THREE-PHASE
HYBRID INVERTER
INSTALLER MANUAL
SUN-25K-SG01HP3-EU-BM2 / SUN-30K-SG01HP3-EU-BM3
SUN-40K-SG01HP3-EU-BM4 / SUN-50K-SG01HP3-EU-BM4
Global Tech China Ltd, 3 Floor, Wai Yip Industrial Building.
171 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong.
Tel: +852 2884 4318 Fax: +8522884 4816
www.sunsynk.com / sales@sunsynk.com
V.8 (12/09/22)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUN-25K-SG01HP3-EU-BM2 and is the answer not in the manual?

Questions and answers

Related Manuals for SunSynk SUN-25K-SG01HP3-EU-BM2

Summary of Contents for SunSynk SUN-25K-SG01HP3-EU-BM2

  • Page 1 THREE-PHASE HYBRID INVERTER INSTALLER MANUAL SUN-25K-SG01HP3-EU-BM2 / SUN-30K-SG01HP3-EU-BM3 SUN-40K-SG01HP3-EU-BM4 / SUN-50K-SG01HP3-EU-BM4 Global Tech China Ltd, 3 Floor, Wai Yip Industrial Building. 171 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong. Tel: +852 2884 4318 Fax: +8522884 4816 www.sunsynk.com / sales@sunsynk.com...
  • Page 2 The manufacturer's warranty does not cover any damage resulting from the neglect of these instructions. Sunsynk assumes no liability for damage caused by the operation contrary to what is specified in this operating manual.

  • Page 3: Table Of Contents

    Table of Contents SAFETY 1.  1.1. General Safety 1.2. Symbols 1.3. Safety Instructions 1.4. Disposal Remarks 2. PRODUCT INTRODUCTION 2.1. System Overview 2.2. Product Size 2.3. Features 2.4. Basic System Architecture 3. TECHNICAL SPECIFICATIONS 4. INSTALLATION 4.1. Parts List 4.2. Selecting the Mounting Area 4.3. Mounting the Inverter 4.4. Function Port Definition 4.5. Battery Connection 4.6. Grid Connection and Backup Load Connection 4.7. PV Connection 4.7.1. PV Module Selection 4.7.2. PV Module Wiring...
  • Page 4 5.1. Display 5.2. Switching ON/OFF 5.3. Home Page 5.4. Status Page 5.5. System Flow Page 5.6. Setup Page 5.7. Set Time (Clock) 5.8. Set Company Name / Beeper / Auto dim 5.9. Factory Reset and Lock Code 5.10. Battery Setup Page 5.11. Generator & Battery Page 5.12. Battery Discharge Page 5.13. Setting Up a Lithium Battery 5.14. Program Charge &...

  • Page 5: Safety

    1. SAFETY 1.1. General Safety This device should only be used in accordance with the instructions within this manual and in compli- ƒ ance with local, regional, and national laws and regulations. Only allow this device to be installed, operat- ed, maintained, and repaired by other person(s) who have read and understood this manual. Ensure the manual is included with this device should it be passed to a third party.

  • Page 6: Safety Instructions

    1.3. Safety Instructions WARNING HIGH LIFE RISK DUE TO FIRE OR ELECTROCUTION. Sunsynk Three-Phase Hybrid Inverter can only be installed by a qualified licensed electrical contractor. This is not a DIY product. Be sure to read this manual thoroughly before installation.

  • Page 7: Product Introduction

    2. PRODUCT INTRODUCTION The Sunsynk Three-Phase Hybrid Inverter is a highly efficient power management tool that allows the user to hit those ‘parity’ targets by managing power-flow from multiple sources such as solar, mains power (grid) and generators, and then effectively storing and releasing power as and when utilities require.

  • Page 8: Product Size

    2.2. Product Size HYBRID INVERTER | Installer Manual...

  • Page 9: Features

    2.3. Features INTERACTIVE Easy and straightforward to understand LCD display; ƒ Supporting Wi-Fi or GSM monitoring; ƒ Visual power flow screen; ƒ Built-in 2 strings for 1 MPP tracker and 1 string for 1 MPP tracker; ƒ Smart settable 3-stage MPPT charging for optimised battery performance; ƒ...

