- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS for all Hydrocarbon WTRF Refrigerator Freezer Models 809-172A Rev. A. 02/20/2023 SEE BACK COVER FOR 3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105 WARRANTY REGISTRATION Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: beverage-air.com...
-
Page 2: Table Of Contents
User Manual for WTRF Refrigerator Freezer Beverage Air WELCOME Congratulations on your purchase of Beverage-Air food Additionally, Beverage-Air food service equipment has service equipment. Every employee welcomes you to the one of the best warranties in the food service industry, family of satisfied Beverage-Air customers. -
Page 3: Safety
User Manual for WTRF Refrigerator Freezer Beveragae Air SAFETY This appliance has been designed with your safety in mind. It has many features to keep you from being harmed. However, safe operation and maintenance are your responsibilities. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 4 User Manual for WTRF Refrigerator Freezer Beverage Air Note: The top panel of this unit can be damaged by standing on it. Damage like that is NOT covered by warranty. WARNING Risk of Personal Injury From Falling Stay OFF top of unit For your protection, safety labels have been placed at important locations on the cabinet.
-
Page 5: Important Information
User Manual for WTRF Refrigerator Freezer Beveragae Air IMPORTANT INFORMATION This unit is intended to be used in a commercial application. That includes bars and restaurants. If installed in a residence some commercial service companies may not be able to service it on site. The manufacturer has designed and produced this machine with the finest in materials. -
Page 6: Product Information
User Manual for WTRF Refrigerator Freezer Beverage Air PRODUCT INFORMATION Full Load Full Load Refrigerant Type / Cabinet Dimensions Door Power Cord Model Amps - Amps - Charge (g) / Charge w x d x h (Inches) Count Plug (NEMA) Refrigerator Freezer (oz) -
Page 7: Clearance And Placement
User Manual for WTRF Refrigerator Freezer Beveragae Air CLEARANCE AND PLACEMENT 2" REAR MINIMUM CLEARANCE 3" 0" BOTTOM LEFT/RIGHT SIDE MINIMUM MINIMUM CLEARANCE CLEARANCE Placement Consider the following when selecting a location for your Refrigerator: Clearance: 0" - Top 0" - Left 0"... -
Page 8: Unpacking And Set Up
User Manual for WTRF Refrigerator Freezer Beverage Air UNPACKING AND SET UP Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim. Do NOT contact the manufacturer. -
Page 9: Shelf Installation
User Manual for WTRF Refrigerator Freezer Beveragae Air SHELF INSTALLATION 1. Determine the proper location for the shelf clips. 7. Confirm that the shelf is resting on ALL 4 clips and that the clips are securely attached to the pilasters. 2. -
Page 10: Electrical
User Manual for WTRF Refrigerator Freezer Beverage Air ELECTRICAL This is a cord-connected unit, and must be connected to its own dedicated power supply. Check the dataplate on the machine to confirm the voltage and per the dataplate use the correct fuses or HACR circuit breakers. Note: Do not connect to GFI / GFCI outlets. -
Page 11: Using The Unit With A Danfoss Controller
User Manual for WTRF Refrigerator Freezer Beveragae Air USING THE UNIT - DANFOSS CONTROLLER Operation is simple, just keep it connected to the correct The refrigerator temperature was set at the factory at 38 º power supply and the refrigerator will maintain the F, and the freezer temperature was set at 0 F., but you internal temperature it has been set to. -
Page 12: Sequence Of Operations - Refrigerator Section
User Manual for WTRF Refrigerator Freezer Beverage Air SEQUENCE OF OPERATIONS REFRIGERATOR SECTION - DANFOSS CONTROLLER The refrigerator operates based on the air temperature measured by the probe located at the return air. COMPONENT OPERATION CONTROLLER ACTION OPERATION CONTROLLER ACTION Compressor turns The Compressor The Compressor... - Page 13 User Manual for WTRF Refrigerator Freezer Beveragae Air REFRIGERATOR SECTION Electronic Controller DEFROST (ESC) SELECT (OK) DOWN Control Panel Display Defrost LED Alarm LED On fixed: Defrost active On fixed: ALARM Present Off: Defrost is off Flashing: ALARM Silenced Off: No Alarm Fan LED Compressor LED...
- Page 14 User Manual for WTRF Refrigerator Freezer Beverage Air 01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 REFRIGERATOR SECTION Beverage Air Rev.
