INDOOR/COVERED OUTDOOR CEILING FAN
Questions, problems, missing parts? Before returning to the store,
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m.- 6 p.m., EST, Saturday
We appreciate the trust and con dence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We
strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for
your home improvement needs. Thank you for choosing Home Decorators Collection!
USE AND CARE GUIDE
52 IN. EASTON
call Home Decorators Collection Customer Service
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
Visual instruction of how to install this fan:
Visit www.homedepot.com and enter either the Item or Model number to nd
this fan and click the link of visual instruction in the product overview section.
Item #1008 590 986
Model # N381A-BN
THANK YOU
1008 590 275
1008 590 282
1008 590 992
1008 590 994
1008 590 997
N381A-MBK
N381A-CB+MBK
N381A-MBK+V8
N381A-CB+MWH N381A-MWH
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection EASTON N381A-BN
Summary of Contents for Home Decorators Collection EASTON N381A-BN
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........Assembly . -
Page 3: Warranty
Warranty The manufacturer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. The manufacturer warrants the light kit (excluding any glass), to be free from defects in workmanship and material present at time of shipment from the factory for a period of ve years after the date of purchase by the original purchaser. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Plastic wire nut Blade attachment screw and lock washer (additional) 1.5V AAA battery 3-pin extension cord...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Mounting bracket Blade support plate with screws and lock washers Canopy Canopy bottom cover (preassembled) Blade Hanger ball/downrod assembly Receiver Coupling cover Remote control Fan motor assembly HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
-
Page 6: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain proper WARNING: To reduce the risk of re, electric shock, or blade clearance when installing on a steep, sloped ceiling. personal injury, mount the fan to an outlet box marked The maximum angle allowable is 18°... -
Page 7: Assembly
Assembly — Attaching the Fan Blades Attaching the fan blades Preparing the canopy Remove the canopy bottom cover (C) from the canopy (B) by Align the blade notches with the motor posts. turning the canopy bottom cover (C) counterclockwise. Attach the blade (H) to the fan motor assembly (F). Align the Remove the mounting bracket (A) from the canopy (B) by holes on the blade support plate (G), the blade (H), and the loosening canopy mounting screws (EE) a half turn from the... - Page 8 Assembly — Hanging the Fan Assembling the fan WARNING: Failure to properly install the cotter pin (FF) could result in the fan loosening and possibly falling. NOTE: If a longer downrod (not included) is needed, take out the screw located in the hanger ball (JJ), lower the hanger ball (JJ) and remove the pin (KK).
- Page 9 Assembly — Hanging the Fan (continued) Attaching the mounting bracket to the Hanging the fan on the mounting electrical box bracket WARNING: To reduce the risk of re, electric shock or other WARNING: The tab in the ring must rest in the groove of personal injury, mount the fan only to an outlet box or supporting the hanger ball/downrod assembly (D).
- Page 10 Assembly — Hanging the Fan (continued) Making the electrical connections Ground White Black conductor WARNING: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts (except for the ground wire). Outlet Box CAUTION: To reduce the risk of electric shock, this fan must be installed with an isolating wall control/switch.
- Page 11 Assembly — Hanging the Fan (continued) Finishing the fan installation WARNING: Make sure the tab on the mounting bracket Outlet Box properly sits in the groove in the hanger ball before attaching the canopy to the bracket by turning the housing until it drops into place.
-
Page 12: Operation
Operation SETTING UP THE TRANSMITTER NOTE: The remote has been pre-paired in the factory for your convenience. NOTE: Batteries will weaken with age and should be replaced before leaking takes place as this will damage the remote control. Dispose of used batteries properly and keep them out of the reach of children. - Page 13 Operation (continued) Signal light Fan speed Power on/off Comfort Breeze Fan reverse Timer OPERATING YOUR FAN AND REMOTE CONTROL NOTE: The fan will store the last used speed setting for the next time it is turned on. NOTE: You must turn the fan on prior to using the speed or time functions. NOTE: On each start up of your ceiling fan, the fan blades will oscillate back and forth.
- Page 14 Operation (continued) Comfort Breeze Pressing the button will activate the Comfort Breeze mode. If you are using Comfort Breeze mode, pressing the button or the fan speed buttons will cancel Comfort Breeze mode and resume normal fan operation. Fan reverse button (Must be pushed when the fan is in operation) Controls fan direction.
- Page 15 Operation (continued) INSTALLING THE REMOTE CONTROL HOLDER Attach the remote control holder (PP) with the two remote control holder mounting screws (QQ). WARM/COOL WEATHER OPERATING INSTRUCTIONS Speed settings for warm or cool weather depend on factors such as the room size, ceiling height, numbers of fans. NOTE: The fan reverse buttons must be pressed while the fan is running.
-
Page 16: Care And Cleaning
Care and Cleaning Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. Because of the fan’s natural movement, some connections may become loose over time. It is not necessary to remove the fan from the ceiling. Clean your fan periodically. - Page 17 - Consult the dealer or an experienced radio/TV technician for help. Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m.- 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
