Outdoor living today 8x4 SpaceSaver Garden Shed Assembly Manual

Double door
Hide thumbs Also See for 8x4 SpaceSaver Garden Shed:

Advertisement

Available languages

Available languages

Quick Links

Download this manual
Thank you for purchasing
a 8x4 SpaceSaver Garden
Shed. Please take the time
to identify all the parts prior
to assembly.
Safety Points and Other Considerations
Our products are built for use based on
proper installation and normal residential
use, on level ground. Please follow the
instruction manual when building your
shed and retain the manual for future
maintenance purposes.
Some of the safety and usage measures you may wish to consider include:
-snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to
sweep the snow off the roof(s).
-if the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
-in high or gusty wind conditions it is advisable to keep the structure securely grounded.
-have a regular maintenance plan to ensure screws, doors, windows and parts are tight.
Customer agrees to hold Outdoor Living Today Partnership and any Authorized Dealers
free of any liability for improper installation, maintenance and repair.
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Outdoor Living Today
8x4 SpaceSaver Garden
www.outdoorlivingtoday.com
Page 1
Shed - Double Door
Assembly Manual
Revision #9
Feb. 23, 2009
sales@outdoorlivingtoday.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 8x4 SpaceSaver Garden Shed and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Outdoor living today 8x4 SpaceSaver Garden Shed

Summary of Contents for Outdoor living today 8x4 SpaceSaver Garden Shed

  • Page 1 Customer agrees to hold Outdoor Living Today Partnership and any Authorized Dealers free of any liability for improper installation, maintenance and repair. In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase.
  • Page 2 Thank you for purchasing our 8x4 SpaceSaver Garden Shed. Please take the time to identify all the parts prior to assembly. Parts List: C. Rafter & Roof Section 2 - Roof Panels 51 ½” x 55 ¾” (1-Left 1- Right ) A.
  • Page 3 8x4 SPACESAVER DD HARDWARE PACKAGE Hardware Kit (Provided) Note: screws and nails shown actual size. 2 1/2” 3/4” Black 2” 1 1/4” Finishing 1 1/4” 2” Square Drive Bit Black Tee Hinge x 6 Door Handle x 2 Barrel Bolt Simpson Strong Cane Bolt Tie x 8...

