Installing Motherboards into 2975-94xx Back Boxes (4100U/4100ES),
Continued
Connecting the
733-525 Harness
733-525 Harness
Connector with
Blue Wire Goes
to P2
Connector with
White Wire Goes
to P3
Figure 9. Power and Communication Wiring for Motherboard (4100U/4100ES)
14
733-996
HARNESS