  • Page 10: Basic System Architecture

    2.4. Basic System Architecture The following diagram explains the basic application and architecture of this 3-Phase Inverter. It also includes the following devices to have a Complete running system. Generator or Utility ƒ PV modules ƒ Batteries ƒ Normal and smart loads ƒ...

  • Page 11: Technical Specifications

    3. TECHNICAL SPECIFICATIONS SUN-25K- SUN-30K- SUN-40K- SUN-50K- Model SG01HP3-EU- SG01HP3-EU- SG01HP3-EU- SG01HP3-EU- Battery Input Date Battery Type Li-Ion Max. Charging Current 50A+50A Max. Discharging Current 50A+50A Number of battery input Charging Strategy for Li-lon Battery Self-adaption to BMS PV String Input Data Max.
  • Page 12 SUN-25K- SUN-30K- SUN-40K- SUN-50K- Model SG01HP3-EU- SG01HP3-EU- SG01HP3-EU- SG01HP3-EU- Protection PV Input Lightning Protection Integrated Anti-islanding Protection Integrated PV String Input Reverse Polarity Integrated Protection Insulation Resistor Detection Integrated Residual Current Monitoring Unit Integrated Output Over Current Protection Integrated Output Shorted Protection Integrated Output Over Voltage Protection DC Type II / AC Type III...

  • Page 13: Installation

    4. INSTALLATION 4.1. Parts List Check the equipment before installation. Please make sure nothing is damaged in the package. You should have received the items in the following package: Stainless steel anti-collision bolt M12x60 Hybrid Inverter Wall Mounting bracket Parallel communication cable L-type Hexagon wrench Meter (optional) Data Logger x1...

  • Page 14: Selecting The Mounting Area

    4.2. Selecting the Mounting Area For proper heat dissipation, allow a clearance of approximately 500mm to the side, 500mm above and below the unit, and 1000mm to the front of the unit. DO NOT install the inverter in the following areas: Areas with high salt content, such as the marine environment.

  • Page 15: Mounting The Inverter

    Wi-Fi or GSM monitoring. If children under 10 years old may approach the unit, take preventive measures so they cannot reach ƒ and touch the unit. Install the indoor unit on the wall where the floor height is higher than 1600mm. ƒ...
  • Page 16 Inverter hanging plate installation HYBRID INVERTER | Installer Manual...

  • Page 17: Function Port Definition

    4.4. Function Port Definition HYBRID INVERTER | Installer Manual...

  • Page 18: Battery Connection

    4.5. Battery Connection For safe operation and compliance, an individual DC overcurrent protector or disconnection device is required to connect the battery and the inverter. Users are recommended to utilise a suitable fuse and DC isolator (see next page). Switching devices may not be required in some applications, but overcurrent pro- tectors must be used.
  • Page 19 3. Crimp terminals: 4. Fasten terminal with a bolt: 5. Fasten the terminal with outer cover: PLEASE NOTE Depending on the battery type, the inverter should be capable of controlling the battery BMS. There- fore, you need to set the protocol of the BMS on both the battery and the inverter. When using more than one battery, the first battery will be the master, and the other batteries will be the slaves.

  • Page 20: Grid Connection And Backup Load Connection

    AC breaker for the grid is 180A. There are three terminal blocks marked as GRID, LOAD, and GEN. Please do not confuse input and output connections. External AC SPD is compulsory on all Sunsynk inverters. CAUTION All wiring must be performed by qualified personnel. System safety and efficient operation need to use appropriate cable for AC input connection.

  • Page 21: Pv Connection

    In addition, we request users install PV junction boxes with surge protection to protect the system from a lightning strike. External AC SPD is compulsory on all Sunsynk inverters. To avoid any malfunction, do not connect any PV modules with possible current leakage to the inverter. For example, grounded PV modules will cause current leakage to the inverter.

