- Page 1 ASSEMBLY MANUAL 9x9 Penthouse Garden Shed Stock Code: PEN99-CEDAR PENN99-PLY Version #21.4 March 24, 2025...
-
Page 2: What You Need To Know
Failure to use supplied parts included in this kit could result in poor product performance and may void your warranty. Please contact Outdoor Living Today’s Customer Toll Free Line if you plan to deviate from our written instructions. Warranty Customer agrees to hold Outdoor Living Today and any Authorized Dealers free of any liability for improper installation, maintenance and repair. - Page 3 You can find the footprint for your shed on Page 3 of your Assembly Manual. If doing the assembly yourself, have all the necessary tools ready to go and in working condition. A list of required tools can be found after the parts list. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 3...
-
Page 4: Wall Section
Note: All Trim and Skirting pieces are graded best face rough. This means the rough side will be exposed when completing these Sections. Important: If painting or staining your shed, refer to Step 88 to remove window from door to treat before assembly. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com... - Page 5 Cane Bolt Bracket (28) Tools Required (Not Provided) Hammer Wood Clamp Utility Knife Tape Measure Screw Gun/Drill Pliers 1/8” & 9/16” Drill Bits Ladder Level Safety Equipment Required (Not Provided) Safety Glasses Work Gloves Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 5...
-
Page 6: Floor Section
78 1/2” Lay out perimeter pieces for Triangular Floor Section. Attach in each corner with 2 - 2 1/2” screws. When attached together, the perimeter will be 55 1/2” x 55 1/2” x 78 1/2”. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com... - Page 7 2 - 2 1/2” screws per end. Attach Rectangular Section Lay out completed Floor Joist together with 6 - 2 1/2” screws per Frame Sections as illustrated above. section. Complete all Rectangular Sections as per Step A5. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 7...
- Page 8 Position on center 27 3/4” from outside edge and attach as per Step A8. Place 3rd set of Runners on center Joists. Short Runner is angle cut on front end. Attach as per Step A8. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 9 27 5/8” A12. Position Plywood Floor pieces (6) on top of completed floor joists. Push Plywood Floor pieces together at seams. Plywood will sit slightly recessed from edge of Floor Frame. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 9...
-
Page 10: Table Of Contents
Rear Top Wall Plate (4) Wall Plate (2) Front Top Wall Plate Solid Wall Door Header Panel (6) Corner Post (3) Window Insert (2) Window Wall (2) Narrow Wall (2) Front Corner Post (2) Door Jamb (2) Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 10... - Page 11 Do Not Attach Walls To Floor Until Step B21. Position second Solid Wall corner panel to Post and secure as per Step B2. Important: Do Not Attach Walls To Floor at this stage. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 11...
- Page 12 Complete both rear walls. Lift and position a Corner Post to end of outside rear wall panel. Post will overhang floor by 1/2” Position and secure Corner Post to rear wall stud as per Step B2. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 12...
- Page 13 Position and secure Corner Post to rear wall stud as per Step B2. Locate a Window Wall Panel. Position and attach wall stud to Corner Post as per Step B2. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 13...
- Page 14 Place a Front Corner Post against an outside Window Wall Stud with the tip of the wedge flush to the inside. Attach with 3 - 2 1/2” screws at top, middle and bottom locations. Complete both sides. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 15 Locate Vertical Door Jambs and position flush against left Narrow Wall Panel stud. The Jamb is 3 1/8” wide and will sit flush to outside of wall siding. When positioned correctly, secure both Jambs using 4 - 2.5” screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
-
Page 16: Wall Plate
Locate 2x3 Rear Wall Plates (55 1/2” long with 45 degree cut at 1 end). Position in rear corner and secure each plate with 4 - 2 1/2 screws. B18. Position and attach remaining Rear Wall Plates as per Step B17. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 16... - Page 17 4 - 2 1/2” screws per wall panel. Optional - Caulking seams will help prevent moisture from entering at seam. Caulking not included in kit. Doorway Opening 49 3/4” Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 17...
- Page 18 Locate Hip Rafters with Cleat (90 9/16” long) and Core Block. On the ground, angle screw end of Hip Rafter to Core Block with 1 - 3” long Screw. Drill 1/8” diameter pilot hole in rafter to prevent splitting. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 19 Rafter to prevent splitting. Be careful to support both Rafters. Attach the Final Hip Rafter at 90 degrees to other rafters as per Step C1. Once again, drill pilot hole to prevent splitting. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 19...
- Page 20 24” long Support Cleat with 2 - 2 1/2” screws. Flip over and attach a 2nd Cleat. Screw Plywood Base - 5 1/2” x 5 1/2” to bottom of Support Beam with 2 - 1 1/2” screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 20...
- Page 21 Top Plates. With a 90° Metal Bracket, tack rafter into position using 2 - 1 1/4” screws. (When main rafters are all aligned correctly, go back and completely secure rafter using 2 - 90° Metal Brackets and 4 - 1 1/4” screws.) Complete all Hip Rafters. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 22 Equally space from side to side Mid Rafter on Rear Top Plates on walls. Align rafter so seat cut is 1/8” past the outside of the Top Plate. When positioned correctly, secure with 2 - 90° Metal Brackets and 8 - 1 1/4” screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 23 Use Front and Side Facia to assist in positioning 2nd Front Hip Rafter. If rafter is out of alignment, reposition 1st Front Hip Rafter until both rafters are reasonably aligned. When satis- fied with position of both rafters, secure each with 1 - 90° Metal Bracket and 4 - 1 1/4” screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 24 Complete both Left and Right Corner Rafters, aligning and attaching as per Step C16. Secure with 2 - 90° Metal Brackets and 8 - 1 1/4” screws per rafter. C18. Complete remaining Corner Rafter sets, aligning and attaching as per Steps C16 - C17. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 24...
