DATE & TIME
YEAR
MONTH
DAY
TIME
CURRENT DATE TIME
DAYLIGHT SAVING
DAYLIGHT SAVING
BEGIN MONTH
END MONTH
TIME DIFFERENCE
OFF TIMER
RESET

MULTI INPUT

KEEP MULTI PICTURE
1
MODE*
MULTI PICTURE
1, 3
MODE* *
MULTI PICTURE
1, 2
ACTIVE PICTURE* *
ACTIVE
ACTIVE FRAME
1, 2, 3
INPUT SELECT* * *
PICTURE SIZE* 1, * 2, * 4
1, 2, 4
PICTURE POSITION* * *
1, 2, 4
PICTURE ASPECT* * *
1, 3
TEXT TICKER* *
MODE
POSITION
SIZE
DETECT
INPUT SELECT
*1: This function is released when selecting SUPER in INPUT CHANGE, MOTION in SCREEN SAVER, TILE MATRIX and IMAGE FLIP except for NONE.
*2: When TEXT TICKER is active or multi picture is OFF, this function is not available.
*3: When you select OPTION for multi picture input, this function depends on which option board you are using.
*4: This function is not available if PIP is set at MULTI PICTURE MODE and then PICTURE1 is set at ACTIVE PICTURE.
Sets the date, time, and daylight savings region. Date & time must be set in order for the "SCHEDULE" function
to operate.
NOTE: If the monitor's main power has been turned off for two weeks, the DATE & TIME setting goes back to the
default setting and the clock function stops working.
Sets the year for the real-time clock.
Sets the month for the real-time clock.
Sets the day for the real-time clock.
Sets the time for the real-time clock.
Shows the current date and time.
Sets daylight savings on or off.
NOTE: Please set the TIME & DATE setting first if you change the DAYLIGHT SAVING setting.
If ON is selected, please set daylight savings settings below.
Set daylight savings beginning date.
Set daylight savings ending date.
Set the time difference.
Set the monitor to power off after a preset time period. A time period between 1 to 24 hours may be set.
NOTE: SCHEDULE is not available if OFF TIMER is ON.
Resets the following settings within the SCHEDULE menu back to factory setting: DATE & TIME and DAYLIGHT
SAVING.
Allows the monitor to remain in MULTI PICTURE and TEXT TICKER mode after powering off.
When Power is returned, MULTI PICTURE and TEXT TICKER appear without having to enter the OSD.
When "OFF" is selected, one picture is displayed.
When "ON" is selected, several pictures are displayed. Select PIP or PBP.
NOTE: When "ON" is selected, TEXT TICKER, CLOSED CAPTION, TILEM ATRIX, MOTION in SCREEN
SAVER, IMAGE FLIP, except for NONE, INPUT SUPER in INPUT CHANGE is released.
When MULTI PICTURE is "OFF", [PICTURE 1] is the Active Picture. When MULTI PICTURE is "ON", sets Active
Picture.
NOTE: This function depends on MULTI PICTURE setting.
The active picture is shown within a red frame.
Selects the Multi Picture input. Press the + button or - button to select the input.
NOTE: This function is not available when MULTI PICTURE is "OFF".
When changing input signal for the active picture, after selecting an input press SET.
Sets the Active Picture size.
Press the SET/POINT ZOOM button to adjust the picture size. Press + or CH+ to expand. Press - or CH- to
reduce.
Sets the Active Picture location.
Pressing the + button moves the Active Picture to the right, and pressing the - button moves it to the left.
Pressing the button moves the Active Picture up, and pressing the
Selects the Active Picture frame aspect.
To change aspect ratio of the screen image, see page 20.
NOTE: When TEXT TICKER is set, MULTI PICTURE MODE and STILL are not available.
TEXT TICKER is released if following menu is activated: MULTI PICTURE MODE, TILE MATRIX, SCREEN
SAVER, IMAGE FLIP, SUPER in INPUT CHANGE, CLOSED CAPTION.
When this function is active, POINT ZOOM and STILL are not available.
Enables Text Ticker and allows you to set Horizontal or Vertical direction.
Selects the location of the Text Ticker on the screen.
Determines the size of the Text Ticker in relationship to the overall screen size.
Enables auto-detection of the Text Ticker.
Set input signal for PICTURE1, PICTURE2.
English-36
button moves it down.
