- Page 1 Installation and maintenance guide PowerLuber grease gun (lithium ion) 1262E, series “A”, base model 1260, original instruction Date of issue February 2023 Form number 425014 Version...
-
Page 2: Table Of Contents
Contents Declaration of Conformity* ......U.K. Declaration of Conformity* ......Safety* . -
Page 3: Declaration Of Conformity
• EN 62233-1:2008 I, the undersigned of Lincoln Industrial Corporation, do hereby declare that the equipment specified above, in its intended use, conforms to the requirements of the above directives and harmonized standards at the time of placing the above product on the market. -
Page 4: U.k. Declaration Of Conformity
• EN 62233-1:2008 I, the undersigned of Lincoln Industrial Corporation, hereby declare that the equipment specified above, in its intended use, conforms with all requirements of the U.K. legislation Supply of Machinery (Safety) Regulations 2008 No. 1597 by the time of placing it on the market. -
Page 5: Safety
Safety* Explanation of signal WARNING Do not allow any body part words for safety to be trapped by equipment. The assembly must be installed, maintained Body parts can be crushed and repaired exclusively by persons familiar by subassemblies during with the instructions. -
Page 6: Intended Use
Electrical safety Personal safety Intended use This PowerLuber was exclusively designed • Power tool plugs must match the out- • Stay alert, watch what you are doing to pump and dispense lubricant using 12 V let. Never modify the plug in any way. and use common sense when battery power. -
Page 7: Power Tool Use And Care
689 bar • Store idle power tools out of the reach • Under abusive conditions, liquid may be (10,000 psi). Use only Lincoln 1218, 1224, of children and do not allow persons ejected from the battery; avoid contact. -
Page 8: Residual Risks
Do not use any hose not approved by Vibration emission value during actual The PowerLuber has been designed to Lincoln. Extreme pressure may cause use of power tool can differ from operate over a long period of time with a nozzle extension or whip hose to burst. -
Page 9: Protecting The Environment
Battery liquid may burn. charger Do not splash or immerse in water or Should you find one day that your Lincoln other liquids. This may cause premature product needs replacement, or if it is of no cell failure. -
Page 10: Charger
If the supply cord is damaged, it must be physical, sensory or mental capabilities or replaced by the manufacturer or an author- lack of experience and knowledge. ized Lincoln service center in order to avoid a Charger • The Lincoln model 1261 battery pack con- hazard. -
Page 11: Tool Use And Care
12 V poorly maintained tools. Capacity 1 500 mAh • Use only accessories that are recom- mended by Lincoln. Battery charger (E) Model 1870E TYPE 2 Charge time 40 minutes • Do not use any accessory that is not capa- Input 220 –... -
Page 12: General Description
General description Fig. 1 1260 series PowerLuber grease gun Lincoln’s 1260 PowerLuber is a lithium-ion battery-operated grease gun developed for manual lubrication of grease points. Driven by a small, low-voltage electric motor that is connected to a gear transmis- sion. Rotary motion of the motor is con- verted into a reciprocating motion of the plunger, using a yoke mechanism. -
Page 13: Replace Grease Cartridge Or Refill Tube
Replace grease cartridge or Install grease cartridge NOTE refill tube Air pockets in cartridge lubricant cause 1 Unscrew the grease tube assembly from the grease gun to lose prime. Prime the PowerLuber after each refill or PowerLuber. Always open vent valve after replacing grease cartridge change. -
Page 14: Fill Gun From Bulk Container
NOTE Remove air pocket! Air pocket at grease inlet prevents grease from being pumped. Unscrew vent valve three to four turns to remove small air pockets trapped in this area. If air pocket is substantial and no grease flows from coupler after trig- ger is pulled for 15 seconds, refer to following steps, Expel air pockets. -
Page 15: Charger Operation
Lincoln chargers are designed to charge 1 The charger and battery may become warm NOTE Lincoln lithium-ion batteries in 30 to 90 to the touch while charging. This is a nor- Do not obstruct vent slots in top and minutes depending on the battery’s state of mal condition, and does not indicate a bottom of charger. -
Page 16: Exploded View And Parts List
Exploded view and parts list Fig. IPB 1 Parts list Part no. Description 280213 Hardware kit (1260) 280244 Pump assembly kit (1262E) 1230 Hose, 3,1 mm ID x 762 mm long (0.125 in ID x 30 in long) 280235 Trigger, switch kit 280211 Decal kit 280210... - Page 17 Exploded view and parts list Fig. IPB 2 Parts list Part no. Description 280212 Housing with bearing kit 280245 Motor kit (1262E) 280214 Gear set kit (1260) 280215 Piston, yoke kit 280232 Driver assembly kit 280231 Check valve kit 286315 Vent valve kit...
- Page 18 Troubleshooting Condition Possible cause Corrective action PowerLuber fails to dispense grease. Grease tube assembly is out of grease. Check that grease tube assembly has grease. Loss of prime. Repeat priming operation. Ball check is not functioning. Remove ball check clean and inspect ball seat area. Clogged whip hose.
-
Page 19: Warranty
® SKF and Lincoln are registered trademarks of the SKF Group. © SKF Group 2023 The contents of this publication are the copyright of the publisher and may not be reproduced (even extracts) unless prior written permission is granted. Every care has been taken to ensure the accuracy of the information contained in this publication but no liability can be accepted for any loss or damage whether direct, indirect or consequential arising out of the use of the information contained herein.
