R0E556100CFK00
Converter Board for Connecting RX610 Group 144-pin 0.5mm pitch LQFP
1. Outline
The R0E556100CFK00 is a converter board for connecting the
flexible cable R0E001000FLX10 to a foot pattern for 144-pin
0.5mm pitch LQFP (PLQP0144KA-A).
2. Package Components
Check to see if the R0E556100CFK00 package has all the
following contents before using this product.
(1) R0E556100CFK00 converter board ............................ 1 pc.
(2) YQPACK144SD
(made by Tokyo Eletech Corporation)
(3) NQPACK144SD-ND
(made by Tokyo Eletech Corporation)
(4) YQ-GUIDE
(made by Tokyo Eletech Corporation)
(5) R0E556100CFK00 User's Manual (this manual)
3. Specifications
Table 1 Specifications
Applicable package
Insertion/removal
iterations of connector
4. Usage (See Figure 2)
The R0E556100CFK00 can be used for debugging and
on-board
evaluation
in
NQPACK144SD-ND on the user system.
(1) For debugging
Mount the NQPACK144SD-ND on the foot pattern of the
user system and attach the YQPACK144SD on it. In
addition,
connect
YQPACK144SD, and then connect the flexible cable
R0E001000FLX10 of the emulator to the upper connector
of the R0E556100CFK00.
(2) For on-board evaluation
Mount an MCU with on-chip flash memory or one-time
PROM and the HQPACK144SD (not included) in order
on the NQPACK144SD-ND on the user system.
Before using the R0E556100CFK00, be sure to read the
precautions on page 3.
* NQPACK, YQPACK, YQSOCKET, YQ-GUIDE, HQPACK, TQPACK, TQSOCKET, CSSOCKET, CSPLUG/W and
LSPACK are trademarks of Tokyo Eletech Corporation.
REJ10J2088-0200 Rev.2.00
Apr 16, 2010
(See Figure 1)
................ 1 pc.
....... 1 pc.
.....................4 pcs.
PLQP0144KA-A
(144-pin 0.5mm pitch LQFP)
50 times guaranteed
common
by
mounting
the
R0E556100CFK00
R0E556100CFK00
converter board
YQ -GUIDE (×4)
Figure 1 Package components of the R0E556100CFK00
(1)For debugging
the
to
the
●:No.1 pin
Be sure to align the pins.
Figure 2 Usage of the R0E556100CFK00
User's Manual
REJ10J2088-0200
Apr 16, 2010
YQPACK144SD
NQPACK144SD-ND
Flexible cable
R0E001000FLX10
(2)For on-board
evaluation
R0E556100CFK00
HQPACK144SD
(not included)
YQ-GUIDE(×4)
YQPACK144SD
FLASH MCU, etc.
NQPACK144SD-ND
144-pin 0.5mm pitch
(PLQP0144KA-A) foot pattern
Page 1 of 4
Rev.2.00