- Page 15 01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 2 2 3 6 2 3 User Manual for WTRF Refrigerator Freezer Beveragae Air REFRIGERATOR SECTION () * + , ÿ . / ÿ 0 1 0 2 3ÿ 4 5 6 1 7 8 9 : ; ÿ < 9 34 8 ÿ 0 2 4 ÿ 9 ; ÿ = 2 : > 2 4 8 8 ÿ ? @A @ÿ / : 1 C 4 2 ÿ : / ÿ < D 4 ÿ = 0 2 0 34 < 4 2 ÿ < 0 E 1 4 F G ÿ < D 4 ÿ 0 1 0 2 3ÿ 9 8 ÿ ; : < ÿ 8 9 > ; 0 1 4 C H Rev.
-
Page 16: Sequence Of Operations - Freezer Section
User Manual for WTRF Refrigerator Freezer Beverage Air User Manual for PFI Freezers Beverage-Air SEQUENCE OF OPERATIONS FREEZER SECTION - DANFOSS CONTROLLER SEQUENCE OF OPERATIONS FREEZER The freezer operates based on the air temperature measured by the probe located at the return air. - Page 17 User Manual for WTRF Refrigerator Freezer Beveragae Air User Manual for PFI Freezers Beverage-Air FREEZER SECTION User Manual for PFI Freezers Beverage-Air Keyboard Functions DEFROST (ESC) DOWN SET (ENTER) Quick press and release Quick press and release Quick press and release Quick press and release •...
- Page 18 01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 User Manual for WTRF Refrigerator Freezer Beverage Air FREEZER SECTION Beverage Air...
- Page 19 01 2 3 ÿ 56 78 6 9 ÿ 3 ÿ ÿ 2 2 3 6 2 3 User Manual for WTRF Refrigerator Freezer Beveragae Air FREEZER SECTION () * + , ÿ . / ÿ 0 1 0 2 3ÿ 4 5 6 1 7 8 9 : ; ÿ < 9 34 8 ÿ 0 2 4 ÿ 9 ; ÿ = 2 : > 2 4 8 8 ÿ ? @A @ÿ / : 1 C 4 2 ÿ : / ÿ < D 4 ÿ = 0 2 0 34 < 4 2 ÿ < 0 E 1 4 F G ÿ < D 4 ÿ 0 1 0 2 3ÿ 9 8 ÿ ; : < ÿ 8 9 > ; 0 1 4 C H Rev.
-
Page 20: Using The Unit With An Eliwell Controller
01 2 3 ÿ 56 78 6 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 User Manual for WTRF Refrigerator Freezer Beverage Air +,- ./ÿ... -
Page 21: Sequence Of Operations - Refrigerator Section
Refrigerator with Eliwell Controller Refrigerator with Eliwell Controller Beverage-Air Beverage-Air User Manual for WTRF Refrigerator Freezer Beveragae Air SEQUENCE OF OPERATIONS REFRIGERATOR SEQUENCE OF OPERATIONS - REFRIGERATOR SECTION - ELIWELL CONTROLLER The refrigerator operates based on the air temperature measured by the probe located at the return air. - Page 22 User Manual for WTRF Refrigerator Freezer Beverage Air 01 2 3 ÿ 56 78 6 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 REFRIGERATOR SECTION Beverage Air Rev.
- Page 23 User Manual for WTRF Refrigerator Freezer Beveragae Air 01 2 3 ÿ 56 7 86 9 ÿ 3 ÿ ÿ 9 ÿ 5 9 ÿ 9 2 3 ÿ 2 2 3 6 2 3 REFRIGERATOR SECTION Rev.
