Outdoor living today 8x4 SpaceSaver Garden Shed Assembly Manual

Hide thumbs Also See for 8x4 SpaceSaver Garden Shed:

Advertisement

Quick Links

Thank you for purchasing
a 8x4 SpaceSaver Garden
Shed. Please take the time
to identify all the parts prior
to assembly.
Safety Points and Other Considerations
Our products are built for use based on
proper installation and normal residential
use, on level ground. Please follow the
instruction manual when building your
shed and retain the manual for future
maintenance purposes.
Some of the safety and usage measures you may wish to consider include:
-snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to
sweep the snow off the roof(s).
-if the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
-in high or gusty wind conditions it is advisable to keep the structure securely grounded.
-have a regular maintenance plan to ensure screws, doors, windows and parts are tight.
Customer agrees to hold Outdoor Living Today Partnership and any Authorized Dealers
free of any liability for improper installation, maintenance and repair.
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Outdoor Living Today
www.outdoorlivingtoday.com
Page 1
8x4 SpaceSaver
Garden Shed
Assembly Manual
Revision #5
Oct 3, 2008
sales@outdoorlivingtoday.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 8x4 SpaceSaver Garden Shed and is the answer not in the manual?

Questions and answers

Summary of Contents for Outdoor living today 8x4 SpaceSaver Garden Shed

  • Page 1 Customer agrees to hold Outdoor Living Today Partnership and any Authorized Dealers free of any liability for improper installation, maintenance and repair. In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase.
  • Page 2 Thank you for purchasing our 8x4 SpaceSaver Garden Shed. Please take the time to identify all the parts prior to assembly. Parts List: D. Miscellaneous Section (Skirting, Facia ,Trim & Misc. Parts A. Floor Section 2 - ½” x 4” x 54 1/8” Side Angle Cut Facia 1 - 45 ½”...
  • Page 3 When correctly positioned, attach each Joist with 4 - 2 1/2” screws (2 per end). If door location to be on left, position Small Floor Joist Frame to right. Reverse if opposite. You can find the Square Drive Bit for the screws in with the Hardware Kit Bag. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 4 Choosing a foundation will vary between regions. Typical foundations can be concrete pads or patio stones positioned underneath the floor runners. Position Plywood Floor pieces (2) on top of When in place, level floor completely completed floor joists. before proceeding. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 4...
  • Page 5 Wall Plate Locate 4 Solid Wall Panels and 4 Wall Plates. Attach Plates to bottom of wall studs of each wall panel with 3 - 2 1/2” screws. Position so plates are flush with framing. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 6 Butt both vertical wall studs of side and rear walls together and attach with 3 - 2.5” screws. Screw at the bottom, middle and top of stud to secure properly. Note, drill pilot holes in studs to prevent splitting. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 7 With Rear Wall Panel in place, position other side wall panel on floor as per Step 10 & 11. Secure side wall panel to rear wall panel as per Step 12. Next, locate Window Wall Panel and place in front corner. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 8 Note, Narrow Wall Panel is only 73” high. Door Jamb Secure as per Step 12. Locate 3” wide Door Jamb and place on wall stud to the right where door to be located. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 8...
  • Page 9 3 - 2 1/2” screws. Lap Siding of panels will fit together. Locate a Angled Wall Extendor and place on side wall panel frame. Note, lap siding of Wall Extendor will cover lap siding of side wall. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 9...
  • Page 10 With Angled Wall Extendor and Side Wall aligned correctly, secure together from the inside with 4 - 2 1/2” screws. Complete opposite Angled Wall Extendor positioning and attachment as per Step 23 & 24. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 10...
  • Page 11 With 2x3 wall framing aligned, attach Wall Extendor to both the Angled Wall Extendor framing and the rear wall framing with 5 - 2 1/2” screws. Position and secure 2nd Wall Extendor Panel as per Steps 26 & 27. Attach together with 2 - 2 1/2” screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 11...
  • Page 12 Identify all parts prior to starting. 6” Wide Filler Shingles not shown in Illustration. Left Roof Panel Right Roof Simpson Strong Panel Ties (8) Rear Soffit (2) 3” wide Front Soffit (2) 4” wide Rafter (5) Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 12...
  • Page 13 Important- Drill pilot holes in Soffit ends to prevent splitting. Measure and attach interior Rafters as illustrated below in (B). Measure and attach remaining Soffit / Rafter connections using 2 -1 1/4” screws per rafter/soffit. See Illustration (C). Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 13...
  • Page 14 Front and Rear Soffits are flush against both front and back walls. 3” wide Soffit 4” wide Soffit When Rafter Section is positioned correctly, both Front and Rear Soffits will sit flush against siding of wall panels. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 14...
  • Page 15 Correctly orientate Left Side Roof Panel with shingles overhanging roof battens on the outside left and shingles flush with battens to the right. Place on rafters with front roof batten flush with front of rafter. Note, trimmed shingles on roof panel to back of shed. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 16 Roof Filler Shingles are included to cover roof seams. Starting at the bottom, slide the first Long shingle in until flush with other bottom shingles. Screw first filler shingle down to rafters using 1 - 2 1/2” screw per panel (2 in total). Make sure to screw into both rafters. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 17 To further secure roof panels, from the inside, drill pilot holes in each Mid Rafters (3 per Rafter) on an angle. Using 3 - 2 1/2” screws, secure rafters to roof battens. Note, from outside, push roof panel down so batten sit flush against rafter when securing. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 18: Table Of Contents