  • Page 22: Pv Module Wiring

    Inverter Model 25kW 30kW 40kW 50kW PV Input Voltage 600V (180V~1000V) PV Array MPPT Voltage Range 150-850V No. Of MPP Trackers No. Of Strings per MPP Tracker 2+2+2 2+2+2+2 4.7.2. PV Module Wiring 1. Switch the Grid Supply Main Switch (AC) OFF. 2.
  • Page 23 2. Crimp metal terminals with crimping pliers. 3. Insert the contact pin into the connector housing until it locks into place. Then screw the cap nut onto the connector housing. Torque to 2.5-3 N.m. 4. Finally, insert the DC connector into the positive and negative input of the inverter. PLEASE NOTE When sunlight falls on the solar panel, it will generate a voltage.

  • Page 24: Connecting The Ct Coil

    4.8. Connecting the CT Coil The CT coil is one of the most important parts of the Sunsynk inverter. This device reduces the power of the inverter to prevent feeding power to the grid. This feature is also known as “Zero Export”.

  • Page 25: Meter Connection

    4.9. Meter Connection 4.9.1. System Connection for the CHNT Meter HYBRID INVERTER | Installer Manual...

  • Page 26: System Connection For The Chnt Meter With Ct Coil

    4.9.2. System Connection for the CHNT Meter with CT Coil HYBRID INVERTER | Installer Manual...

  • Page 27: Earth Connection (Mandatory)

    PLEASE NOTE When the inverter is in the off-grid state, the N line needs to be connected to the earth. In the final installation, a breaker certified according to IEC 60947-1 and IEC 60947-2 shall be installed with the equipment. 4.10. Earth Connection (MANDATORY) Ground cable shall be connected to ground plate on grid side this prevents electric shock if the original pro- tective conductor fails.

  • Page 28: Wiring System For Inverter

    4.12. Wiring System for Inverter HYBRID INVERTER | Installer Manual...

  • Page 29: Wiring Diagram

    4.13. Wiring Diagram HYBRID INVERTER | Installer Manual...
  • Page 30 HYBRID INVERTER | Installer Manual...

  • Page 31: Typical Application Diagram Of Diesel Generator

    4.14. Typical Application Diagram of Diesel Generator HYBRID INVERTER | Installer Manual...

  • Page 32: Three Phase Parallel Connection Diagram

    4.15. Three Phase Parallel Connection Diagram HYBRID INVERTER | Installer Manual...

  • Page 33: Operation

    5. OPERATION 5.1. Display LED indicator Meaning Green LED solid light PV connection normal Green LED solid light Grid connection normal Normal Green LED solid light Inverter functioning normally Alarm Red LED solid light Fault Function Key Description To exit the previous mode Increase the value of a setting Down Decrease the value of a setting...

  • Page 34: Home Page

    5.3. Home Page Press the Esc button any page to access the home page: 1. Customer name 2. Access the settings menu page 3. Access solar history 4. Access system status page SOLAR/TURBINE AC load 5. Access system status page 6. Access grid history 7.

  • Page 35: System Flow Page

    What this page displays: Total solar power produced. Inverter voltage. ƒ ƒ MPPT 1 power/voltage/current. Inverter current. ƒ ƒ MPPT 2 power/voltage/current. Load power. ƒ ƒ Grid power. Load voltage. ƒ ƒ Grid frequency. Battery power charge/discharge. ƒ ƒ Grid voltage. Battery SOC.

  • Page 36: Setup Page

    What this page displays: The system flow. Battery status. ƒ ƒ MPPTs power. Power distribution to load or grid. ƒ ƒ 5.6. Setup Page To access Settings, click on the gear icon on the right top of the navigation menu. What this page displays: Serial number.

  • Page 37: Set Time (Clock)

    Access the Grid Setup Page (press the GRID icon). ƒ Access the real-time programmable timer/system mode (press the SYSTEM MODE icon). ƒ Access the advanced settings such as Paralleling and Wind Turbine (press the ADVANCE icon). ƒ Access the auxiliary load/smart load settings (press the AUX LOAD icon) ƒ...

  • Page 38: Factory Reset And Lock Code

    How to change the name: Change the letters in each box by moving the arrows up and down and then select OK. This will change the name on the home screen. SOLAR/TURBINE AC load BATTERY IN/OUT MPPT. GRID. Battery Grid How to set the auto dim: Set a number in the auto dim box to dim the LCD after a number of seconds.

