User Manual
DK1417
3840 x 2160@60Hz native resolution
1U Dual Slide Ultra Short Depth
LCD Console Drawer
Designed and manufactured by Austin Hughes
UM-CV-751-DK1417-Q222V1
dedicated KVM switch and rackmount screen technology
17" 4K LCD
Ultra short depth
480mm / 18.9"
Options :
- SDI
- DC power
www.austin-hughes.com
751
Advertisement
Table of Contents
Related Manuals for Cyber View DK1417
Summary of Contents for Cyber View DK1417
- Page 1 KVM switch and rackmount screen technology User Manual 17” 4K LCD DK1417 3840 x 2160@60Hz native resolution 1U Dual Slide Ultra Short Depth LCD Console Drawer Options : - SDI - DC power Ultra short depth 480mm / 18.9″...
- Page 2 ■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected. UM-CV-751-DK1417-Q222V1 www.austin-hughes.com...
-
Page 3: Table Of Contents
Contents < Part. 1 > DK1417 Package Content Structure Diagram & Dimension Installation Connection < Part. 2 > Specifi cations / OSD Product Specifi cations Keyboard / Mouse Specifi cations Video connectivity P.12 On-screen Display Operation ( OSD ) P.13 <... - Page 4 fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-DK1417-Q222V1 www.austin-hughes.com...
-
Page 5: Dk1417
< Part 1 > < 1.1 > Package Content DK1417 DK1417 unit X 1 - 6ft HDMI cable X 1 - 6ft USB cable X 2 - 4A power adapter & Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. - Page 6 Weight 441.6 x 480 x 44.5 mm 590 x 622 x 140 mm 10.6 kg 15.6 kg DK1417 17.4 x 18.9 x 1.75 inch 23.2 x 24.5 x 5.5 inch 23.4 lb 34.4 lb The weight is only for the single console models. It varies with accessories & options such as KVM, SDI, HDMI &...
-
Page 7: Installation
< 1.3 > Installation - How to install Installation Slides DK1417 Step ■ Insert the left and right rear mounting brackets into the LCD console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. - Page 8 < 1.3 > Installation - How to Use the Dual Slides ■ Press the handle button and gently slide out the drawer. ■ Flip up the LCD to a suitable angle. ■ Operate the LCD console drawer. UM-CV-751-DK1417-Q222V1 www.austin-hughes.com...
- Page 9 Installation - How to Use the Dual Slides DK1417 ■ Flip down the front panel. ■ Press the handle button and gently push back the drawer into the rack. ■ Return the LCD console drawer to park position. UM-CV-751-DK1417-Q222V1 www.austin-hughes.com...
-
Page 10: Connection
Before attempting to connect anything to the LCD console drawer, we suggest turning off the power to all devices. Apply power to connected devices again only after the LCD console drawer is receiving power. The company is not responsible for damage caused in this way. UM-CV-751-DK1417-Q222V1 www.austin-hughes.com... -
Page 11: Product Specifi Cations
< Part 2 > < 2.1 > Product Specifi cations DK1417 Panel Size ( diagonal ) 17.3-inch Widescreen TFT color LCD Panel Display pixel ( dots x lines ) 3840 x 2160@60Hz Brightness ( typ. ) Contrast Ratio ( typ. ) - Page 12 1920 x 1080 x 50 / 60Hz ( 1080p ) 1920 x 1080 x 25 / 30Hz ( 1080i ) 1280 x 720 x 50 / 60Hz ( 720p ) 720 x 480 x 50 / 60Hz ( 576p / 480p ) Audio Signal 2ch Linear PCM UM-CV-751-DK1417-Q222V1 www.austin-hughes.com...
-
Page 13: Keyboard / Mouse Specifi Cations
< 2.2 > Keyboard / Mouse Specifi cations DK1417 G keyboard integrated with touchpad Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time OS support Windows / Linux / Unix / Mac OS... - Page 14 How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion Decrease volume default Keyboard Shortcuts. Dashboard Increase volume Eject disc Rewind Command Play / Pause UM-CV-751-DK1417-Q222V1 P.10 www.austin-hughes.com...
- Page 15 < 2.2 > SUN Keyboard / Mouse Options DK1417 S keyboard integrated with touchpad Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■...
-
Page 16: Video Connectivity
; others will be OFF • LED light will be if no video signal input • To auto adjust under VGA mode, by pressing the VGA button 3 ~ 5 seconds to confi rm UM-CV-751-DK1417-Q222V1 P.12 www.austin-hughes.com... -
Page 17: On-Screen Display Operation ( Osd )
< 2.4 > On-screen Display Operation ( OSD ) DK1417 Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control... - Page 18 OSD time out : Adjust the screen timeout OSD transparency : Adjust the screen transparency OSD size : Adjust the screen size - Normal / Small OSD rotation : Rotate the screen - 90° / 180° / 270° UM-CV-751-DK1417-Q222V1 P.14 www.austin-hughes.com...
- Page 19 On-screen Display Operation ( OSD ) DK1417 Reset Reset : Return the adjustment back to factory setting PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) /...
- Page 20 48kHz, 16 / 20 / 24 bit, 2 CH, Synchronized Video SD-SDI 48kHz, 16 / 20 / 24 bit, 2 CH, Synchronized / Asynchronized Video Max. Transmission Distance 3G-SDI 150m at 2.97Gb/s 75 ohm coaxial cable HD-SDI 250m at 1.485Gb/s SD-SDI 480m at 270Mb/s UM-CV-751-DK1417-Q222V1 P.16 www.austin-hughes.com...
- Page 21 < 3.2 > Options : DC Power DK1417 Model 125V 250V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt 300-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load...
- Page 22 < Part. 4 > KVM Integration KVM integration : Refer to dual slide DK117 series www.austin-hughes.com/PS-CV-DK117.pdf UM-CV-751-DK1417-Q222V1 P.18 www.austin-hughes.com...
- Page 23 Intentionally Left Blank UM-CV-751-DK1417-Q222V1 www.austin-hughes.com...
- Page 24 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2022 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-DK1417-Q222V1 P.20 www.austin-hughes.com...