    Note, Corner Trim will cover screws in Steps 53 & 54. Drill pilot holes in siding to prevent splitting. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 19 Locate Corner Filler Trims (2 - 1/2” x 2 1/2” x 75”) support since it will be a high traffic area. and place in front corners of SpaceSaver. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 19...
  • Page 20 Locate Vertical Door Trim - (2 - 1/2” x 2 1/2” x 78 3/4”). Position left door trim flush with outside narrow wall stud. Trim should also be aligned flush with bottom skirting. Attach with 8 - 1 1/4” finishing nails. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 21: Front Side

    To completely trim out rear corners, locate Rear Trim -1/2” x 2 1/2” x 88 3/4” and a Rear Corner Trim - 1/2” x 4 1/2” x 88 3/4”. Align and attach as per Step 54. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 22 The # of screw holes in the hinge may vary from three to four depending on model. Attach Door Hinges to Door Panel trim. Position Hinges equally on door trim as shown above and attach with Black 3/4” and 2” screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 22...
  • Page 23: Skirting

    Locate and identify all Facia pieces. Front Facia is 4” wide while Rear Facia is 4 1/2” wide. Side Angle Cut Facia is angle cut on both ends. In front corner, align side and front Facia together. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 24 Position Roof Ridge Boards at the rear of roof to cap off shingles and facia. Ridge Board should meet on seam of roof panel. When aligned correctly, attach with 3 - 2 1/2” screws. Screw into outside, mid and center rafter. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 25: Roof Ridge Boards

    Attach Interior Door Stops to door framing from inside of shed. Start by securing both Vertical Door Stops. Use Horizontal Door Stop to help determine distance between vertical stops. See Step 70 for detail. Use 4 - 2” screws to secure each Stop. Stops should overlap door by approx. 1/2”. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 26 4 - 1 1/4” finishing nails . Attach Flower Box below bottom of window trim with 2 - 2” screws. Screw from inside of box into the center wall stud. Attach second screw 2” below top screw. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 27 Follow sequential Steps 11-15 in the wall section for regular configuration to position and secure wall panels. Door Jamb With walls positioned and attached together, locate Door Jamb and orientate on wall stud. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 27...
  • Page 28: Trim

    Vertical Door Stop. Cut to 8” and 32” Attach 1 Vertical and Horizontal Door Stop. lengths. Cut the Optional Door Trim down to See Step 69 for detail. 80” and attach as per Step 57. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 28...
  • Page 29 Please call, write or email us at: contained on the materials. No material may be Outdoor Living Today Partnership modified, edited or taken out of context such that its use creates a false or misleading statement or P.O.