  • Page 4: Floor Section

    A. Floor Section Exploded view of all parts necessary to complete Floor Section. Identify all parts prior to starting. Note, Floor Footprint is 96” wide x 45 1/2” deep. Exploded Floor Section Plywood Floor Floor Joists (2) Small Floor Joist Frame Large Floor Joist Frame Floor Runners (5)
  • Page 5 4th Runner Flush with Floor Framing Position and attach Floor Runners to completed floor With Floor Joist Frames positioned frames with 6 - 2 1/2” screws per Runner . Make sure together flush, attach with 6 - 2 1/2” Runners are flush with outside and front and rear floor screws.
  • Page 6 Plywood is cut slightly smaller than floor framing. Keep plywood seams tight. Position Plywood so it sits flush with outside of floor joist framing. When correctly positioned, attach to all floor joists with 1 1/4” screws. Use screws every 16”. B.
  • Page 7 Starting on Side, position a Solid Wall Panel on top of plywood floor. The Wall Panel bottom framing will sit flush with plywood. Wall siding will over- hang the floor. Important: Make sure all walls are aligned in their upright position.
  • Page 8 With the corner wall attachment complete, position the second rear wall panel in place so bottom 2x3 wall framing is sitting flush with outside floor joists and plywood floor. Wall siding should overhang floor by approximately 1/2”. When positioned correctly, attach both wall panel studs together as per Step 12 with 3 - 2 1/2”...
  • Page 9 2x3 wall plate flush with plywood floor. When correctly positioned, secure Narrow Wall Once again position the 2x3 wall plate so Studs to Side Wall Stud with 3 - 2 1/2” screws. it sits flush on floor and siding overhangs. Note, Narrow Wall Panel is only 73”...
  • Page 10 Push Locate Door Header - Long (Dado Cut on edge facing out). Attach using 2 - 2 1/2” screws per end. Screw from top down into wall framing. Once again, align with inside of wall framing and other Door Headers. Hint- Push Side Wall to close any gaps between Headers. Locate both Vertical Door Jambs and position flush against front narrow wall stud.
  • Page 11 Extendor Framing overhangs Wall Framing by 1/2” Siding lines up Slight Gap Align siding of Angled Wall Extendor and Side Wall so they are flush. Note, When correctly aligned, vertical rear framing of Angled Gable Wall will overhang Side Wall framing by approx.
  • Page 12 Lap siding of Extension Wall Lap Siding of rear wall. Locate one Wall Extendor and place on rear wall panel with lap siding of extendor overlapping that of the rear wall. With 2x3 wall framing aligned, attach Wall Extendor to both the Angled Wall Extendor framing and the rear wall framing with 5 - 2 1/2”...
  • Page 13 Attach Horizontal Wall Cleats to Wall Extendor bottom framing and rear wall top framing so cleat is flush with extendor framing. There is a short and long wall cleat. Alternate alignment of screws so 1/2 screw into wall extendor framing and the other land in the rear wall top framing. Use 8 - 2” screws. To complete Wall Section, attach bottom 2x3 Confirm Doorway...
  • Page 14 3” wide Rear Soffit Board (2) 96” Mid Rafter Mid Rafter 22 1/8” 48” Centered on Rafter 22 1/8” Front 3” wide Soffit 4” wide Front Soffit Board (2) Confirm Rafter angle Locate 5 Rafters, 2 Front 4” wide Soffits and 2 Rear 3” wide Soffits. Lay out on level ground as shown in Illustration (A) below.
  • Page 15 Carefully flip completed Rafter Section over so 4” wide Soffit is facing the front and place on SpaceSaver walls. Note, once again, make sure 4” wide Soffit is positioned to the front of the shed. Position Rafter Section on walls so outside Rafters lay flush with gable framing equally from side to side and both Front and Rear Soffits are flush against both front and back walls.
  • Page 16 Simpson Strong Tie Connectors With Rafter Section correctly aligned, secure rafters to walls using Simpson Strong Tie Connectors. Start with outside rafters and secure 2- strong ties with 1 1/4” screws. Screw into Wall Extension Framing at the rear and the Wall Panel top framing at the front. Complete both sides. With outside rafters properly secured, completely secure remaining interior rafters using 3 - 2 1/2”...
  • Page 17 Roof Panel centered on rafter. For correct Roof Panel position, align panel so roof batten sits evenly on center Rafter. Complete both roof Panels Roof Seam With Roof Panel aligned, screw panels down to center rafter with 2 - 2.5” screws in the bottom row of shingles.
  • Page 18 Slide in another Long Filler Shingle and attach as per Step 40. On your last row of shingles, the Filler Shingle is precut to fit properly. Attach to roof with 2 -1 1/4” finishing nails. Strong Ties Secure roof panels to walls at both ends by positioning 2 Simpson Strong Ties on battens and outside rafters and securing with 4 - 1 1/4”...

