- Page 1 RT-3100 High-throughput Gigabit AV Router with BakPak BakPak Enabled QUICK START GUIDE...
- Page 2 Introduction The Pakedge RT-3100 High-throughput Gigabit AV Router gives you incredibly fast speeds and unmatched ease of use for a mid-sized network, including a simple configuration page for fast setup. The router has common features like port forwarding, 1:1 NAT, and static routes, while also supporting advanced configuration of firewall and multicast forwarding rules.
-
Page 3: Installing The Router
Installing the router Tools required: • Phillips screwdriver (if using rack-mount brackets) • Computer with Ethernet interface and a web browser • Ethernet cable Installation 1 Open the box and remove the router. 2 If mounting the router in a standard 19" AV rack, attach the included rack-mount brackets to the sides of the router. - Page 4 Logging in 1 Connect the router to power and toggle the power switch on the rear panel to the On position. The PWR LED will light up. 2 Connect a computer to the router’s LAN port using an Ethernet cable. Enter 192.168.1.1 into the address bar of your web browser.
- Page 5 The first-time configuration screen opens, which enables you to configure all basic router settings to get up and running quickly. 4 Change the settings, including the login credentials, then click Apply. 5 To see an overview of your router status, click the Overview tab. 6 To register the router with BakPak, click the BakPak icon in the top menu bar.
- Page 6 The BakPak Registration page allows you to connect this router to your existing BakPak account, or create a new account to manage all of your BakPak Management Agents. Note: For more detailed instructions for this device and for the BakPak Management ctrl4.co/rt3100-ug Agent, refer to the RT-3100 User Guide (...
- Page 7 Creating a new Bakpak Cloud account 1 Click the HERE link on the BakPak Registration page or open a web browser and https://mybakpak.com enter the following URL: 2 Click [Create a] Dealer Admin Account. The Register for mybakpak page opens. 3 Follow the on-screen instructions to get your Dealer Code.
-
Page 8: Technical Support
Technical Support For technical help: www.pakedge.com/portal support@pakedge.com +1 (650) 385-8703 For regulatory information: www.pakedge.com/regulatory Latest version at pkdge.co/rt3100-qsg 11734 Election Road, Draper, UT 84020 Main: +1 (650) 385-8700 Fax: +1 (650) 685-5520 www.pakedge.com sales@pakedge.com 200-00569-B 2019-05-17 MS ©2019 Control4. All rights reserved.
