- Page 1 KVM switch and rackmount screen technology User Manual 17” 4K LCD RM-DSK17 3840 x 2160@60Hz native resolution 1U Dual Slide Ultra Short Depth LCD Console Drawer Options : - SDI - DC power Ultra short depth 480mm / 18.9″...
- Page 2 Legal Information First English printing, April 2022 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents RM-DSK17 < Part. 1 > Package Content Structure Diagram & Dimension Installation Connection < Part. 2 > Specifi cations / OSD Product Specifi cations Keyboard / Mouse Specifi cations Video connectivity P.12 On-screen Display Operation ( OSD ) P.13 <... - Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 5: Package Content
< Part 1 > RM-DSK17 < 1.1 > Package Content RM-DSK17 unit X 1 - 6ft HDMI cable X 1 - 6ft USB cable X 2 - 4A power adapter & Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. - Page 6 Weight 441.6 x 480 x 44.5 mm 590 x 622 x 140 mm 10.6 kg 15.6 kg RM-DSK17 17.4 x 18.9 x 1.75 inch 23.2 x 24.5 x 5.5 inch 23.4 lb 34.4 lb The weight is only for the single console models. It varies with accessories & options such as KVM, SDI, HDMI &...
-
Page 7: Installation
RM-DSK17 < 1.3 > Installation - How to install Installation Slides Step ■ Insert the left and right rear mounting brackets into the LCD console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. - Page 8 < 1.3 > Installation - How to Use the Dual Slides ■ Press the handle button and gently slide out the drawer. ■ Flip up the LCD to a suitable angle. ■ Operate the LCD console drawer. UM-CV-751-DK47-Q222V1 www.rackmountsales.com...
- Page 9 RM-DSK17 Installation - How to Use the Dual Slides ■ Flip down the front panel. ■ Press the handle button and gently push back the drawer into the rack. ■ Return the LCD console drawer to park position. UM-CV-751-DK117-Q222V1 www.rackmountsales.com...
-
Page 10: Connection
< 1.4 > Connection to HDMI Server LCD Console Drawer USB x 2 POWER HDMI 6ft HDMI K/B & MS cable USB cable HDMI DP server < 1.4 > Connection to external KVM LCD Console Drawer LCD Console Drawer USB x 2 POWER HDMI 6ft HDMI... -
Page 11: Product Specifi Cations
< Part 2 > RM-DSK17 < 2.1 > Product Specifi cations Panel Size ( diagonal ) 17.3-inch Widescreen TFT color LCD Panel Display pixel ( dots x lines ) 3840 x 2160@60Hz Brightness ( typ. ) Contrast Ratio ( typ. ) - Page 12 Product Specifi cations Physical Product ( W x D x H ) 441.6 x 480 x 44.5 mm Specifi cation 17.4 x 18.9 x 1.75 inch Packing ( W x D x H ) 590 x 622 x 140 mm 23.2 x 24.5 x 5.5 inch Net Weight 10.6 kg / 23.4 lb...
-
Page 13: Keyboard / Mouse Specifi Cations
RM-DSK17 < 2.2 > Keyboard / Mouse Specifi cations keyboard integrated with touchpad Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time OS support Windows / Linux / Unix / Mac OS... - Page 14 MAC Keyboard / Mouse Options MAC keyboard integrated with touchpad Supporting layouts America United States How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion Decrease volume default Keyboard Shortcuts.
- Page 15 RM-DSK17 < 2.2 > SUN Keyboard / Mouse Options S keyboard integrated with touchpad Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■...
-
Page 16: Video Connectivity
< 2.3 > Video connectivity LED light No light = OFF Green = ON / Connected = Disconnected Video selection button HDMI • HDMI LED will be ON after power ON (Default video input = HDMI) • Select VGA or DP video input by pressing the desired video selection button •... -
Page 17: On-Screen Display Operation ( Osd )
RM-DSK17 < 2.4 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control... - Page 18 < 2.4 > On-screen Display Operation ( OSD ) Picture Brightness : Adjust the screen brightness Contrast : Adjust the diff erence between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen : Screen in power saving mode Position Picture size : Adjust the image size...
- Page 19 RM-DSK17 On-screen Display Operation ( OSD ) Reset Reset : Return the adjustment back to factory setting PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) /...
- Page 20 < Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input Crystal Image’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CIT displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
- Page 21 RM-DSK17 < 3.2 > Options : DC Power Model 125V 250V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt 300-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load...
- Page 22 < Part. 4 > KVM Integration KVM integration : Refer to dual slide RM-DK17 series www.rackmountsales.com/RM-DK17.pdf UM-CV-751-DK117-Q222V1 P.18 www.rackmountsales.com...
- Page 23 Intentionally Left Blank UM-CV-751-DK117-Q222V1 www.rackmountsales.com...
- Page 24 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2022 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-DK117-Q222V1 P.20 www.rackmountsales.com...
