Environmental Specifications; Regulatory Specifications - Compaq 8-EL Quickspecs

QuickSpecs
E
N V I R O N M E N T A L
Features
Temperature
Humidity
Altitude
Shock
Vibration
R S
E G U L A T O R Y P E C I F I C A T I O N S
Safety
EMI
Immunity
© 2002 Compaq Information Technologies Group, LP.
Compaq, the Compaq logo, CarePaq, and StorageWorks are trademarks of Compaq Information Technologies Group, L.P. in the U.S. and/or other countries.
All other product names mentioned herein may be trademarks of their respective companies.
Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information is provided "as is" without warranty of any kind and
is subject to change without notice. The warranties for Compaq products are set forth in the express limited warranty statements accompanying such
products. Nothing herein should be construed as constituting an additional warranty.
DA-10647 North America — Version 7 — March 21, 2002
S
P E C I F I C A T I O N S
Operating Range
50 to 104 F/10 to 40 C
5% to 85% non-condensing @ 104 F/40 C
0 to 9,842.5 ft/0 to 3 kilometers above sea level
4g, 11 ms duration, half sine
0 to 3KHz
UL Standard 1950, 3rd Edition
FCC Rules & Regulations, Part 15B, Class A level
CISPR22 Class A
EN55022 Class A
VCCI Class A ITE
AS/NZS 3548 Class A
IEC 801-2 (IE: IEC 1000-4-2), Severity Level 3 for ESD
IEC 801-3 (IE: IEC 1000-4-3), Severity Level 3 for Radiated Fields
IEC 801-4 (IE: IEC 1000-4-4), Severity Level 3 for Fast Transients
IEC 801-5 (IE: IEC 1000-4-5), Severity Level 3 for Surge Voltage
IEC 801-6 (IE: IEC 1000-4-6), Conducted Emissions
StorageWorks Fibre Channel
SAN Switch 8-EL by Compaq
6
