Thank you for purchasing
an 8x15 Santa Rosa Garden
Shed from Outdoor Living Today.
Please take the time to
identify all the parts prior
to assembly.
Safety Points and Other Considerations
Our products are built for use based on
proper installation and normal residential
use, on level ground. Please follow the
instruction manual when building your
Cabana and retain the manual for future
maintenance purposes.
Some of the safety and usage measures you may wish to consider include:
-snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to sweep the
snow off the roof(s).
-if the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
-in high or gusty wind conditions it is advisable to keep the structure securely grounded.
-have a regular maintenance plan to ensure screws, doors, windows and parts are tight.
Customer agrees to hold Outdoor Living Today Partnership and any Authorized Dealers free
of any liability for improper installation, maintenance and repair.
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Toll Free 1-888-658-1658
www.outdoorlivingtoday.com
Page 1
8x15 Santa Rosa
Assembly Manual
Version #4
Oct 2, 2008
sales@outdoorlivingtoday.com
Advertisement
Related Manuals for Outdoor living today 8x15 Santa Rosa
Summary of Contents for Outdoor living today 8x15 Santa Rosa
- Page 1 Customer agrees to hold Outdoor Living Today Partnership and any Authorized Dealers free of any liability for improper installation, maintenance and repair. In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase.
- Page 2 Thank you for purchasing our 8x15 Santa Rosa Garden Shed. Please take the time to identify all the parts prior to assembly. A. Floor Section E. Miscellaneous Section 4 - 45 1/2” x 75” - Floor Joist Frames Ridge Caps 4 - 45 1/2”...
- Page 3 Exploded view of all parts necessary to complete A. Floor Section Floor Section. Identify all parts prior to starting. Note, Floor Footprint is 182” deep x 96” wide. Plywood Floor Large (3) Plywood Floor Small (3) Floor Joist Frames Large (3) Floor Joist Concrete Pad Frames...
- Page 4 Lay out Floor Joist Frames as illustrated at left. There are 4 larger and 4 smaller Frame Sections. The Footprint for the floor when attached together will be 182” deep x 96” wide. Attach each large and small floor joist frames together with 6 - 2.5”...
- Page 5 Concrete Slab Foundation With Floor Runners attached, carefully flip the Complete all Floor Runners. floor over and place on your foundation. Caution- you will need 2 people to assist you. Be careful when laying floor down not to bend or twist floor. Foundations When in place, level floor completely.
-
Page 6: Table Of Contents
Attach 17 pieces of 1x5 1/2” Decking using 8 - 2 1/4” deck nails per piece. Attach both outside pieces first and equally space all others on the floor before attaching. Lay all Deck Boards down and evenly space them prior to attaching. Important - Make sure floor is level before moving... - Page 7 Dutch Door Lay out all the wall panels and become familiar with their location. On Standard Kits, there are 4 Window Wall Panels, 5 Solid Wall Panels, 1 Narrow Wall Panel and Dutch Door (top and bottom sections). Make sure to position panels right side up so water is directed away from and not into shed. Look at window wall panels to determine proper wall position to confirm.
- Page 8 Starting at Rear Corner, position a Wall Panel on top of plywood floor. Depending on your preference, you may use a solid or window wall panel in this position. If using a solid wall, make sure panel is facing up. Important: Make sure all walls are aligned in their upright position.
- Page 9 Start positioning and securing wall panels on your floor. Attach together as per Step 18. Be sure to correctly position wall panels so siding overhangs your floor and wall framing is flush with floor framing. When attaching front corner wall panel, make sure panel is nested inside the side panel. Line wall framing and secure at top, middle and bottom of wall studs.
- Page 10 narrow wall To complete walls, attach the Narrow Porch Wall to front wall panel. Note, the narrow wall is only 73” high. Attach wall stud to adjoining wall with 3 - 2 1/2” screws. Door Header with Dado Cut on Front Edge Attach Door Header to top of Narrow wall so Header is flush with framing on inside.
-
Page 11: Rear Top Plates
When all walls are attached together, check alignment with the floor. Bottom wall plates should sit flush with outside of plywood floor. When positioned correctly,fasten bottom wall plates to floor using 4 - 2 1/2” screws per wall panel. Wall Plate Position angle cut Rear Top Plates on top of wall studs so they are flush on the inside with 2x3 wall stud. -
Page 12: Side Top Plates
Next, attach the 6 Side Top Plates (3 per side). The side top plates are angle cut down the edge. Once again, position top plate on wall plate so it is flush with inside of wall plate. Side plate should also be flush with rear wall plate. -
Page 13: Front Wall Trim/Supports With 2 1/2"W Filler Strip
Top Plate Front Extension To complete the Porch Rail Section, the porch Corner sections must be assembled on level ground first. Bracket There are 2 sections. A . Attach 1x4 Top Plate Front Extension (45”L) to 4x4 Porch Post with 2 - 1 1/2” screws. Make sure support is flush with post. - Page 14 When both porch sections are completed, lift Right Side Section into place on deck beneath the side top plate. (Make sure to use the correct right/left side configuration.) Attach Wall Trim/ Support to wall with 3- 2 1/2” screws. Try to conceal screws if possible.
- Page 15 1/4” gap Place Top Door into place and space as per Bottom Door on sides. Leave a 1/4” gap between the Bottom and Top Door. When in correct position, secure hinges to Wall Trim/ Support as per previous step. Locate both Rear Gable Wall pieces. Rear Gables have shingles that overhang the top and bottom of the gable frame.
- Page 16 Position the Rear Gable Wall on top of the Rear Top Plate. The rear gable framing should sit flush with the inside of the top plate. It should also be centered sideways on the top plate. Hint: use a square to check the angle of the gable framing and top plate.
