This publication describes the installation procedure for the 4100/4120-0154 and 4100-6048

Introduction

VESDA Interface modules.

This document covers the following topics:

•

Prerequisites

Before attempting to install the VESDA RS-232 interface card, make sure that the 4100 FACP

does not already have 10 MAPNET-style cards installed in it. A 4100 FACP limits the number of

MAPNET card slots to 10.

Remove AC power and disconnect the battery from the system when installing and wiring the

VESDA RS-232 interface card.

Inspecting Contents

Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If

of Shipment

damage is apparent, immediately file a claim with the carrier and notify Simplex.

•

Documentation

•

In this Publication

This publication discusses the following topics:



2001, Simplex Time Recorder Co., Westminster, MA 01441-0001 USA

All specifications and other information shown were current as of publication, and are subject to change without notice.

VESDA is a registered trademark of Vision Systems.

Configuring, wiring, and installing a VESDA RS-232 Interface card in a 4100/4100U FACP.

Adding supervisory wiring to a VESDA power supply. This wiring is only required for

VESDA power supplies, and is not required if VESDA detectors are powered by 4100 power

supplies.

Installation Guide for Detectors. This document ships with the VESDA LaserPLUS

detectors. It describes the installation and wiring of VESDA LaserPLUS detectors, and

contains instructions for connecting the detector network to the VESDA High Level Interface

(HLI) board.

4100 Field Wiring Diagrams 841-731 (power-limited) or 841-995 (non power-limited)

4100 Field Wiring Diagram 841-804

4100U Fire Alarm System Installation Guide (574-848)

Cautions and Warnings

Setting Jumpers

Setting Switches

Installing the Motherboard into 2975-91xx Back Boxes (4100)

Installing Motherboards into 2975-94xx Back Boxes (4100U)

Installing the Daughter Card

Wiring

Adding a Power Supervision Circuit for VESDA Power Supplies

firealarmresources.com

4100/4120-0154, 4100-6048

VESDA

Installation Instructions

Topic

   

Interface Card

See Page #

574-050

Rev. A

Need help?

Do you have a question about the VESDA 4120-0154 and is the answer not in the manual?