  • Page 19: Miscellaneous Section

    D. Miscellaneous Section Exploded view of all parts necessary to complete the Skirting, Trim, Facia and all Miscellaneous Pieces. Identify all parts prior to starting. ( Not Shown; Door Stops, Flange, Threshold, Rear Trim, Horizontal Door Trim) Roof Ridge Boards (2) Rear Facia (2) Facia Detail Plate...
  • Page 20 Skirting meets flush in center Rear skirting pieces will meet together in the center. Secure with 4 - 1 1/4” finishing nails per piece. Insert additional screws into siding as per Step 44. Gaps on outside will be covered by Corner Trim pieces later. Complete front and side skirting attachments.
  • Page 21 Attach Corner Filler Trims where gaps exist in front corners. Hammer with 8 - 1 1/4” finishing nails. Corner Fillers are positioned flush with siding and to the top of the bottom skirting. Angled Extendor Wall Corner Filler Trim Position and attach Corner Filler Trims in the rear as per Step 49. Flush with Narrow Wall stud.
  • Page 22 Horizontal Narrow Wall Trim Horizontal Door Trim Right Side Flush with Door Trim. Door Jamb To trim out door, locate both Horizontal Narrow Wall Trims (9 1/2” long) and the Horizontal Door Position Right Side Door Trim flush with Trim (64” long). Position as shown above and attach inside of Door Jamb.
  • Page 23 Attach Middle Trim - 1/2” x 2 1/2” x 88 3/4” where wall panels come together and leave a seam in the rear. Attach with 8 - 1 1/4” finishing nails aligning flush with bottom skirting. 2“ Screws Attach Black Tee 3/4”...
  • Page 24 2” Black Screws Important- Drill Pilot Holes 3/8” on to prevent side. splitting 1/2” gap at bottom. Bottom of Door Next, position and secure the Double Doors. Starting with Right Side Door, position so there is a 1/2” gap on bottom and approximately 3/8”...
  • Page 25 With Side Angle Cut Facia correctly aligned, attach Front Facia to rafter ends with 6 - 1 1/4” finishing nails per piece. Attach Side Angle Cut Facia to batten ends with 4 - 1 1/4” nails. Attach next piece of Front Facia. Align Facia in corner as per Step 62. Note, with Front Facia correctly aligned, a small gap may occur where they meet.
  • Page 26 Attach Top Horizontal and Vertical Interior Complete both Roof Ridge Boards Door Stops to door header and jambs. Start with horizontal Stop first centering over doorway and then complete both vertical stops. Use 4 - 2” screws per piece to secure. Close both doors and align so doors are straight.
  • Page 27 Drill 9/16” Diameter Hole The Interior Cane Bolt will be attached to Vertical Door Flange. To to accommodate rod of position Cane Bolt correctly, attach to flange first, close doors and mark Cane Bolt. hole to house Cane Bolt Rod. Open doors and drill hole where previously marked with 9/16”...
  • Page 28 Please call, write or email us at: Outdoor Living Today Partnership P.O. Box 96 Sumas, Washington 98295 Toll Line: 1.888.658.1658...
  • Page 29 8x4 SpaceSaver Garden Shed - Double Door Manuel d'Assemblée Revision #3 Feb 2008 Merci pour acheter un 8x4 SpaceSaver Garden Shed. S'il vous plaît prendre le temps pour identifier toutes les parties avant l'assemblée. S'il vous plaît les Lunettes de Sûreté...
  • Page 30 Merci pour acheter notre 8x4 SpaceSaver Garden Shed. S'il vous plaît pren- dre le temps pour identifier toutes les parties avant l'assemblée. Parts List: D. Miscellaneous Section (Skirting, Facia ,Trim & Misc. Parts A. Floor Section 2 - ½” x 4” x 54 1/8” Side Angle Cut Facia 1 - 45 ½”...
  • Page 31 Frame comme un gabarit pour déterminer la position de solive. Disposer la Solive si éclat avec l'en- cadrement. Small Floor Joist Frame Door Location. Quand correctement disposé, attacher chaque Solive avec 4 - 2 1/2” vis (2 par la fin). Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 3...
  • Page 32 Disposer les morceaux de Plywood Floor (2) Quand à sa place, niveler le plancher sur les solives de plancher complétées. complètement avant le procédé. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 4...
  • Page 33 Localiser 4 Solid Wall Panels et 4 Wall Plates. Attacher des Plaques pour der de clous de mur de chaque panneau de mur avec 6 - 2 1/2” vis. Disposer si des plaques sont au ras de l'encadrement. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 34 Le bout les deux clous de mur verticaux de murs de côté et arrière et attache ensemble avec 3 - 2,5” vis. La vis au fond, le milieu et le sommet de clou pour obtenir convenablement. Note: entraîner les trous de pilote dans les clous pour empêcher la répartition. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 35 10 & 11. Obtenir le panneau latéral de mur au panneau de mur postérieur comme par l'Etape 12. Prochain, localiser les Narrow Wall Panels et la position dans le coin de devant. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 36 Localiser les deux En-têtes de Porte - Court (la Coupure de Cimaise sur le revêtement de bord hors). Attacher les deux morceaux de fin courts utilisant 2 - 2 1/2” vis par le morceau. La vis du sommet en bas dans l'encadrement de mur. Aligner à l'intérieur d'encadrement de mur. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 37 Localiser un Angled Wall Extendor et le lieu sur le cadre de panneau de mur latéral. Note, les genoux prennent le parti de mur de Mur-pignon couvrira des genoux prennent le parti de mur latéral. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 38 Avec le Mur de Mur-pignon Incliné et le Mur de Côté a aligné correctement, obtenir ensemble de l'intérieur avec 4 - 2 1/2” vis. Compléter en face d'Extendor Incliné de Mur disposant et l'attachement comme par l'Etape 23 & 24. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 10...
