M-system R7L-DC16B-R Instruction Manual page 14

■ FUNCTIONAL BLOCK: fbTMR[0,1]
nv 128,
nv 129
• Network Variables
TYPE
NETWORK
{ Range }
VARIABLE
{ Default }
{SNVT_switch}
nviTMRIn {0.0 0}, {100.0 1}, {Invalid}
{0.0 0}
{SNVT_switch}
nvoTMROut {0.0 0}, {100.0 1}, {Invalid}
{0.0 0}
• Configuration Properties
Common
CONFIGURATION NETWORK
PROPERTY VARIABLE
SCPTdirection ----
SCPTinvrtOut nviTMRIn
SCPTinvrtOut nvoTMROut
SEN TRONIC
fbTMR[0,1] (Object ID : 45, 46)
Network Variables
nviTMRIn
SNVT_switch
Configuration Properties
fbTMR :
SCPTtimeout[0]
On delay time
SCPTtimeout[1]
OFF delay time
SCPTtimeout[2] ON hold time at ON
nviTMRIn :
SCPTinvrtOut
Timer's trigger condition
nvoTMROut :
Output logic
SCPTinvrtOut
EXPLANATIONS
Starts the timer function.
With 'Invalid,' nvoTMROut is reset to the default status and the internal
counter is reset.
Timer output
TYPE
{ Range }
{ Default }
{SNVT_state}
{0 or 1}
{0,0,0,0,0,0,0,0,
0,0,0,0,0,0,0,0}
{SNVT_lev_disc}
{ST_OFF, ST_ON}
{ST_OFF}
{SNVT_lev_disc}
{ST_OFF, ST_ON}
{ST_OFF}
056 222 38 18
AG
nvoTMROut
nv 130,
nv 131 SNVT_switch
EXPLANATIONS
Bit 0 : fbTMR operating mode
0 : One shot mode
1 : Cyclic mode
Bit 1 through 15 : Invalid
Timer's trigger condition
ST_OFF : Start with nviTMRIn = ON, Stop at OFF
ST_ON : Start with nviTMRIn = OFF, Stop at ON
Timer output logic
ST_OFF : nvoTMROut = ON with the timer functioning
and ON, nvoTMROut = OFF in any other conditions.
ST_ON : nvoTMROut = OFF with the timer functioning
and ON, nvoTMROut = ON in any other conditions.
mailbox@sentronic.com www.sentronic.com
R7L-DC16B
EM-7804-H Rev.7 P. 14 / 19
