For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7384EK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Not Included)
Rev: 18-06-28
Advertisement
Related Manuals for Furniture of America CM7384EK
Summary of Contents for Furniture of America CM7384EK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7384EK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 6pcs Headboard Bolt Ø5/16"x1-1/2" #B x 6pcs #2 x 2pcs Leg(L&R) Lock Washer Ø5/16"...
- Page 4 Exploded View Align connecting rod (#3) to the holes of the legs (#2R/L), then secure by using bolts (#A) with washers (#B,C). #A x 2pcs #B x 2pcs #C x 2pcs Page 4 of 7...
- Page 5 Align legs (#2R,L) to the holes of the headboard (#1), then secure by using bolts (#A) with washers (#B,C). #A x 4pcs #B x 4pcs #C x 4pcs Attach leg supports (#9,10) to the holes of the footboard (#4). Page 5 of 7...
- Page 6 Align and hook the side rails (#5) to the latches of the headboard (#1) and footboard (#4). Align center slat (#7) to the slat kit (#6), then secure by using leg supports (#8). Adjust the leveler of the leg supports (#8) according to ground level. Page 6 of 7...
- Page 7 Align slat kit (#6) to the side rails (#5), then secure by using screws (#D). #D x 26pcs ASSEMBLY IS COMPLETED Page 7 of 7...