- Page 25 Wall Plate with 4 - 1 1/4” screws. C21. Complete attachment of remaining Front Wall Soffit. Locate 12 Side and Rear Soffits (28”Long). Follow Step C19 to measure and cut to fit, to complete Soffit Section. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 25...
- Page 26 Front and previous Side Facia equally on rafter ends and secure completely with 6 - finishing nails per piece. Important: gaps occurring in corners will be covered by Decorative Detail Facia Plates installed in Step E. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 27 Rafter once again and attach with 6 - Finishing nails per piece. equally spaced on Rear Mid Rafter. C26. Complete 2nd Rear Side Facia as per Step C25. C27. Complete remaining Rear Side Facia pieces as per Steps C25 - C26. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 27...
- Page 28 Only with 1 - 2 1/2” screw. Screw from shingle into rafter. Important: later in Step D7 Roof Panels may need to be slightly re-positioned and will be completely secured to rafters at that point. Position Right Front Roof Panel in place. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 29 Screws will be covered by Ridge Caps in Step E11. Facia and Soffit not shown. Place Right Side Roof Panel on Front Hip Rafter and align and attach as per Step D3. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 29...
- Page 30 Roof Panels may need to be slightly re-positioned. If so, loosen panel and re-attach when satisfied with position. Use 3 - 2 1/2” screws per panel on all Hip Rafters. (Do not attach Roof Panels to Mid Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 31 2 - 1 1/2” shingle nails per shingle. NOTE: The rear panels require 5 - long Filler Shingles and 1 - 14” to complete. The Front Roofs will require 4 - Long Filler and 1 - 11” Filler Shingle to complete. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 31...
-
Page 32: Panel
When correctly aligned, secure panel to Front Mid Rafter using Only 2 - 1 1/4” Screws. Important: later in Step 69 Roof Panels may need to be slightly re-positioned and will be completely secured to rafters at that point. Position Right Front Roof Panel (#2) in place. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com... - Page 33 Screw Roof Panel down with 2 - 1 1/4” Screws in bottom at each corner. Make sure to screw into Rafters. Facia and Soffit not shown. Place Right Side Roof Panel (#4) on Front Hip Rafter and align and attach as per Step D3. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 33...
- Page 34 Roof Panels may need to be slightly re-positioned. If so, loosen panel and re-attach when satisfied with position. Use an additional 4 - 1 1/4” Screws per panel to completely secure each panel. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 34...
- Page 35 3 - 1 1/4” Screws per panel. D10. Once all plywood roof panels are secured, you should attach roofing paper to cover plywood completely. Please following the roofing material suggestions on how to install correctly. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 35...
-
Page 36: Miscellaneous Section
Rear and Side Skirting pieces first, The rear skirting pieces will meet where walls come together. Attach with 4 - 1 1/2” finishing nails per piece. Complete all rear wall pieces. Position Side Skirting piece in place. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com... - Page 37 2 - finishing nails. Place wider trim on side wall flush to outside of narrow trim. When properly positioned, secure with 8 - finishing nails per piece. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 38 Locate 4 Rear Wall Seam Trim (2 1/2” wide). Place equally on rear wall seams and attach with 8 - finishing nails. Locate both Front Corner “V” Shaped Trims. Place over corners in front and attach each with 8 - finishing nails. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 38...
-
Page 39: Door Jamb
Ridge Cap. Attach above 9” exposure line with 2 shingle nails. Place 3rd Ridge Cap on roof seam. Start the 3rd Ridge Cap approx 8” from bottom of 2nd Ridge cap and attach with 2 shingle nails above the exposure line. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com... - Page 40 Complete attaching Ridge Caps to all corner roof seams as per Step E8 - E9. Place Roof Peak Cap on top center of shed. E12. Center and secure Roof Peak Cap with 5 - 3” screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 40...
- Page 41 4 - 1 1/4” screws. Align Vertical Door Stop to inside of wall framing and attach with 4 - 1 1/4” screws. Complete both sides. (Prior to completing, check Step E15 for best fit). Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 42 Remove screw from top and bottom of window frame to detach window. Once treated you can return the window into the door and replace the screw. Important: When reinstalling the window, ensure the Mullion is facing outside your shed. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 43 Using 2” black screws, secure hinges to Door Trim. Hint: Do not attach all the 2” screws until both doors are positioned correctly. Use Screw Driver to tighten screws completely. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 44 1/2” bit. Attach with Black 1” Screws Drill 1/2” Diameter Important: Drill 1/8” pilot holes Hole to accommodate to prevent wood from splitting. rod of Cane Bolt. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 44...
- Page 45 The window kit trim pack = 1x 24 1/16” = top / 3 x 23”= sides and bottom. Window trim has a small dado on reverse face. Outside flange of window will roughly sit in the dado to give a better fit. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 46 2 - 2 1/2” screws. Screw from inside of box into the center wall stud. Attach second screw 2” under- neath first screw and once again into the wall stud. Install Flower Box Kits underneath each window. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 46...
- Page 47 Outdoor Living Today Flower Box Assembly Instructions Exploded Side Trims (D) View Front Trim (C) End Caps (B) 1 1/4” Parts Lists: Nails (G) A - Base, Rear & Front Box Frames (3pcs) 3/4” x 5 1/2” x 23” B - End Cap Frames (2pcs) 3/4”...
- Page 48 Please call, write or email us at: Canadian Address United States Address 9393 287th Street P.O. Box 96 Maple Ridge, British Columbia Sumas, Washington Canada V2W 1L1 98295 Toll Line: 1.888.658.1658 Fax: 1.604.462.5333 sales@outdoorlivingtoday.com Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 48...
