Condensing wall mounted boiler
MURELLE HE 110 R I - 110 R E
 INSTALLATION AND SERVICE INSTRUCTIONS
EN
Gas Safety Certificate AS/NZS 5263.1.2 LN: SAI-400271
CAUTION
This product must be installed exclusively by professionally qualified personnel in accordan-
ce with the requirements of the standards AS/NZS 5601, AS/NZS 3500, AS/NZS 3000 (current
version) of the local gas, electricity authorities and other relevant legislation.
Fonderie SIME S.p.A
Cod. 6322972B - 09/2018