  • Page 39: Battery Setup Page

    System self-check: Allows the user to conduct a system diagnosis. Test mode (only for engineers): For engineers to conduct tests. 5.10. Battery Setup Page To configure battery settings, click on the BATTERY icon and then on ‘Batt type’. What this page displays: Battery capacity in (Ah) –...

  • Page 40: Generator & Battery Page

    BMS setting. ƒ Active battery - This feature will help recover a battery that is 100% discharged by slowly changing from ƒ the solar array. Until the battery reaches a point where it can change normally. 5.11. Generator & Battery Page To configure battery charging settings, click on the BATTERY icon and then on ‘Batt Charge’.
  • Page 41 1Amp 12V. Below is a simple reference circuit of an auto-start system that can autostart generators on a boat. (Sunsynk will be releasing a new OS E406 ( Auto-Start ) for better generator control).

  • Page 42: Battery Discharge Page

    Gen On Lamp 60 Amp Contactor MCB 45A To generator Inverter Grid Relay 1 MCB 5A Relay 2 MCB 5 A Inverter Load To Gen Feed In TriggerN/C Generator Auto Start Override Switch 5.12. Battery Discharge Page To configure inverter’s shutdown settings, click on the BATTERY icon and then on ‘Shut Down’. HYBRID INVERTER | Installer Manual...

  • Page 43: Setting Up A Lithium Battery

    Activating Shutdown causes the inverter to enter standby-mode. It does not entirely shut down the inverter. Total shutdown occurs at voltages below 19V. The voltage displayed on the Sunsynk Parity Inverter will vary depending on whether the inverter is charging or discharging the batteries.
  • Page 44 What this page displays: This information will only display if the ‘Lithium’ option is selected under ‘Batt Type’. ƒ The type of communion protocol. ƒ Approved batteries. ƒ What you can do from this page: Set up you Lithium-ion battery. ƒ...

  • Page 45: Program Charge & Discharge Times

    5.14. Program Charge & Discharge Times To set ‘Charge’ and ‘Discharge’ times, click on the ‘System Mode’ icon after clicking on the gear icon. What this page displays: A setting to prevent the inverter exporting power to the grid - ‘Zero Export’. ƒ...
  • Page 46 50000 50000 50000 50000 50000 50000 50000W Example: This example shows the battery being charged up to 100% by both the Grid and Solar PV from 8 a.m. to 11 a.m. and then being able to supply up to 4kW of battery-power to the ‘essential’ loads from the ‘Load’ Port until the battery SOC drops to 50%.

  • Page 47: Grid Supply Page

    Example: The power produced is supplying the ‘Non-Essential Load’ while the inverter is set at a maximum power of 8kW (Max Sell Power). The inverter is connected to the grid, but no export is performed. The unit allows small amounts of power to flow from the Grid (100W Zero Export Power) to prevent any back-flow. In this example, the solar PV is prioritised to supply the Load first and then subsequently, charge the battery.

  • Page 48: Advanced Settings For Paralleling Inverters

    Set the Modbus SN for paralleling. ƒ The Sunsynk inverter can be wired standalone, or it can be connected in parallel when more power is re- quired. The maximum number of inverters that can be paralleled in a three-phase utility grid is 10. In the case where 10 inverters are operating in parallel, one will operate as the Master and the other ones as Slaves (this is uder development and should be ready first quarter 2023).
  • Page 49 Each phase must only have one Master and the others set to slave. ƒ Each inverter must have a unique Modbus number. ƒ The maximum length of the communication cables is 2 meters (do not exceed this value) ƒ All batteries must be connected in parallel, and the MPPTs must be kept separate. ƒ...
  • Page 50 It can damage the inverter and fault F46 will be indicated on the display. If you need further help please refer to the Sunsynk website where you will find training videos and Fre- quently Asked Questions www.sunsynk.com. Firmware prior installation is important to be updated and all inverters in parallel or three phase system must be the same.

