Cautions
READ AND SAVE THESE INSTRUCTIONS
and
followed to avoid damage to this product and associated equipment. Product operation and reliability depend upon proper
Warnings
installation.
DO NOT INSTALL ANY SIMPLEX® PRODUCT THAT APPEARS DAMAGED
inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify
an authorized Simplex product supplier.
ELECTRICAL HAZARD
be performed by a representative or authorized agent of your local Simplex product supplier.
STATIC HAZARD
• Ground yourself before opening or installing components.
• Prior to installation, keep components wrapped in anti-static material at all times.
EYE SAFETY HAZARD -
safety limits. Do not use magnification (such as a microscope or other focusing equipment) when viewing the output of this device.
FCC RULES AND REGULATIONS – PART 15
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a res-
idential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
SYSTEM REACCEPTANCE TEST AFTER SOFTWARE CHANGES -
accordance with NFPA-72, after any programming operation or change in site-specific software. Reacceptance testing is required after any change,
addition or deletion of system components, or after any modification, repair or adjustment to system hardware or wiring.
All components, circuits, system operations, or software functions known to be affected by a change must be 100% tested. In addition, to ensure that
other operations are not inadvertently affected, at least 10% of initiating devices that are not directly affected by the change, up to a maximum of 50
devices, must also be tested and proper system operation verified.
Introduction
The 4100-1340 TFX Audio Interface module converts 10 Vrms 4100U or 4100ES analog outputs
into 0.77 Vrms signals compatible with the AUTOCALL® AMP-96 audio riser. During a TFX-
500 or TFX-800 to 4100U or 4100ES master panel migration, the TFX Audio Interface module
provides a means to retain existing AMP-96 speaker circuits.
This publication covers the installation procedure of the TFX Audio Interface module into a
4100U or 4100ES Master control panel.
In this
This publication discusses the following topics:
Publication
©2007- 2011 SimplexGrinnell LP. All rights reserved.
Specifications and other information shown were current as of publication and are subject to change without notice.
Simplex and the Simplex logo and AUTOCALL are trademarks of Tyco International Ltd. and its affiliates and are used under license.
-
Follow the instructions in this installation manual. These instructions must be
- Disconnect electrical field power when making any internal adjustments or repairs. All repairs should
- Static electricity can damage components. Handle as follows:
Under certain fiber optic application conditions, the optical output of this device may exceed eye
- This equipment has been tested and found to comply with the limits for a Class A digital
Topic
firealarmresources.com
TFX Audio Interface Module
Installation Instructions
- Upon unpacking your Simplex product,
To ensure proper system operation, this product must be tested in
4100-1340,
See Page
2
3
7
579-815
Rev. C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Simplex 4100-1340
Summary of Contents for Simplex 4100-1340
- Page 1 Specifications and other information shown were current as of publication and are subject to change without notice. Rev. C Simplex and the Simplex logo and AUTOCALL are trademarks of Tyco International Ltd. and its affiliates and are used under license. firealarmresources.com...
- Page 2 Autocall TFX-500, TFX-800 series fire alarm panel Overview The 4100-1340 TFX Audio Interface Module interfaces the 4100U/4100ES Analog Audio Controller to existing AUTOCALL TFX AMP-96 amplifiers. It provides an AMP-96 compatible audio riser by converting the 10 Vrms audio signal from the 4100U/4100ES PDI to a 0.77 Vrms signal.
- Page 3 Introduction to TFX Audio Interface Module Physical The card is a flat, 4"x5" form-factor module that plugs into the 4100U/4100ES power distribution Specification interface. Figure 2. TFX Audio Interface Module Input Specifications • 24VDC • Supervisory or Alarm Current: Card Power: 29mA maximum Environmental Specifications •...
- Page 4 Introduction to TFX Audio Interface Module, Continued External Connectors, (continued) • 2 is a 3 position shield jumper. Refer to Table 2 for pinout description. Table 2: P2 Jumper Position Position Function 24C shield connection Earth shield connection(default) • P4 is a 6 position header used to select between Audio1 +/- or Audio2 +/- riser inputs •...
- Page 5 Introduction to TFX Audio Interface Module, Continued Field Wiring Figure 3 shows fields wiring information. Figure 3. Field Wiring Wiring Notes 1. All wiring to be in accordance with NEC (National Electronic Code), local authorities and applicable notes. 2. All wiring in the audio system is Power Limited. 3.
- Page 6 Introduction to TFX Audio Interface Module, Continued Field Wiring, Ground Fault Detection of Audio Riser Continued The output of the riser driver transformer is referenced to DC common of the power supply that is used to power the amplifier system. Because the riser is referenced to DC common, ground fault detection of the audio riser is possible.
- Page 7 Installing the TFX Audio Interface Module Overview The 4100U/4100ES TFX Audio Interface module mounts on a PDI in a 4100U/4100ES expansion bay. It can be mounted on any available block. Refer to Figure 4. Figure 4. Mounting TFX Audio Interface Module firealarmresources.com...
- Page 8 579-815 Rev. C firealarmresources.com...
