Gardener's 8613058 Quick Start Manual

OVER THE TOP CUCUMBER TRELLIS GREEN

PARTS LIST

(2) Side Panel (With Sleeve):46" H x 16" W
(2) Side Panel (With Pin): 46" H x 16" W
(1) Top Panel (With Sleeve): 46" H x 16" W
(1) Top Panel (With Pin): 46" H x 16" W
(2) Spike: 48"H
NOTE: Assembly is best with two people. It is easiest to assemble your trellis on the ground. Choose a
flat, clean surface to execute your assembly.
1. Insert side panel(with pin) into the side panel(with sleeve). Make sure the U-shaped clips of both panels
are on the upper side. Repeat this process for the other side panel as well.
U-shaped clips
2. Insert top panel(with pin) into top panel(with sleeve).
Top Panel (With Pin)
Side Panel
(With Sleeve)
46" H x 16" W
Side Panel
(With Pin)
46"H x 16" W
Top Panel (sleeve)
Side Panel
Assembled:
46"H x 32" W
Top Panel Assembled: 46" H x 32" W
U-shaped clips
Turn over please
