Self-Watering Metal Raised Bed
Parts List
2' x 4' Raised Bed
(2) RESERVOIRS and RESERVOIR TOPS
(1) CONNECTING TUBE
(1) FILL TUBE
(1) WATER LEVEL INDICATOR
(2) CAPS
Tools Required
Assemble your Metal Raised Bed (shipped separately) according to the instructions provided, and place it
Snips or shears
in the garden. Then, follow the instructions below to install the self-watering system.
1. Use CAPS to seal connector ports.
(Seal one port on each RESERVOIR for
both the 2' x 4' and 4' x 4' beds; seal
one port on only two RESERVOIRS for
the 2' x 8' bed.)
3. Remove perforated circle in
RESERVOIR TOP(S) to create a hole
for the FILL TUBE. (Remove just one
perforated circle for the 2' x 4' and 2' x
8' beds; two for the 4' x 4' bed.)
Filling and Planting
Fill your raised bed with a lightweight mix designed for self-watering containers, such as our Organic Self-Watering Potting Mix. Add
some compost and a slow-release fertilizer for best results. Press the potting mix into the channels in RESERVOIR TOPS to ensure
good water-soil contact. Fill the RESERVOIRS completely using the FILL TUBE. You're now ready to plant! While plants are getting
established, or in higher temperatures, water regularly from the top too.
#8610207 #8610208 #8610394
Shown here:
2' x 4' Self-Watering
Metal Raised Bed
2' x 8' Raised Bed
(4) RESERVOIRS and RESERVOIR TOPS
(3) CONNECTING TUBES
(1) FILL TUBE
(1) WATER LEVEL INDICATOR
(2) CAPS
2. Link RESERVOIRS with CONNECTING TUBE(S) by sliding the
tubes fully over each port. Place inside your raised bed, add
some water, and check for leaks. (For the 2' x 8' bed you will
connect all four RESERVOIRS in a single row. For the 4' x 4' bed
you will create two pairs of connected RESERVOIRS.)
4. Add RESERVOIR TOPS to RESERVOIRS. Then insert FILL TUBE(S) into the holes you created
in Step 3. The FILL TUBE is notched so you can set it at multiple heights. Be sure to set it above
your desired soil planting line. Once placed, slide outer section up if needed (for additional
height), then insert WATER LEVEL INDICATOR, foam end down. You may need to trim indicator
to close cap. Note: The WATER LEVEL INDICATOR should rise up when reservoirs are full. The
foam end, however, may become caught under the FILL TUBE during filling. If this happens,
gently jostle it free.
8% of our profits
Learn more at gardeners.com/
4' x 4' Raised Bed
(4) RESERVOIRS and RESERVOIR TOPS
(2) CONNECTING TUBES
(2) FILL TUBE
(2) WATER LEVEL INDICATOR
(4) CAPS
go back to our communities.
FoRCE-FoR-GoOD
1-800-876-5520 • gardeners.com
info@gardeners.com
Shown here:
2' x 8'
Self-Watering
Metal Raised
Bed
1393G Rev 12/2020
