VERSION # 2022-04-1 4
1 / 15
MODEL #
CM7317D
Questions?
GIVE US A CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PT)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7317D
Summary of Contents for Furniture of America CM7317D
- Page 1 MODEL # CM7317D Questions? GIVE US A CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PT) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 15...
- Page 5 DRESSER CM7317D #1 1pc #2 1pc #3 1pc #4 1pc Right Side Left Side Top Back Top Panel Panel Panel Panel #8 6pcs #5 1pc #7 6pcs #6 6pcs Drawer Right Bottom Drawer Drawer Left Side Panel Panel Front Panel...
-
Page 6: Exploded View
#A 6pcs #B 12pcs #C 6pcs Handle Handle Screw Wood Dowels Ø5/32" x 7/8" Ø8 x 30mm #D 46pcs #E 1pc #F 1pc Bolt Ø1/4" x 1" Tipping Restraint Allen Wrench M4 Hardware Kit Exploded View 6 / 15... - Page 7 ASSEMBLY INSTRUCTIONS Align and attach Divider panels (#12) to Right side panel (#3) and lock into place. Part #3 x1pc Part #12 x2pcs Align and attach Center Panel (#13) to the Divider panels (#12) Part #13 x1pc and lock into place. 7 / 15...
- Page 8 ASSEMBLY INSTRUCTIONS Align and attach Divider panel (#12) to the other side of center panel (#13) and lock into place. Part #12 x2pcs Part #2 x1pc Align and attach Left side panel (#2) to the Divider panel (#12) and lock into place.
- Page 9 ASSEMBLY INSTRUCTIONS Attach wooden dowels (#C) to L/R side panels (#2, #3) and center divider panel (#13). Hardware #C x 6pcs Part #5 x 1pc Part #11 x 5pcs Attach legs (#11) to the Bottom Panel (#5). 9 / 15...
- Page 10 ASSEMBLY INSTRUCTIONS Align and attach Bottom board (#5) to the L/R side panels (#2,3) and Center panel (#13). Attach Top panel (#1) onto L/R side Part #1 x1pc panels (#2,3). Lock into place. 10 / 15...
- Page 11 ASSEMBLY INSTRUCTIONS Align Top and Bottom back panels (#4,14) and secure using Bolts (#D). Part #4 x 1pc Part #14 x 1pc Hardware #D x 20pcs Hardware #D x2pcs Secure Bottom panel (#5) by using Bolts (#D). 11 / 15...
- Page 12 ASSEMBLY INSTRUCTIONS Attach Drawer L/R Panels (#7, #8) to the Drawer front panel (#6). Part #6 x1pc Part #7 x1pc Part #8 x1pc Insert Drawer bottom panel (#9). Part #9 x 1pc Then align Drawer back panel (#10) Part #10 x 1pc and secure using Bolts (#D).
- Page 13 ASSEMBLY INSTRUCTIONS Align and attach Handles (#A) with screw (#B) . H ardware #A x 1pc Hardware #B x 2pcs Insert drawers. Note: Press down release tab to insert rail completely into side glides. 13 / 15...
- Page 14 ASSEMBLY INSTRUCTIONS Hardware #F x 1pc 14 / 15...
- Page 15 15 / 15...
