7.0 Compaq AlphaServer GS320 Environmental Information
7.1 Compaq AlphaServer GS320 Physical Information
GS320 enclosure
Width
Depth
Height
Weight
Expander Cabinet
Width
Depth
Height
Weight
Note: The GS320 system is comprised of one H9A21-AA and one H9A21-AB cabinet bolted together with a width
of 55". The Power cabinet H9A20-BA has a width of 23.5".
System Dimensions
2000 mm (78.7 in)
1000 mm (39.4 in)
1700 mm (66.9 in.)
850 kg
(1870 lb)
600 mm
(23.6 in)
1000 mm (39.4 in)
1700 mm (66.9 in)
613 kg
(1349 lb)
23
