifications (Sechnische Daten)).

  • Page 24: Controls And Indicators

    Controls and Indicators ONTROLS AND NDICATORS All indicators illuminated for illustrative purposes only. ON/Alarm Silence/Battery Test Button This button controls output power to connected load(s) and has three functions: •On •Alarm Silence •Battery Test ON—When the UPS is Off, pressing the ON/Alarm Silence/Battery Test button for more than one (1) second will start the UPS, and an audible alarm sounds briefly.

  • Page 25: Voltage Programming Button

    The Battery Level Indicators are displayed in 20% increments as shown in Figure 12: Figure 12 Battery level indicators—5 green The S3K2U is equipped with automatic and remote battery test features. The automatic test occurs every 14 days if mains has not been interrupted; this option may be configured by the user. Should the battery fail this test, the amber Battery Indicator will be illuminated and an alarm will sound (see 11.0 - Troubleshooting for details).

  • Page 26: Over Temp Indicator-Amber

    Controls and Indicators Over Temp Indicator—Amber The Over Temp Indicator flashes when the UPS detects an over temperature condition. This indicator illuminates when the UPS shuts down due to an over temperature condition (see 11.0 - Trouble- shooting for details). 6.10 Fault Indicator—Red The Fault Indicator illuminates when the UPS detects an internal problem (see 11.0 - Trou-...

  • Page 27: Modes Of Operation

    Mains power present ..and within operational limits The S3K2U continuously monitors the batteries to maintain them in a fully charged state. The bat- tery charger operates whenever AC power is present, even if the UPS is switched Off. By default, the UPS is set to perform an automatic battery test after it has been operating continuously for two (2) weeks.

  • Page 28: Battery Recharge Operation

    Modes of Operation When the UPS is in Battery mode, the Battery Indicator illuminates green and an alarm sounds every 10 seconds. As capacity decreases, fewer indicators remain illuminated. Figure 15 shows the UPS in Battery mode with 61% - 80% battery capacity remaining. Figure 15 Battery mode at 61 –...

  • Page 29: Communications

    Open Emitter Remote Shutdown Via the DB-9 Connector The S3K2U can be shut down remotely by shorting Pins 5 and 6 or via Pins 4 and 5 of the DB-9 connector. 8.2.1 Any Mode Shutdown—Via Pins 5 & 6 When Pin 6 is shorted to Pin 5, the UPS output is shut Off regardless of what mode the UPS is oper- ating in.

  • Page 30: Usb Interface Port

    Web site (www.solaheviduty.com) or contact your local distributor, Sola/Hevi-Duty represenative or Sola/Hevi-Duty Technical Services. Several option cards are available for use in the Intellislot port of the S3K2U. The Intellislot SNMP- WEBCARD provides SNMP and Web-based monitoring and control of the UPS across the network.

  • Page 31: Voltage Programming Procedure

    Voltage Programming Procedure OLTAGE ROGRAMMING ROCEDURE Figure 17 Load Level Indicators Load Level Indicators Voltage Programming Button 1. Remove the front bezel from the UPS. 2. UPS must be operating in Normal (AC) mode. NOTE Mains power will be applied to the connected load. 3.

  • Page 32: Maintenance

    When storing the UPS, it is recommended to plug in the UPS for at least 24 hours every four to six months to ensure full recharge of the batteries. The S3K2U is designed to allow the user to replace the internal batteries safely. Read the safety cau- tions before proceeding. Contact your local distributor, Sola/Hevi-Duty representative or Sola/Hevi- Duty Technical Services to obtain the appropriate replacement battery kit part number and pricing.
  • Page 33 Maintenance VORSICHT Bei einer Batterie ist das Risiko eines Stromschlags und eines starken Kurzschlussstroms gegeben. Folgende Vorsichtsmaßnahmen sollten beim Austausch der Batterien beachtet werden: • Armbanduhren, Ringe und sonstige Metallobjekte sind zu entfernen. • Verwenden Sie einen Kreuzschlitzschraubendreher mit isoliertem Griff. •...

  • Page 34: 10.3.1 Internal Battery Replacement Procedure

    Maintenance 10.3.1 Internal Battery Replacement Procedure (Verfahren zum Austausch von internen Batterien) 1. Gently remove the front plastic bezel cover from the UPS. (Demontieren Sie die vordere Kunststoffblendenabdeckung vorsichtig von der USV.) 2. Loosen and remove the five (5) screws on the front cover plate. Lay the cover plate aside for reassembly.

