Dantel A23-41073-00 Installation & Operation Manual

About this Practice:
This practice has been reissued to:
• Add lamp replacement procedure
to Operation section.
Reissued Practices: Updated and
new content can be identified by a
banner in the right margin.
Issue date: February 1999
Copyright 1999 by Dantel, Inc. • Dantel is a registered trademark of Dantel, Inc. • ISO 9001 Registered
A23-41072 A
P
ILOT

Table of Contents

Ordering Information ............................................................................ 2
General Description ............................................................................... 2
Circuit Description ................................................................................ 2
Application Information ......................................................................... 4
Installation ............................................................................................ 5
Operation ............................................................................................... 6
Technical Specifications ......................................................................... 7
Warranty ............................................................................................... 8
CAUTION
•
Install or remove modules from the shelf only when the power is off.
If you install a module in the shelf with the power on, the internal
circuitry may suffer damage and the product warranty will be void.
•
Remove and install circuit boards only in a static-safe environment
(use antistatic wrist straps, smocks, footwear, etc.).
•
Keep circuit boards in their antistatic bags when they are not in use.
•
Do not ship or store circuit boards near strong electrostatic, electromag-
netic, magnetic, or radioactive fields.
•
For more complete information on electrostatic discharge safety
precautions, refer to Bellcore
Printed in the U.S.A.
I
NSTALLATION
41072-0299 <90-00053>
A
LARM
Technical Reference # TR-NWT-000870.
TM
& O M
PERATION ANUAL
ISLE
U
NIT
