ASSEMBLY RATING

The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7389CK
DIFFICULT
R
Tools Required For Assembly:
Allen Wrench
Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 8
R
(Included)
(Included)
(Not Included)
REV: 18-01-10
