Sola Hevi Duty S2K User Manual

Line-interactive ups
Hide thumbs
Table of Contents

Advertisement

Quick Links

S2K UPS
U
M
SER
ANUAL
Line-Interactive
350-1000 VA
230V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S2K and is the answer not in the manual?

Questions and answers

Related Manuals for Sola Hevi Duty S2K

Summary of Contents for Sola Hevi Duty S2K

  • Page 1 S2K UPS ANUAL Line-Interactive 350-1000 VA 230V...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS ..... 1 MPORTANT AFETY NSTRUCTIONS & S ....5 NTRODUCTION YSTEM ESCRIPTION...
  • Page 4 ........19 AINTENANCE Cleaning the UPS........19 Maintaining Batteries .

  • Page 5: Important Safety Instructions

    MPORTANT AFETY NSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important safety instructions that should be fol- lowed during the installation and maintenance of the Uninterruptible Power System (UPS) and its batteries. Please read this manual thor- oughly before attempting to install or operate this UPS. Read all safety, installation, and operating instructions before operat- ing the UPS.
  • Page 6 WARNING ELECTRICAL PRECAUTIONS • This UPS should not be supplied from electrical power sys- tems of the “IT” (Impedance á Terre) type (IEC 364 - Elec- trical Installation of Buildings). • The UPS must be earthed/grounded at all times during operation.
  • Page 7 CAUTION BATTERY HANDLING PRECAUTIONS Servicing of batteries should be performed or supervised by personnel knowledgeable of batteries and required precautions. Keep unauthorized personnel away from the batteries. A battery can present a risk of electrical shock and high short-circuit current. The following precautions should be observed when working on batteries: •...
  • Page 8 Electromagnetic Compatibility—The Sola S2K series complies with the requirements of the EMC Directive 89/336/EEC and the pub- lished technical standards. Continued compliance requires installa- tion in accordance with these instructions and use of Sola/Hevi-Duty approved accessories only. Environmental—Operate the UPS in an indoor environment only in an ambient temperature range of 0°C to 40°C (32°F to 104°F).

  • Page 9: Introduction & System Description

    (4) sizes: 350, 500, 650 and 1000VA at 120 VAC and 230 VAC. Sola S2K models are available for 120 VAC and 230 VAC supply volt- ages and loads. Please verify that this model matches your AC Mains...

  • Page 10: Front View Of Ups

    Front View of UPS Power ON/OFF/ Alarm Silence* Mains Indicator* (Green/Amber) Fault Indicator* (Red/Green) Battery Indicator* (Green/Amber) * For details, see Controls and Indicators section...

  • Page 11: Rear View Of Ups

    Rear View of UPS 350&500VA Models switches** port*** Data Line Protection Connectors (2)*** DB-9 Phone/Fax/DSL/Internet/ port*** Modem devices Black output receptacles (2)* Orange output Surge protection receptacles* only Battery backup + surge protection Input circuit protector input Battery cover plate (on rear of 350 &...

  • Page 12: Major Components

    Battery The S2K unit utilizes valve-regulated, nonspillable, lead acid batter- ies. To optimize battery life, operate the UPS in an ambient tempera- ture of 20°-25°C (68°-77°F).

  • Page 13: What ' S Included

    ’ NCLUDED The S2K unit is shipped with the following items: • Sola S2K user manual • MultiLink™ software CD • MultiLink serial cable, 3.0m (10 ft.) • USB cable, 1.8m (6 ft.) • RJ-11 cord, 2.1m (7 ft.) • Two (2) 10A output power cords, 2.0m (6.6 ft.)

  • Page 14: Installation

    Sola/Hevi-Duty representative, or Sola/Hevi-Duty Technical Services. 2. Decide where to place the S2K unit. Find a location that is near an easily accessible mains outlet. Install the UPS indoors in a con- trolled environment, where it cannot be accidentally turned off.
  • Page 15 Option 3—USB Communications a. Connect USB cable provided with the UPS to the USB ports on the S2K and your computer. The S2K will work automatically with your built-in power management software on Windows XP and 2000 and Mac OS 10.2 or later (see USB Interface Port section for details).

  • Page 16: Ontrols And Ndicators

    ONTROLS AND NDICATORS ON/OFF/Alarm Silence Button This button controls output power to the connected load and has three functions: • ON • OFF • Alarm Silence ON/OFF/Alarm Silence When the UPS is off, pressing and releasing the main ON/ OFF button will start the UPS, and an audible alarm sounds briefly.

  • Page 17: Status Indicators: Mains, Battery, Fault

    Status Indicators: Mains, Battery, Fault There are three (3) status indicators on the front of the UPS (Mains, Battery and Fault), as shown in the diagram below. Each indicator illuminates to specify the status of the UPS (see Troubleshooting section for details). Mains Indicator (Green/Amber) The Mains Indicator illuminates when the UPS is operating and sup- plying power to connected loads: green indicates Normal mode, amber...

