Figure1-1 Removing the access panel
6.
Remove the chassis air baffle. As shown in Figure1-2, press the blue latches in the notches at
two sides of the air baffle against each other, and then lift the air baffle up to remove it from the
chassis.
Figure1-2 Removing the chassis air baffle
2