Questions and answers

Summary of Contents for Simplex VESDA 4120-0154

Page 1 Remove AC power and disconnect the battery from the system when installing and wiring the VESDA RS-232 interface card. Inspecting Contents Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If of Shipment damage is apparent, immediately file a claim with the carrier and notify Simplex.
Page 2 Product operation and reliability depends upon proper installation. ELECTRICAL HAZARD - Disconnect electrical field power when making any internal adjustments or repairs. Servicing should be performed by qualified Simplex Representatives. STATIC HAZARD - Static electricity can damage components. Therefore, handle as follows: •...
Page 3 Setting Jumpers Verifying Jumper All jumpers on the VESDA RS-232 interface daughter card are factory preset and should not Settings require modification. If necessary, use this section to verify that the jumpers are in the correct positions. See Table 1 and Figure 1. Table 1.
Page 4 Setting Switches Switches Switch SW1 on the VESDA RS-232 interface daughter card is a bank of eight dip switches. From left to right (see figure below) these switches are designated as SW1-1 through SW1-8. The function of these switches is as follows: •...
Page 5 Setting Switches, Continued Switches (continued) Table 2. 4100 Daughter Card Addresses Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 firealarmresources.com...
Page 6 Installing the Motherboard into 2975-91xx Back Boxes (4100) Overview The VESDA motherboard can be mounted to either 4100 Back Boxes (PID series 2975-91xx) or 4100U Back Boxes (PID series 2975-94xx). • The 4100/4120-0154 is used for systems with 4100 Back Boxes. •...
Page 7 Installing the Motherboard into 2975-91xx Back Boxes (4100), Continued Installing into a Review the following guidelines before mounting the motherboard into a 2975-91xx Expansion 2975-91xx Bay. Expansion Bay • If a power supply is installed in the bay, it must be installed on the far right of the bay and any relay modules must be installed in the slots immediately to its left.
Page 8 Installing the Motherboard into 2975-91xx Back Boxes (4100), Continued Connecting the If you need to connect a 733-525 Harness to a motherboard, refer to Figure 5 and follow these 733-525 Harness steps. Make sure to route the power and communication wiring on the left side of the bay. Connect one end of the harness to a motherboard in an adjacent bay.
Page 9 Installing the Motherboard into 2975-91xx Back Boxes (4100), Continued Connecting the Connect the other end of the harness to the leftmost motherboard in the next bay, as described 733-525 Harness below. Make sure to route the wiring on the left side of the bay. (continued) Insert the harness connector with the blue wire into the P2 connector.
Page 10 Installing Motherboards into 2975-94xx Back Boxes (4100U) Overview The VESDA motherboard can be mounted to either 4100 Back Boxes (PID series 2975-91xx) or 4100U Back Boxes (PID series 2975-94xx). • The 4100/4120-0154 is used for systems with 4100 Back Boxes. •...
Page 11 Installing Motherboards into 2975-94xx Back Boxes (4100U), Continued Installing into a When installing 2 x 11 ½-inch motherboards in a 4100U expansion bay, adhere to the following 2975-94xx guidelines: Expansion Bay • Each expansion bay assembly includes a chassis, two end supports, one LED/switch frame, and a power distribution interface (PDI) board.
Page 12 Installing Motherboards into 2975-94xx Back Boxes (4100U), Continued Installing into a Use the following procedure when installing motherboards in an expansion bay. Start with the 2975-94xx second slot from the left and fill to the right. Expansion Bay (continued) Orient the motherboard with the connector labeled J1 on the right and the header labeled P1 on the left.
Page 13 Installing Motherboards into 2975-94xx Back Boxes (4100U), Continued Connecting the If you need to connect a 733-525 Harness to a motherboard, refer to Figure 9 and follow these 733-525 Harness steps. Make sure to route the power and communication wiring on the left side of the bay. Connect one end of the harness to a motherboard in an adjacent bay.
Page 14 Installing Motherboards into 2975-94xx Back Boxes (4100U), Continued Connecting the 733-525 Harness (continued) 733-996 HARNESS 733-525 Harness Connector with Blue Wire Goes to P2 Connector with White Wire Goes to P3 Figure 9. Power and Communication Wiring for Motherboard (4100U) firealarmresources.com...
Page 15 Installing the Daughter Card Installing the The daughter card inserts into the connector located in the center of the motherboard. The Daughter Card connector is keyed so that the daughter card fits only one way. Before installing the card, examine the slot in the motherboard and the fingers on the daughter card and note where the key is located.
Page 16 Wires can run a distance of 10, 000 feet, maximum. • Conductors must test free of all grounds. • Power must come from a Simplex-approved power supply. • All wiring must be done using copper conductors only, unless noted otherwise. •...
Page 17 Wiring, Continued Power-Limited Make sure these guidelines are accounted for before wiring for power-limited systems: Guidelines • Non-power limited field wiring (AC power, batteries, City connection) must be installed and routed in the shaded areas shown in Figure 11. • Power-limited field wiring must be installed and routed in the non-shaded areas shown in Figure 11, with the exception of City wiring.
Page 18 Wiring, Continued • Power-Limited Auxiliary power only: In order to connect a circuit using power-limited wiring, the devices Guidelines being powered must all be addressable, or a UL Listed EOL relay must be used to supervise (continued) the circuit. Refer to Figure 12 for wiring directions for the EOL relay. TO AU POWER Note: BLACK...
Page 19 Wiring, Continued Connecting the Wire the 733-571 Harness as shown in Figure 13. Make sure to connect the wires to the terminals 733-571 Harness located at the top of the motherboard. Note: Neither the terminals at the bottom of the motherboard nor the motherboard’s RS-232 connectors are functional.
Page 20 Power for the VESDA detectors must be from either a VESDA-supplied, UL-Listed power supply, or a Simplex 4100 supply. The voltage range is 20.4 V to 32 V with a current drop of 70 mA. Situations in which the VESDA detectors are powered by VESDA power supplies require the addition of a supervisory wiring circuit.