  • Page 35: Troubleshooting

    11.0 T ROUBLESHOOTING The information below indicates various symptoms a user may encounter in the event the S3K2U experiences a problem. Use this information to determine whether external factors caused the prob- lem. See Table 3 - Troubleshooting chart for suggested remedy.

  • Page 36: Table 3 Troubleshooting Chart

    Troubleshooting If the UPS fails to operate properly, turn Off the unit and repeat the steps in 5.0 - Installation. If the problem persists, refer to Table 3: Table 3 Troubleshooting chart Problem Cause Solution UPS will not start Short circuit Check the circuit protector on the rear of the UPS.

  • Page 37: Specifications (Sechnische Daten )

    Specifications (Sechnische Daten) 12.0 S PECIFICATIONS ECHNISCHE ATEN Table 4 UPS specifications Model Number S3K2U1000-5 S3K2U1440-5 S3K2U2200-5 S3K2U3000-5 Power Rating, VA/W 1000VA/750W 1440VA/1080W 2200VA/1650W 3000VA/2250W Dimensions, W x D x H, mm (in) Unit 87 x 557 x 430 87 x 557 x 430 87 x 612 x 430 87 x 612 x 430 (3.43 x 22 x 17)

  • Page 38: Table 4 Ups Specifications

    Specifications (Sechnische Daten) Table 4 UPS specifications (continued) Model Number S3K2U1000-5 S3K2U1440-5 S3K2U2200-5 S3K2U3000-5 Agency Safety EN 62040-1-1; TUV/GS listed; CE compliance mark Surge EN61000-4-5, Level 3, Criteria B EN61000-4-2, Level 3, Criteria B Susceptibility EN61000-4-3, Level 3, Criteria A Electrical Fast Transient EN61000-4-4, Level 4, Criteria A Emissions...

  • Page 39: Table 6 Battery Run Times

    Specifications (Sechnische Daten) Table 6 Battery run times Load% 1000VA 1440VA 2200VA 3000VA Internal Battery (minutes) 100% Internal Battery + 1 External Battery Cabinet (minutes) 100% Internal 1001 — — Battery + 2 External Battery Cabinet (minutes) 100% Downloaded from Elcodis.com electronic components distributor...
  • Page 40 Specifications (Sechnische Daten) Table 6 Battery run times Load% 1000VA 1440VA 2200VA 3000VA Internal 1174 1001 — — Battery + 3 1001 — External Battery Cabinet (minutes) 100% Internal — 1174 — — Battery + 4 1174 — — External Battery Cabinet (minutes)
  • Page 41 Specifications (Sechnische Daten) Table 7 Technische Daten zur USV (continued) Modellnummer S3K2U1000-5 S3K2U1440-5 S3K2U2200-5 S3K2U3000-5 Ausgangsbuchsen (8) IEC-320-C13 (8) IEC-320-C13 (8) IEC-320-C13 (8) IEC-320-C13 (1) IEC-320-C19 (1) IEC-320-C19 Spannung 220/230/240 V AC (konfigurierbar) ±10 % (Normalmodus) Spannung 220/230/240 V AC (konfigurierbar); (Batteriemodus) ±5 % vor der Warnung "Batterie schwach";...

  • Page 42: Table 7 Technische Daten Zur Usv

    Specifications (Sechnische Daten) Table 7 Technische Daten zur USV (continued) Modellnummer S3K2U1000-5 S3K2U1440-5 S3K2U2200-5 S3K2U3000-5 Behörden Sicherheit EN 62040-1-1; TÜV/GS-Liste; CE-Konformitätsmarkierung Überspannung EN61000-4-5, Level 3, Kriterium B EN61000-4-2, Level 3, Kriterium B Störempfindlichkeit EN61000-4-3, Level 3, Kriterium A Schnelle Transienten EN61000-4-4, Level 4, Kriterium A Emissionen EN 50091-2, Klasse B...

  • Page 43: Product Warranty Registration

    Specifications (Sechnische Daten) 12.1 Product Warranty Registration To register for warranty protection: Technical Support • Visit the section of our Web site at: http://www.solaheviduty.com/support/index.htm • Click on the Warranty link and fill in the form. This will register your product with Sola/Hevi- Duty.
  • Page 44 Specifications (Sechnische Daten) Downloaded from Elcodis.com electronic components distributor...
  • Page 45 Downloaded from Elcodis.com electronic components distributor...
  • Page 46 Technical Support U.S.A......(800) 377-4384 International ....(847) 268-6000 www.solaheviduty.com While every precaution has been taken to ensure accuracy and completeness in this manual, Sola/Hevi-Duty assumes no responsibility,...