-
Page 24: Cleaning And Maintenance
User Manual for WTRF Refrigerator Freezer Beverage Air CLEANING AND MAINTENANCE Cleaning Schedule: Cabinet Condenser coil Gaskets Daily wipe down Quarterly cleaning Periodic Routine maintenance Weekly interior Annually Daily Exterior Cleaning It is much easier to clean on a regular basis than to have to remove stains once they have built up. 1. -
Page 25: Drawer Cleaning And Maintenance
User Manual for WTRF Refrigerator Freezer Beveragae Air DRAWER CLEANING AND MAINTENANCE Drawer models are shipped with the drawers already installed in the cabinets. Drawers are designed with slides which have locking mechanisms to prevent drawers from coming off cabinets during normal opening and closing operations. See illustration below: Drawers and slides can be removed from a cabinet for cleaning purposes. -
Page 26: Condenser Cleaning
User Manual for WTRF Refrigerator Freezer Beverage Air CONDENSER CLEANING Keeping the condenser coil clean is critical to efficient 6. To reinstall line up the bottom of the panel to the operation. bottom of the unit keeping the screw holes lined up on the panel and on the unit The condenser coil is located behind the front or rear grille of the cabinet. -
Page 27: Methods For Cleaning Stainless Steel
User Manual for WTRF Refrigerator Freezer Beveragae Air METHODS FOR CLEANING STAINLESS STEEL Cleaning Needed Cleaning Agent Method of Application Affect on Finish Satisfactory for use on all Areal 20, Lac-O-Nu, Lumin Wash Rub with cloth as directed finishes. Smears and fingerprints O’Cedar Cream Polish, Stainless on the package. -
Page 28: Help
User Manual for WTRF Refrigerator Freezer Beverage Air HELP Trouble Diagnosis for the User Malfunction Possible Cause Likely Solution Connect to proper voltage circuit Replace Unit not plugged in. fuse or reset breaker. No cooling - unit is silent Fuse or circuit breaker tripped. Check outlet for loose connection, replace Power cord plug loose in outlet. -
Page 29: For The Service Tech - R290
User Manual for WTRF Refrigerator Freezer Beveragae Air FOR THE SERVICE TECH - R290 Refrigeration service should only be attempted by a trained trade professional certified to work on R290 systems. Here are some critical service items. Other Information: This list does not qualify anyone to service the unit. It is a Evacuation: It is critical that a refrigeration system be reminder and checklist for the service tech. -
Page 30: For The Service Tech - Wiring Diagrams Section
User Manual for WTRF Refrigerator Freezer Beverage Air FOR THE SERVICE TECH - WIRING DIAGRAM - REFRIGERATOR SECTION - DANFOSS CONTROLLER CNTRL *SEE CONTROLLER DETAIL CONDENSER FAN CURRENT RELAY COMP *SEE CONTROLLER DETAIL COMPRESSOR DETAIL (115V 1PH) EVAP FANS POWER *SEE CONTROLLER DETAIL SUPPLY *NOT ALL MODELS*... - Page 31 10/26/2020 2020E-0619 DRAWING IS THE SOLE PROPERTY OF S.C. COMP DANFOSS CONTROLLER DETAIL R.C. BEVERAGE-AIR CORPORATION. ANY E CONTROLLER DETAIL REPRODUCTION IN PART OR AS A REMOVED OPTIONS THAT DON'T COMPLY WITH HC 12/5/2019 2019E-1063 ENGINEE WHOLE WITHOUT THE WRITTEN...
- Page 32 User Manual for WTRF Refrigerator Freezer Beverage Air FOR THE SERVICE TECH - WIRING DIAGRAM - REFRIGERATOR SECTION - < ELIWELL CONTROLLER 38 44ÿ 3884ÿ4392 8 44ÿ9 43ÿ489 44ÿ 3884ÿ4392 8 4ÿ4392 8ÿ 6 6 5 ÿ6 1 44ÿ 3884ÿ4392 8 3ÿ988ÿ48 4 9 ÿ9 04 44ÿ 3884ÿ4392 8 8...
-
Page 33: Limited Warranty
(87) months from the date of defective. shipment from Beverage-Air, provided upon receipt of the The labor warranty shall be for self-contained units compressor, manufacturer examination shows the sealed only and for standard straight time, which is defined as compressor to be defective. -
Page 34: Limited Warranty (Continued)
With the exception of Blast Chillers product is designed for LIMITATION OF LIABILITY: maintaining temperature and not bringing food to a desired Beverage-Air Corporation or their affiliates shall not be temperature therefore cannot be held responsible for this liable for any indirect, incidental, special or consequential function under warranty. - Page 35 User Manual for WTRF Refrigerator Freezer Beverage Air Warranty Registration Register your product online at Beverage Air.com/parts-service or fill out and mail the form below. Cabinet Model Number: _____________________________________________ Date Of Installation: _________________ Cabinet Serial Number: _____________________________________________ Location Of Product Business Name: ____________________________________________________ Business Street: ____________________________________________________ Business City: ____________________________________ State: _________ Postal Code:___________...
