Pakedge WR-1 Quick Start Manual

802.11ac wireless router with ovrc
Hide thumbs Also See for WR-1:

Advertisement

Quick Links

Download this manual
WR-1
802.11ac Wireless Router
with OvrC
OvrC
Enabled
QUICK START GUIDE

Advertisement

loading

Related Manuals for Pakedge WR-1

Summary of Contents for Pakedge WR-1

  • Page 1 WR-1 802.11ac Wireless Router with OvrC OvrC Enabled QUICK START GUIDE...
  • Page 2 Introduction The Pakedge WR-1 Wireless Router with OvrC gives you the convenience of a high- throughput wired router integrated with an 802.11ac Wave 2 wireless access point. The router has features like high throughput and secure OpenVPN, while also supporting UPnP for simple compatibility with common consumer devices.

  • Page 3: Package Contents

    • (1) Power adapter • (1) Quick Start Guide • (1) Ethernet cable User guide • For more detailed instructions, refer to the WR-1 User Guide ( pkdge.co/wr1-ug Specifications • System requirements: Windows or Mac PC with an Ethernet interface.
  • Page 4 Overview 前视图 后视图 RESET 12V/1.5A F RESET button A Power G USB port B Internet H LAN ports C LAN port activity D 2.4 GHz active WAN (to modem/Internet) port E 5 GHz active J Power connector...
  • Page 5 3 Connect an Ethernet cable from your ISP modem to the WAN port on the WR-1. 4 Connect power to the WR-1. You are now ready to configure the unit to allow Internet access and register with...
  • Page 6 1 After power is connected and a computer is connected to the LAN port, enter the WR-1’s IP address into the address bar of your web browser. A login screen opens. Default settings: The IP address will be automatically set to 192.168.1.1.
  • Page 7 Quick setup: WAN zone options DHCP By default, the wireless router will connect to the Internet using DHCP. If your ISP uses DHCP, you may need to reset the modem to get Internet access.
  • Page 8 Static IP If your ISP uses static IP, enter the IPv4 address, IPv4 subnet mask, IPv4 gateway, and DNS server provided by your ISP. Select Custom from the Subnet mask drop-down menu to enter a custom subnet mask.
  • Page 9 PPPoE If your ISP uses PPPoE, enter the username that the ISP assigned under the PAP/ CHAP username field. Enter the password in the PAP/CHAP password field. For the Use custom DNS servers field, enter the DNS server you would like to use. For example, you can use 8.8.8.8.
  • Page 10 Registering your WR-1 with OvrC OvrC gives you remote device management, real-time notifications, and intuitive customer management, right from your computer or mobile device. Setup is plug-and- play, with no port forwarding or DDNS address required. To add this device to your OvrC account:...

  • Page 12: Technical Support

    Latest version at pkdge.co/wr1-qsg 11734 Election Road, Draper, UT 84020 Main: (650) 385-8700 Fax: (650) 685-5520 www.pakedge.com sales@pakedge.com QSG-WR-1-F 2021-06-30 TW Copyright ©2021, Snap One, LLC. All rights reserved.
