M-system R7L-DC16B-R Instruction Manual page 15

One Shot Mode
CONFIGURATION NETWORK
PROPERTY VARIABLE
SCPTtimeout[0] ----
SCPTtimeout[1] ----
SCPTtimeout[2] ----
[Example]
• Providing one-shot output when nviTMRIn is turned on:
SCPTtimeout[0] : One-shot output delay time
SCPTtimeout[1] : Pulse width
SCPTtimeout[2] : 800.1* (Holds nvoTMROut when nviTMRIn is turned off.)
* If SCPTtimeout[2] equals other than 800.1, the pulse width equals the addition of SCPTtimeout[1] and SCPTtimeout[2].
• Turning nvoTMROut on in a specific time period after nviTMRIn is turned on:
SCPTtimeout[0] : ON delay time
SCPTtimeout[1] : 800.1 (Holds nvoTMROut on while nviTMRIn remains on.)
SCPTtimeout[2] : Time to hold nvoTMROut on after nviTMRIn is turned off.
Cyclic Mode
CONFIGURATION NETWORK
PROPERTY VARIABLE
SCPTtimeout[0] ----
SCPTtimeout[1] ----
SCPTtimeout[2] ----
SEN TRONIC
TYPE
{ Range }
{ Default }
{SNVT_time_sec}
{0.0...800.0}
{10.0}
{SNVT_time_sec}
{1.0...800.0,800.1}
{10.0}
{SNVT_time_sec}
{0.0...800.0,800.1}
{10.0}
TYPE
{ Range }
{ Default }
{SNVT_time_sec}
{0.0}
{0.0}
{SNVT_time_sec}
{0.0...800.0}
{0.0}
{SNVT_time_sec}
{0.0}
{0.0}
056 222 38 18 mailbox@sentronic.com
AG
EXPLANATIONS
Delay time before nvoTMROut is turned on after nviTMRIn
has been turned on.
Time to maintain ON status of nvoTMROut after it has
been turned on.
800.1 = Latching (no turning off)
Delay time before nvoTMROut is turned off after nviTM-
RIn has been turned off.
800.1 = Latching (no turning off) (With SCPTtimeout[1]
also set to '800.1,' nvoTMROut remains on. Set 'Invalid' at
nviTMRIn to turn nvoTMROut off.
EXPLANATIONS
Invalid
Defines ON-OFF time period. ON and OFF times are
equal. One pulse cycle equals twice as long as the set
value.
Invalid
www.sentronic.com
R7L-DC16B
EM-7804-H Rev.7 P. 15 / 19