  • Page 39 Incliné encadrant et le mur postérieur encadrant avec 5 - 2 1/2” vis. La position et obtient le deuxième Panneau d'Extendor de Mur comme par les Etapes 26 & 27. Attacher ensemble avec 2 - 2 1/2” vis. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 40 6” Bouche-trou Large Couvre de bardeaux pas montré dans l'Illustration. Les illustrations montrent Config de Porte Seul. Left Roof Panel Right Roof Simpson Strong Panel Ties (14) Rear Soffit (2) 3” wide Front Soffit (2) 4” wide Rafter (5) Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 12...
  • Page 41 Soffite pour empêcher la répartition. La mesure et attache des Chevrons intérieurs comme illustré au dessous dans (B). La mesure et attache restant le Soffite/les connexions de Chevron utilisant 2 -1 1/4” vis par le chevron/soffite. Voir l'Illustration (C). Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 13...
  • Page 42 Postérieurs sont des éclats contre le devant et de retour les murs. 3” wide Soffit 4” wide Soffit Quand la Section de Chevron est correctement disposé, le Devant et les Soffites Postérieurs assiéront l'éclat contre prendre parti de panneaux de mur. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 14...
  • Page 43 à la droite. Placer sur les chevrons avec le toit de devant latte l'éclat avec le devant de chevron. Note, les bardeaux taillés sur le panneau de toit pour soutenir d'hangar. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 44 La position et obtient le Bon panneau de Toit Latéral en bas comme par les Etapes 37 & 38. Strong Ties Plus obtenir les panneaux de toit aux murs, la position 2 Simpson Strong Ties latte et hors des chevrons et obtient 4 - 1 1/4” vis. Compléter les deux côtés. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 16...
  • Page 45 Shingle Long et attacher comme par l'Etape 42. Sur votre dernier rang de bardeaux, le Bardeau de remplissage est précoupe pour ajuster convenablement. Attacher au toit avec 2 clous finaux par le bardeau. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 17...
  • Page 46 à l'encadrement. Note, le Coin Taille couvrira des vis dans les Etapes 53 & 54. Entraîner les trous de pilote dans prendre parti pour empêcher la répartition. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 47 Localiser le Corner Filler Trims (4 - 1/2” x 2 1/2” x pour le soutien supplémentaire puisque ce 75”) et le lieu dans les coins de devant de SpaceSaver. sera un haut secteur de circulation. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 19...
  • Page 48 Localiser la Vertical Door Trim - (2 - 1/2” x 2 1/2” x 77 1/2”). La position porte gauche taille l'é- clat avec hors de réduit le clou de mur. Tailler aussi devrait être aligné l'éclat avec skirting inférieur. Attacher avec 6 - 1 1/2” clous finaux. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 49 Complètement tailler coins hors des postérieurs, localiser Rear Trim -1/2 » x 2 1/2” x 88 3/4” et un Rear Corner Trim - 1/2” x 4 1/2” x 88 3/4”. Aligner et attacher comme par l'Etape 54. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 50 Doubles Portes. Disposer des Gonds également sur la porte mince comme indiquée au-dessus de et attacher avec le Noir 3/4” et 2” vis. Avec les Gonds attachés sur au panneau de porte, disposer dans l'ouverture d'embrasure. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 51 Localiser et identifier tous morceaux de Facia. Front Facia est 4” pendant que Rear Facia est 4 1/2” large. Side Angle Cut Facia est la coupure d'angle sur les deux fins. Dans le coin de devant, aligner Facia de côté et devant ensemble. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 52 Les Roof Ridge Boards de position à l'arrière de toit pour couvrir d'une capsule des bardeaux et facia. Le Conseil d'arête doit rencontrer sur la couture de panneau de toit. Quand aligné correcte- ment, attacher avec 3 - 2 1/2” vis. Visser dans dehors, mi et le chevron de centre. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 53 Door Frame La position et attache la Bride de Porte Verticale sur le cadre de porte d'intérieur (la porte gauche de dehors) utilisant 6 - 2” vis. Disposer sur le bord d'intérieur de cadre de porte. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
  • Page 54 Le morceau mâle de Boulon de Baril sera dis- posé sur la porte gauche taille. Attacher Facia/Detail Plates pour couvrir la couture où les morceaux de Facia de Devant vien- nent ensemble. Obtenir 4 - 1 1/2” clous finaux. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 26...
  • Page 55 6. Satisfaction générale. trompeuse quant aux positions, les déclarations ou les actions. S'il vous plaît l'appel, écrire ou nous envoyer un e-mail à : Outdoor Living Today Partnership P.O. Box 96 Sumas, Washington 98295 Toll Line: 1.888.658.1658 Fax: 1.604.462.5333...
