■ FUNCTIONAL BLOCK: fbDO[0...7]
• Network Properties
State Mode
TYPE
NETWORK
{ Range }
VARIABLE
{ Default }
{SNVT_switch}
nviDO {0.0 0}, {100.0 1}, {Invalid}
{0.0 0}
{SNVT_switch}
nviDOOvr {0.0 0}, {100.0 1}, {Invalid}
{0.0 0}
{SNVT_switch}
nvoDOStat {0.0 0}, {100.0 1}, {Invalid}
{0.0 0}
Momentary Mode 1 or 2
TYPE
NETWORK
{ Range }
VARIABLE
{ Default }
{SNVT_switch}
nviDO {0.0 0}, {100.0 1}, {Invalid}
{0.0 0}
{SNVT_switch}
nviDOOvr {0.0 0}, {100.0 1}, {Invalid}
{0.0 0}
{SNVT_switch}
nvoDOStat {0.0 0}, {100.0 1}, {Invalid}
{0.0 0}
• Configuration Properties
Common
CONFIGURATION NETWORK
PROPERTY VARIABLE
SCPTdirection ----
Momentary Mode 1 or 2
CONFIGURATION NETWORK
PROPERTY VARIABLE
SCPTtimeout ----
• Difference between Momentary Mode 1 and 2
nviDO or nviDOOvr
Y0, Y2, Y4 and Y6
Momentary Mode 1
Y1, Y3, Y5 and Y7
Y0, Y2, Y4 and Y6
Momentary Mode 2
Y1, Y3, Y5 and Y7
SEN TRONIC
EXPLANATIONS
Turns on or off Y0, Y2, Y4, Y6, Y8, YA, YC, YE depending upon this input.
Turns on or off Y1, Y3, Y5, Y7, Y9, YB, YD, YF depending upon this input.
Invalid
EXPLANATIONS
Y0, Y2, Y4, Y6, Y8, YA, YC, YE : One-shot output when the input is ON.
Y1, Y3, Y5, Y7, Y9, YB, YD, YF : One-shot output when the input is OFF.
nviDO status is invalid when nviDOOvr is other than 'Invalid.' One-shot
output is provided at either Y0 or Y1 depending upon nviDOOvr value.
Outputs last one-shot output status.
TYPE
{ Range } EXPLANATIONS
{ Default }
Bit 0 and 2: fbDO operating mode
0 and 0: State mode
{SNVT_state} 1 and 0: Momentary mode 1
{0 or 1} 1 and 1: Momentary mode 2
{0,0,0,0,0,0,0,0, Bit 1: Output held or not at power off in State mode
0,0,0,0,0,0,0,0} 0 : OFF at the power startup
1 : Outputs the held status at the power startup
Bit 3 through 15 : Invalid
TYPE
{ Range } EXPLANATIONS
{ Default }
{SNVT_time_sec}
{0.1...60.0} Specifies ON time for the one-shot output
{0.5}
ON OFF ON
