S1K UPS
Off-Line UPS
320VA - 1500VA (115V)
Instruction Manual
Advertisement
Table of Contents
Related Manuals for Sola Hevi Duty S1K320
Summary of Contents for Sola Hevi Duty S1K320
- Page 1 S1K UPS Technical Services Off-Line UPS 320VA - 1500VA (115V) U.S.A..............(800) 377-4384 International………………………………………(847) 268-6000 www.solaheviduty.com While every precaution has been taken to ensure accuracy and completeness in this manual, Sola/Hevi-Duty assumes no responsibility, and disclaims all liability for damages resulting from use of this information or for any errors or omissions.
- Page 3 Table of Contents Product Registration Important Safety Instructions............2 To register your product for updates and information on service and support: Storage..................3 • Visit the Technical Support section of our Web site at: http://www.solaheviduty.com/support/warranty.htm Introduction & System Description...........4 • Click on the Product Registration link and fill in the form. This will register your product with Sola/Hevi-Duty.
- Page 4 Specifications Important Safety Instructions Save These Instructions MODEL S1K320 S1K520 S1K650 S1K850 S1K1200 S1K1500 Capacity VA/Watts 320/240 520/360 650/390 1000/600 1200/720 1500/900 This manual contains important safety instructions that should be followed during the installation and maintenance of the UPS and batteries. Please read this...
- Page 5 • The UPS will shut down when a high RS-232 level is sustained on Pin 3 for Your UPS provides conditioned power to connected equipment. Maximum load must not 0.36 seconds; this feature is not applicable to the S1K320 and S1K520 units. exceed that shown on UPS rating label. If uncertain, consult your distributor or •...
- Page 6 Introduction & System Description Software and Interface Port (Option) Congratulations on your choice of the Sola Series S1K Uninterruptible Power Power Monitoring Software System (UPS). It provides conditioned power to microcomputers and other The UPSMON series software (or other power monitoring software) is applied sensitive electronic equipment.
- Page 7 Alarms Front Panel (320VA-1200VA and 1500VA) 1. “BACK UP” (slow beeping) 1) “ REPLACE BATTERY “ indicator (RED LED): The LED illuminates when the UPS’s battery is When in BACK UP mode, the YELLOW LED illuminates and the UPS sounds no longer useful and must be replaced.
- Page 8 Rear Panel (1500 VA) Operating Instructions 1) Battery Power Outlets The Battery Power output outlets will provide protection from surges and power failures. Plug your computer, monitor, and other “data critical” devices into 2) Remote Port (option) these outlets. 2) Surge Protected Outlet 3) Phone Jack (option) The outlet can offer protection against surges and transients (typically caused by lightning or disruptive loads in the building).
