Summary of Contents for Cyber View 1U L-120 Series
-
Page 2: Table Of Contents
Contents Chapter 1 Getting Started Important Safeguards............1 Regulatory Notice..............2 Package Contents...............3 Before Installation...............4 Unpacking................4 Optional Accessories............4 Peripheral Products.............5 Structure Diagram...............5 Installation................6-7 1.10 How to Use L / LS Series LCD Keyboard Drawer....8 1.11 LS-120 (Single console) ......9 - Use CB-6 to connect to server via USB interface 1.12 LS-120 (Single console) ......9... - Page 3 Contents Chapter 4 Optional Specifi cation KVM Options..............17 DVI-D Input Option............17 BNC + S-Video Option............17 Audio Option..............18 DC power Options............19 Chapter 5 Troubleshooting ............20 Chapter 6 Dimensions ...............21...
-
Page 4: Important Safeguards
Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. ■... -
Page 5: Regulatory Notice
Chapter 1 1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. -
Page 6: Package Contents
Chapter 1 1.3 Package Contents LCD keyboard drawer x 1 pc CB-6 USB 2-in-1 KVM cable x 1 pc (for LS series) CE-6 Combo 4-in-1 KVM cable x 1 pc (for L series) User manual x 1 pc Power cord x 1 pc Auto switch power adapter ( for external power version) x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs... -
Page 7: Before Installation
Chapter 1 1.4 Before Installation ■ It is very important to locate the LCD Keyboard Drawer in a suitable environment. ■ The surface for placing and fi xing the LCD Keyboard Drawer should be stable and level or mounted into a suitable cabinet. -
Page 8: Peripheral Products
Chapter 1 1.7 Peripheral Products Item Model No. Description MU-1602 / MU-1603 / MU-1604 Matrix Cat6 16 port KVM MU-IP1613 / MU-IP1614 / MU-IP1624 Matrix IP Cat6 16 port KVM Matrix Cat6 KVM MU-3202 / MU-3203 / MU-3204 Matrix Cat6 32 port KVM MU-IP3213 / MU-IP3214 / MU-IP3224 Matrix IP Cat6 32 port KVM M-802 / M-803 / M-804... -
Page 9: Installation
Chapter 1 1.9 Installation Rear side Right bracket Left bracket Front side ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the mouting bracket to fi t your rack. ■ M6 screw and cup washer x 8 pcs included. Caution : Leaving all M6 screw slightly loose, until you complete the installation in step Mounting bracket... - Page 10 Chapter 1 1.9 Installation Front side Rear kit M3.2 screw ■ Fix the rear kit to the mounting bracket by M3.2 screw x 4 pcs included. Caution : This step is necessary. Failure to complete this will cause damage. Complete the installation ■...
-
Page 11: How To Use L / Ls Series Lcd Keyboard Drawer
Chapter 1 1.10 How to Use L / LS Series LCD Keyboard Drawer ■ Press the carry handle button. Gently pull the carry handle toward the front of the LCD shown in Figure 1. Figure 1. Sliding out the LCD keyboard drawer by pressing the carry handle button first. -
Page 12: Ls-120 (Single Console)
Chapter 1 1.11 LS-120 (Single console) - Use CB-6 to connect to server via USB interface Figure 4. Example of connecting CB-6 2-in-1 USB KVM cable to server via USB interface 1.12 LS-120 (Single console) - Use CB-6 to connect to KVM via USB interface CB-6 KVM Cable Figure 5. -
Page 13: L-120 (Single Console)
Chapter 1 1.13 L-120 (Single console) - Use CE-6 to connect to server via PS/2 interface Figure 6. Example of connecting CE-6 Combo 4-in-1 KVM cable to server via PS/2 interface 1.14 L-120 (Single console) - Use CE-6 to connect to KVM via PS/2 interface CE-6 KVM Cable Figure 7. -
Page 14: L-120 (Single Console)
Chapter 1 1.15 L-120 (Single console) - Use CE-6 to connect to server via USB interface Figure 8. Example of connecting CE-6 Combo 4-in-1 KVM cable to server via USB interface 1.16 L-120 (Single console) - Use CE-6 to connect to KVM via USB interface CE-6 KVM Cable Figure 9. -
Page 15: On-Screen Display Operation
Chapter 2 2.1 On-screen Display Operation LCD membrane Membrane Switch Function Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... -
Page 16: On-Screen Menu
Chapter 2 2.2 On-screen Menu OSD Confi guration Page Image: To enter into the brighness, contrast, color temp, red, green, and blue Geometry: To enter into the auto adjust, H position, V position, phase and clock Video: To enter into the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: To enter into volume, bass, treble, balance, AVL and mute... -
Page 17: Specifi Cations
Chapter 3 3.1 Specifi cations Item Description 1U rack mounting on slide-out rails Form Factor LCD Manufacturer Series 20" TFT 20" TFT Diagonal Size 1152 x 900 (Direct) 1600 x 1200 Max. Resolution 1600 x 1200 (Native) Brightness (cd/m²) 16.7 M 16.7 M Color Support 800:1... -
Page 18: Keyboard & Mouse
Chapter 3 3.2 Keyboard & Mouse For L-120 series Supporting layouts N keyboard integrated with touchpad & 2 buttons mouse interchangeable module kit For LS-120 series Supporting layouts NS keyboard integrated with touchpad & 2 buttons mouse interchangeable module kit ■... -
Page 19: How To Use "Ns" Keyboard
Chapter 3 3.3 How to Use "NS" keyboard ■ NS SUN-compatible keyboard incorporates SUN short-cut keys. ■ Press the Fn/Num button to switch the color the Num LED. Num LED in Off mode Num LED in Green color Key pad behaves as a SUN Solaris system Key pad behaves as a normal key pad mode administration command mode Three Audio / Display keys are located in the upper-right corner of the NS keyboard:... -
Page 20: Kvm Options
Chapter 4 4.1 KVM Options Our KVM is designed to seamlessly integrate into the rear of our full range of LCD drawer solutions: ■ For KVM operation, please refer to KVM user manual ■ Option with Multiple consoles Matrix KVM ■... -
Page 21: Audio Option
Chapter 4 4.4 Audio Option Speaker 3-in-1 VGA KB mouse Power Audio console port Remarks ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.18... -
Page 22: Dc Power Options
Chapter 4 4.5 DC Power Options Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA Output rating... -
Page 23: Chapter 5 Troubleshooting
Chapter 5 5.1 Troubleshooting 1. Is interference signal appeared on LCD normal when shutting down the computer ? In rare cases, interference may appear on the monitor. This may be caused by signal rate of VGA card and is considered normal. -
Page 24: Chapter 6 Dimensions
Chapter 6 6.1 Dimensions Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 442 x 650 x 44 mm 589 x 856 x 168 mm 20 kg 26 kg L-120 series 17.4 x 25.6 x 1.73"...