  • Page 51: Solar Power Generated

    5.17. Solar Power Generated This page shows the daily, monthly, yearly, and total solar power produced. Access this page by clicking on the ‘Solar/Turbine’ icon on the Home Page. 5.18. Grid Power This page shows the Daily / Monthly / Yearly and total grid power export or consumed. Access this page by clicking on the ‘Solar/Turbine’...

  • Page 52: Advanced Settings For Auxiliary Load

    5.19. Advanced Settings for Auxiliary Load To configure Auxiliary Load (previously known as “smart load”) settings, click on the AUX LOAD icon. What this page displays: Use of the Gen (Aux) input or output. ƒ What you can do from this page: Set up a generator input.

  • Page 53: Advanced Settings For Peak Shaving

    5.20. Advanced Settings for Peak Shaving To configure Peak Power Shaving function, click on the AUX LOAD icon. What this page displays: Generator peak shaving is ON or OFF. ƒ Peak Power Shaving value. ƒ 50000W What you can do from this page: Switch on the generator and/or grid peak ƒ...

  • Page 54: Fault Codes

    5.21. Fault Codes To check the fault codes click on the FAULT CODES icon on the settings menu. If any of the fault messages listed in the following table appear on your inverter and the fault has not been removed after re-starting, please contact your local vendor or service centre. The following information is required: 1.
  • Page 55 Description Solutions Inverter work mode changed Working Mode Change 1.Reset the inverter. 2.Seek help from Sunsynk. AC Slide over current fault. AC over current fault or 1.Check if the backup load power is within the range of the inverter. hardware 2.Restart, and check if it is normal.
  • Page 56 Before leaving the factory, all inverters undergo rigorous testing to ensure the in- verter can operate reliably, as presented in Chapter 3, ‘Technical Specifications’. If you need further help please refer to the Sunsynk website where you will find training videos and frequent- ly asked questions www.sunsynk.com.

  • Page 57: Operation Modes

    5.22. Operation Modes 5.22.1. MODE I: Basic 5.22.2. MODE II: With Generator HYBRID INVERTER | Installer Manual...

  • Page 58: Mode Iii: With Smart-Load

    5.22.3. MODE III: With Smart-Load 5.22.4. MODE IV: AC Couple HYBRID INVERTER | Installer Manual...

  • Page 59: Commissioning

    6. COMMISSIONING 6.1. Start-Up / Shutdown Procedure The inverter must be installed by a qualified / licensed electrical engineer in accordance with the country's wiring regulations. Before switching on, the installation engineer must have completed the Earth Bond, RCD and earth leakage tests, checked that the solar panel Voc voltage does not exceed 480V and checked the battery voltage.

  • Page 60: Gdfi Fault

    Check each bond on the Check the VOC does not Ensure both MPPTs are solar panels exceed 480V balanced Measure the supply volt- If it falls out of the setting age check it matches the range it will cause the in- See Grid Setup page settings of the inverter verse shut down and alarm...
  • Page 61 APPENDIX A Definition of RJ45 Port Pin for BMS1 RS485 Pin 485_B 485_A GND_485 CAN_H1 CAN_L1 GND_485 485_A 485_B Definition of RJ45 Port Pin for BMS2 RS485 Pin 485_B 485_A GND_485 CAN_H2 CAN_L2 GND_485 485_A 485_B Definition of RJ45 Port Pin for Meter Meter-485 Pin Meter-485_B Meter-485_A...
  • Page 62 Definition of RJ45 Port Pin for RS485 RS485 Pin Modbus-485_B Modbus-485_A GND_485 GND_485 Modbus-485_A Modbus-485_B RS232 WIFI/RS232 D-GND 12Vdc HYBRID INVERTER | Installer Manual...
  • Page 63 ƒ Secondary output cable length is 4m. ƒ For more information, training videos, software upgrades, help line, forum please refer to http://www.sunsynk.com - Tech Support (Do not forget to register first on the website). Sunsynk @energysolutions sunsynkofficial HYBRID INVERTER | Installer Manual...
  • Page 64 wered by...

This manual is also suitable for:

Sun-30k-sg01hp3-eu-bm3Sun-40k-sg01hp3-eu-bm4Sun-50k-sg01hp3-eu-bm4

Table of Contents