  • Page 18: Transfer Voltage Selectors (Dip Switches)

    Transfer Voltage Selectors (DIP Switches) DIP Switches Rear of UPS The two-position DIP switch control on the rear panel, shown above, allows the operator to select the mains transfer voltage at which the UPS will switch to battery power. DIP switch positions for each volt- age setting are as follows: DIP switch settings Left...

  • Page 19: Modes Of Operation

    When the UPS is in Normal mode, the Mains Indicator illuminates green. Mains Indicator (Green) The S2K unit continuously monitors the batteries to maintain them in a fully charged state. The battery charger operates whenever AC power is present, even if the UPS is switched off. By default, the UPS is set to perform an automatic battery test after it has been operating continuously for two (2) weeks.

  • Page 20: Battery Mode

    Battery Mode The UPS switches to Battery mode in the event of an extreme voltage/ frequency condition or complete mains failure. The battery system supplies power through the Bi-Directional Converter to generate power for connected equipment. When the UPS is in Battery mode, the Battery Indicator illuminates green and an alarm sounds every 10 seconds.

  • Page 21: Communications

    OMMUNICATIONS DB-9 Connector The UPS has a DB-9 (9 pin female) connector on the rear to allow UPS status communications with a computer system running MultiLink™ software. The DB-9 is capable of supplying serial communication, on battery and low battery signals. MultiLink, UPS monitoring and shut- down software, is shipped with the UPS, along with a 3m (10 ft.) DB-9 cable required for running MultiLink.

  • Page 22: Remote Shutdown Via The Db-9 Connector

    Remote Shutdown Via the DB-9 Connector The S2K unit can be shut down remotely by shorting Pins 5 and 6 or via Pins 4 and 5 of the DB-9 connector. Shutdown Via Pins 5 & 6 When Pin 6 is shorted to Pin 5, the UPS output is shut off regardless of what mode the UPS is operating in.

  • Page 23: Maintenance

    AINTENANCE The Sola S2K UPS requires very little maintenance. Follow these practices to prevent problems. Cleaning the UPS The following will help ensure trouble-free operation for years: • Vacuum dust from the ventilation intake occasionally. • Wipe the cover periodically with a dry cloth.

  • Page 24: Battery Replacement Procedure

    Battery Replacement Procedure Replacement requires removing the battery cover plate on the back or bottom of the UPS. No tools are needed. To replace the batteries: 1. Remove the bat- Figure 1 Figure 2 tery cover plate on the back/bot- tom of the UPS (Figure 1).

  • Page 25: Troubleshooting

    ROUBLESHOOTING The information below indicates various symptoms a user may encounter in the event the S2K unit experiences a problem. Use this information to determine whether external factors caused the prob- lem. See Troubleshooting Chart for suggested remedy. 1. The Fault indicator illuminates, indicating the Mains UPS detected a problem.

  • Page 26: Troubleshooting Chart

    Troubleshooting Chart If the UPS fails to operate properly, turn off the unit and repeat the steps in the Installation section of this manual. If the problem per- sists, refer to the chart below: Problem Cause Solution Check the circuit protector on the rear of the UPS.

  • Page 27: Specifications

    PECIFICATIONS Model Number S2K350-5 S2K500-5 S2K650-5 S2K1000-5 Power Rating VA/W 350VA/210W 500VA/300W 650VA/390W 1000VA/600W DIMENSIONS: mm (in.) Unit 116x196x222 116x196x222 116x358x222 116x358x222 WxDxH (4.6x7.7x8.7) (4.6x7.7x8.7) (4.6x14.1x8.7) (4.6x14.1x8.7) Shipping 196x310x293 196x310x293 242x500x316 242x500x316 WxDxH (7.7x12.2x11.5) (7.7x12.2x11.5) (9.5x19.7x12.4) (9.5x19.7x12.4) WEIGHT: kg (lbs) Unit 7.0 (15.4) 7.4 (16.3)

  • Page 28: Battery Run Times

    ENVIRONMENTAL 0°C to +40°C Operating Temperature (+32°F to + 104°F) -15°C to +40°C Storage Temperature (+5°F to + 104°F) Relative Humidity 0% to 95%, non-condensing Operating Elevation Up to 3000m (10,000 ft.) at 35°C (95°F) without derating Audible Noise < 40 dBA, at 1 meter AGENCY Safety EN50091-1-1, CE compliance mark...

  • Page 29: Product Warranty Registration

    Product Warranty Registration To register for warranty protection: • Visit the Technical Support section of our Web site at: http://www.solaheviduty.com/support/index.htm • Click on the Warranty link and fill in the form. This will register your product with Sola/Hevi-Duty. For UPS purchasers: The MultiLink software is available for down- load in the Products section of our Web site under UPS http://www.solaheviduty.com/products/UPS/software/index.htm Contact us at (800) 377-4384 or via e-mail at...

  • Page 32: Technical Support

    Technical Support U.S.A......(800) 377-4384 International ....(847) 268-6000 www.solaheviduty.com While every precaution has been taken to ensure accuracy and completeness in this manual, Sola/Hevi-Duty assumes no responsibility,...