- Page 17 C. & D. Rafter and Roof Section Exploded view of all parts necessary to complete the Roof Section. Identify all parts prior to starting. (Roof Filler Shingles Missing) Outside Rear Middle Roof Roof Panels Outside Front Panels (4) Roof Panels Metal Ridge Ridge Boards Board...
- Page 18 Ridge Board Metal Ridge Locate 12 Rafters, 2 Soffits and Board Connector completed Ridge Board. Lay out on level ground as shown to the right. Screw doubled up Rafters together with 3 - 2 1/2” screws per piece. Note, completed rafter section will flipped over in Step 46.
- Page 19 Carefully lift 1 completed Rafter Section up. (make sure Soffit is facing down) and place on gable framing. Soffit Gable Notch Rafter Flush with end of wall Soffit should sit approx. 1/8” away Slide Rafter Section up on gable framing until bottom of from wall panel.
- Page 20 When Rafter Section is aligned correctly, tack Rafter Section temporarily down from Middle Gable Wall framing into Rafter with 2 - 2” screws. Note, Metal Ridge Board is offset with 1st Rafter Section Place 2nd completed Rafter Section on gable wall framing. Position as per Steps 47 & 49. Rear Gable Gable Notch When both Rafters Section are correctly aligned, Ridge Boards will sit in both the rear and...
- Page 21 Offsetting Metal Important: Ridge Board Make sure Metal Ridge Connectors Board Connectors are offset to one another as illustrated to the left. At the peak, align Ridge Boards so they are flush together and secure them with 16 - 1 1/4” screws. Important- if there is a gap between Ridge Boards, try pushing side walls closer together from outside.
- Page 22 2 1/2“ screw 91” across Attach Rafters in porch area into Top Plate of Roof Gussets are positioned on middle porch with 1 - 2 1/2” screw per Rafter. Once again, rafters. Prior to attaching, make sure walls are measure 91” from inside of wall plate to wall plate properly aligned.
- Page 23 Shingles overhang battens Outside Roof Panel with Roof facing on outside panels. Shingles overhanging end. down with roofing felt showing. Shingles and battens flush on middle panel. Identify Roof Panels. There are 2 Outside and 2 Middle Roof Panel per side. Starting with outside rear panel, lift up and place on rafters.
- Page 24 Aligned Middle Roof Panel as per Step 60 and screw panel down to rafters with 2 - 2 1/2” screws in the bottom row of shingles. Position 2nd Middle Roof Panel on Rafters as per Step 60 and attach as per Middle Roof Panel.
- Page 25 Lift up, position and attach remaining Middle and Outside Roof Panel on Rafters as per Step 60-61. Roof batten flush with end of rafter. 1 - 2 1/2” screw to secure Front Roof Panel. Lift up, position and attach right side Front Roof Panel on Rafters as per Step 62. Attach above the exposure line.
- Page 26 4- 90 degree Simpson Ties / Gable. Slide in another Filler Shingle and attach as per Step 67. On your last row of shingles, the filler shingle is Position 2 Simpson Strong ties on battens and precut to fit properly. Attach to roof outside rafters and secure 4 - 1 1/4”...
- Page 27 E. Miscellaneous Section Exploded view of all parts necessary to complete the Miscellaneous Section. Identify all parts prior to starting. Cedar Ridge Facia/Trim Detail Gusset Pentagon Detail Plates (5) Roof Caps Back Facia (2) Gable Plate (1) Front Gusset Side Facia Facia (2) Rear Seam Trim 75”...
- Page 28 Attach Bottom Skirting around the base of the shed. Skirting will hide floor framing. The front skirting pieces will overlap the side skirting. Start with side skirting for porch. Attach with 4 - 1 1/4” finishing nails per piece. The skirting will sit flush with the outside Side Skirting for Deck deck board.
- Page 29 Wide Trim Attach Wide Trims (2 - 1/2” x 4 1/2” x 82”) over filler trim. Use 8 - 1 1/4” finishing nails per piece. Once again, trim should be flush at bottom of bottom skirting. Attach Narrow Trims (8 - 1/2” x 2 1/2” x 79” long) to both sides of shed where wall seams come together.
- Page 30 Attach Back Facia (angle cut on ends) to end roof panel battens. Line facia up to form a peak and attach to battens with 8 - 1 1/4” finishing nails per piece. Back Facia will sit between Side Facia. Do a dry run of all corner facia to determine correct placement prior to attaching. Side Facia to run 5/8”...
- Page 31 Alternate left/right Ridge Caps 9” from end Undercourse Rid Cap Place First Roof Ridge Cap on roof peak overhanging shingles by approximately 2”. Attach with 2- 1 1/2” Shingle Nails 9” from end. Place 2nd Ridge Cap 1” back from 1st cap. Attach with 2- 1 1/2” Shingle Nails 9”...
- Page 32 exposed plywood of gable Attach Gable Facia to exposed plywood of gable with 2 - 1 1/4” finishing nails. End of gable facia will attach to side facia with 2 - finishing nails. Complete both sides. 4” Deck Post To complete porch, attach Deck Post and Handrail Section together. Measure 4” from bottom of post to align rail.
- Page 33 Attach Door Handle, Exterior Barrel Bolt and Interior Barrel Bolt to door. Handle is positioned on top door, Barrel Bolt on bottom door and Interior Barrel Bolt to top door stud. Use hardware provided in each kit. Interior Barrel Bolt. Attach Horizontal and Vertical Door Stops to door jamb and wall framing.
- Page 34 Congratulations on building your 8x15 Santa Rosa Garden Shed! Note; Our Sheds are shipped as an unfinished product. If exposed to the elements, the western red cedar lumber will weather to a silvery-gray color. If you prefer to keep the cedar lumber looking closer to the original color, we suggest that you treat the wood with a good oil base wood stain.
