Summary of Contents for Cyber View W-119 series
-
Page 2: Table Of Contents
- Use CB-6 to connect to server via USB interface 1.12 WS-119 (Single console) ......9 - Use CB-6 to connect to KVM via USB interface 1.13 W-119 (Single console) ......10 - Use CE-6 to connect to server via PS/2 interface. 1.14 W-119 (Single console) ......10 - Use CE-6 to connect to KVM via PS/2 interface 1.15... - Page 3 Contents Chapter 4 Optional Specifi cation KVM Options..............18 DVI-D Input Option............18 BNC + S-Video Option............18 Audio Option..............19 DC power Options.............19 Chapter 5 Troubleshooting ............20 Chapter 6 Dimensions ...............21...
-
Page 4: Important Safeguards
Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. ■... -
Page 5: Regulatory Notice
Chapter 1 1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. -
Page 6: Package Contents
Chapter 1 1.3 Package Contents LCD keyboard drawer x 1 pc CB-6 USB 2-in-1 KVM cable x 1 pc (for WS series) CE-6 Combo 4-in-1 KVM cable x 1 pc (for W series) User manual x 1 pc Power cord x 1 pc Auto switch power adapter ( for external power version) x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs... -
Page 7: Before Installation
Chapter 1 1.4 Before Installation ■ It is very important to locate the LCD Keyboard Drawer in a suitable environment. ■ The surface for placing and fi xing the LCD Keyboard Drawer should be stable and level or mounted into a suitable cabinet. -
Page 8: Peripheral Products
Chapter 1 1.7 Peripheral Products Item Model No. Description MU-1602 / MU-1603 / MU-1604 Matrix Cat6 16 port KVM MU-IP1613 / MU-IP1614 / MU-IP1624 Matrix IP Cat6 16 port KVM Matrix Cat6 KVM MU-3202 / MU-3203 / MU-3204 Matrix Cat6 32 port KVM MU-IP3213 / MU-IP3214 / MU-IP3224 Matrix IP Cat6 32 port KVM M-802 / M-803 / M-804... -
Page 9: Installation
Chapter 1 1.9 Installation Rear side Right bracket Left bracket Front side ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the mouting bracket to fi t your rack. ■ M6 screw and cup washer x 8 pcs included. Caution : Leaving all M6 screw slightly loose, until you complete the installation in step Inner slide member... - Page 10 Chapter 1 1.9 Installation Mounting bracket ■ Pick up the LCD tray. ■ Insert the LCD tray into the mounting bracket. ■ Pull and hold the left & right black arrow buttons on the rails. ■ Return the LCD tray to park position. Black arrow button ■...
-
Page 11: How To Use The Slides
Chapter 1 1.10 How to Use the Slides ■ A black arrow release button is located on the outside of each slide. (shown in Figure 1). Figure 1. ■ Pull and hold the black arrow button on either side of the LCD keyboard drawer to unlock. (shown in Figure 2). -
Page 12: Ws-119 (Single Console)
Chapter 1 1.11 WS-119 (Single console) - Use CB-6 to connect to server via USB interface Figure 4. Example of connecting CB-6 2-in-1 USB KVM cable to server via USB interface 1.12 WS-119 (Single console) - Use CB-6 to connect to KVM via USB interface CB-6 KVM Cable Figure 5. -
Page 13: W-119 (Single Console)
Chapter 1 1.13 W-119 (Single console) - Use CE-6 to connect to server via PS/2 interface Figure 6. Example of connecting CE-6 4-in-1 Combo KVM cable to server via PS/2 interface 1.14 W-119 (Single console) - Use CE-6 to connect to KVM via PS/2 interface CE-6 KVM Cable Figure 7. -
Page 14: W-119 (Single Console)
Chapter 1 1.15 W-119 (Single console) - Use CE-6 to connect to server via USB interface Figure 8. Example of connecting CE-6 4-in-1 Combo KVM cable to server via USB interface 1.16 W-119 (Single console) - Use CE-6 to connect to KVM via USB interface CE-6 KVM Cable Figure 9. -
Page 15: On-Screen Display Operation
Chapter 2 2.1 On-screen Display Operation LCD membrane Membrane Switch Function Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... -
Page 16: On-Screen Menu
Chapter 2 2.2 On-screen Menu OSD Confi guration Page Image: To enter into the brighness, contrast, color temp, red, green, and blue Geometry: To enter into the auto adjust, H position, V position, phase and clock Video: To enter into the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: To enter into volume, bass, treble, balance, AVL and mute... -
Page 17: Specifi Cations
Chapter 3 3.1 Specifi cations Item Description 1U rack mounting on slide-out rails Form Factor LCD Manufacturer Series Wide 19" TFT Wide 19” TFT Diagonal Size 1152 x 900 (Direct) 1440 x 900 Max. Resolution 1440 x 900 (Native) Brightness (cd/m²) 16.7 M 16.7 M Color Support... - Page 18 Chapter 3 3.2 Keyboard & Mouse For W-119 series Supporting layouts N keyboard integrated with touchpad N keyboard integrated with trackball P.15...
-
Page 19: Keyboard & Mouse
Chapter 3 3.2 Keyboard & Mouse For WS-119 series Supporting layouts NS keyboard integrated with touchpad ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■ 104 key notepad keyboard with full numerical pad and SUN function ■... -
Page 20: How To Use "Ns" Keyboard
Chapter 3 3.3 How to Use "NS" keyboard ■ NS SUN-compatible keyboard incorporates SUN short-cut keys. ■ Press the Fn/Num button to switch the color the Num LED. Num LED in Off mode Num LED in Green color Key pad behaves as a SUN Solaris system Key pad behaves as a normal key pad mode administration command mode Three Audio / Display keys are located in the upper-right corner of the NS keyboard:... -
Page 21: Kvm Options
Chapter 4 4.1 KVM Options Our KVM is designed to seamlessly integrate into the rear of our full range of LCD drawer solutions: ■ For KVM operation, please refer to KVM user manual ■ Option with Multiple consoles Matrix KVM ■... -
Page 22: Audio Option
Chapter 4 4.4 Audio Option Speaker 3-in-1 VGA KB mouse Power Audio console port Remarks ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. 4.5 DC Power Options Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt... -
Page 23: Chapter 5 Troubleshooting
Chapter 5 5.1 Troubleshooting 1. Is interference signal appeared on LCD normal when shutting down the computer ? In rare cases, interference may appear on the monitor. This may be caused by signal rate of VGA card and is considered normal. -
Page 24: Chapter 6 Dimensions
Weight Weight 442 x 600 x 44 mm 581 x 755 x 172 mm 18 kg 24 kg W-119 series 17.4 x 23.6 x 1.73" 22.9 x 29.7 x 6.8" 40 lb 53 lb 442 x 600 x 44 mm...
